Effect of via-Array Side Walls on the Characteristics of SIW Resonator with Novel Design Equations
By
Progress In Electromagnetics Research B, Vol. 104, 35-50, 2024
Abstract
The present work proves by both simulation and experimental work that the most common empirical formulas available in the previous publications for the design of substrate-integrated waveguide (SIW) cavities are incorrect in most cases. Moreover, the present work provides correct and exact design equations that are examined by both simulation and experimental work. In planar circuit structures, rectangular waveguide and resonators are commonly integrated within a dielectric substrate to produce what is known as SIW structures. For ease of fabrication and embedding into the dielectric substrate, the closed (solid) side walls of the rectangular waveguides and resonators are replaced by metallic via arrays. The main concern of the present paper is to investigate the effects of such replacement on the performance of a SIW resonator through simulation as well as experimental work. The limiting constraints on the relative dimensions of such via arrays including the diameter of the vias and the spacing between them are numerically and experimentally investigated to ensure proper operation of the SIW resonator regarding the radiation loss due to leakage from the openings of the resonator side walls. The effects of the via array dimensions on the resonant frequency, radiation loss, and quality factor (Q-factor) of the resonator are evaluated. For this purpose, two models of the rectangular resonator embedded in the dielectric substrate are designed to operate at 10 GHz. The first model is an ideal box-shaped resonator of solid side walls whereas the other model is the conventional SIW resonator with via-array side walls. The two types of the substrate embedded resonators are fed through a microstrip line. The resonant frequency, losses, and Q-factor of the two resonator models are compared to each other taking the box-shaped resonator as a reference because of its ideal structure to evaluate the performance of a conventional SIW resonator. The two types of resonator are fabricated for comparison through experimental measurements. The empirical design equations that are commonly available in literature to calculate the effective dimensions of the SIW resonator are investigated by comparison with the exact simulation results and shown to be incorrect in most cases. More accurate and reliable design equations are proposed in the present work. The results of the proposed design equations are compared to the simulation results showing excellent accuracy and shown to be more reliable than those available in literature.
Citation
Samar M. Azab, Abdelhameed Abdelmoneim Shaalan, Khalid Fawzy Ahmed Hussein, and Asmaa Elsayed Farahat, "Effect of via-Array Side Walls on the Characteristics of SIW Resonator with Novel Design Equations," Progress In Electromagnetics Research B, Vol. 104, 35-50, 2024.
doi:10.2528/PIERB23071501
References

1. Hussein, Y. M., M. K. A. Rahim, N. A. Murad, M. M. Jawad, H. O. Hanoosh, H. A. Majid, and H. H. A. Keriee, "Substrate integrated waveguide and microstrip antennas at 28 GHz," Bulletin of Electrical Engineering and Informatics, Vol. 9, No. 6, 2462-2468, 2020.
doi:10.11591/eei.v9i6.2190

2. Donelli, M., S. K. Menon, G. Marchi, V. Mulloni, and M. Manekiya, "Design of an ultra wide band antenna based on a SIW resonator," Progress In Electromagnetics Research C, Vol. 103, 187-197, 2020.

3. El Khamlichi, Dahbi, Naima Amar Touhami, Tajeddin Elhamadi, and Imane Badaoui, "Broadband antenna SIW for X-band application," International Conference Interdisciplinarity in Engineering, Vol. 46, 808-813, 2020.

4. Miligy, A., A. Hussein, H. Nadir, and M. Rizk, "Investigation and implementation of integrated SIW system for hexagonal diamond of Lamda shape slots fractal array antenna for X and Ku-band applications," International Journal of Telecommunications, Vol. 1, No. 1, 1-25, 2021.
doi:10.21608/ijt.2021.266277

5. Al-Fadhali, Najib, Huda Majid, and Rosli Omar, "Multiband frequency reconfigurable substrate integrated waveguide antenna using copper strip for cognitive radio applicable to internet of things application," Telecommunication Systems, Vol. 76, No. 3, 345-358, Mar. 2021.
doi:10.1007/s11235-020-00721-6

6. Usman, Muhammad, Enis Kobal, Jamal Nasir, Yuanwei Zhu, Chao Yu, and Anding Zhu, "Compact SIW fed dual-port single element annular slot MIMO antenna for 5G mmWave applications," IEEE Access, Vol. 9, 91995-92002, 2021.
doi:10.1109/ACCESS.2021.3091835

7. Serhsouh, Imane, Mohamed Himdi, Hassan Lebbar, and Hamsakutty Vettikalladi, "Reconfigurable SIW antenna for fixed frequency beam scanning and 5G applications," IEEE Access, Vol. 8, 60084-60089, 2020.
doi:10.1109/ACCESS.2020.2983001

8. Rhbanou, Ahmed, Seddik Bri, and Mohamed Sabbane, "Analysis of substrate integrated waveguide (SIW) resonator and design of miniaturized SIW bandpass filter," International Journal of Electronics and Telecommunications, Vol. 63, No. 3, 2017.
doi:10.1515/eletel-2017-0034

9. Grine, Farouk, Tarek Djerafi, Mohamed Taoufik Benhabiles, Ke Wu, and Mohamed Lahdi Riabi, "High-Q substrate integrated waveguide resonator filter with dielectric loading," IEEE Access, Vol. 5, 12526-12532, 2017.
doi:10.1109/ACCESS.2017.2711958

10. Hirokawa, J. and M. Ando, "Single-layer feed waveguide consisting of posts for plane TEM wave excitation in parallel plates," IEEE Transactions on Antennas and Propagation, Vol. 46, No. 5, 625-630, May 1998.
doi:10.1109/8.668903

11. Cassivi, Y., L. Perregrini, P. Arcioni, M. Bressan, K. Wu, and G. Conciauro, "Dispersion characteristics of substrate integrated rectangular waveguide," IEEE Microwave and Wireless Components Letters, Vol. 12, No. 9, 333-335, Sep. 2002.
doi:10.1109/LMWC.2002.803188

12. Xu, F. and K. Wu, "Guided-wave and leakage characteristics of substrate integrated waveguide," IEEE Transactions on Microwave Theory and Techniques, Vol. 53, No. 1, 66-73, Jan. 2005.
doi:10.1109/TMTT.2004.839303

13. Rayas-Sanchez, Jose E. and Vladimir Gutierrez-Ayala, "A general EM-based design procedure for single-layer substrate integrated waveguide interconnects with microstrip transitions," 2008 IEEE MTT-S International Microwave Symposium Digest, 983-986, IEEE, Atlanta, Ga, Jun. 2008.

14. Che, Wenquan, Dapeng Wang, Lei Xu, and Cuixia Li, "Investigation on quality factor of substrate-integrated waveguide resonance cavity," Microwave and Optical Technology Letters, Vol. 49, No. 8, 2007-2010, Aug. 2007.
doi:10.1002/mop.22592

15. Che, W., K. Deng, D. Wang, and Y. L. Chow, "Analytical equivalence between substrate-integrated waveguide and rectangular waveguide," IET Microwaves, Antennas & Propagation, Vol. 2, No. 1, 35-41, 2008.
doi:10.1049/iet-map:20060283

16. Deslandes, Dominic and Ke Wu, "Accurate modeling, wave mechanisms, and design considerations of a substrate integrated waveguide," IEEE Transactions on Microwave Theory and Techniques, Vol. 54, No. 6, 2516-2526, Jun. 2006.
doi:10.1109/TMTT.2006.875807

17. Bozzi, M., M. Pasian, L. Perregrini, and K. Wu, "On the losses in substrate-integrated waveguides and cavities," International Journal of Microwave and Wireless Technologies, Vol. 1, No. 5, 395-401, 2009.
doi:10.1017/S1759078709990493

18. Bozzi, Maurizio, Luca Perregrini, and Ke Wu, "Modeling of conductor, dielectric, and radiation losses in substrate integrated waveguide by the boundary integral-resonant mode expansion method," IEEE Transactions on Microwave Theory and Techniques, Vol. 56, No. 12, 3153-3161, Dec. 2008.
doi:10.1109/TMTT.2008.2007140

19. Grine, Farouk, Tarek Djerafi, Mohamed Taoufik Benhabiles, Ke Wu, and Mohamed Lahdi Riabi, "High-Q substrate integrated waveguide resonator filter with dielectric loading," IEEE Access, Vol. 5, 12526-12532, 2017.
doi:10.1109/ACCESS.2017.2711958

20. Delmonte, N., M. Bozzi, L. Perregrini, and C. Tomassoni, "Miniaturization and quality-factor in substrate integrated waveguide cavities," 2018 IEEE MTT-S International Conference on Numerical Electromagnetic and Multiphysics Modeling and Optimization (NEMO), 1-4, IEEE, 2018.

21. Deslandes, Dominic, "Design equations for tapered microstrip-to-substrate integrated waveguide transitions," 2010 IEEE Mtt-s International Microwave Symposium Digest (MTT), 704-707, IEEE, Anaheim, Ca, May 2010.

22. Cheng, David Keun, Field and Wave Electromagnetics, Pearson Education India, 1989.

23. Pozar, D. M., Microwave Engineering, 3 Ed., John Wiley & Sons, Inc., 2005.

24. Raju, G. S. N., Electromagnetic Field Theory and Transmission Lines, Pearson Education India, 2006.

25. Jordan, E. C. and K. G. Balmain, Electromagnetic Waves and Radiating Systems, Prentice Hall, Englewood Cliffs, New Jersey, 1968.

26. Bozzi, M., A. Georgiadis, and K. Wu, "Review of substrate-integrated waveguide circuits and antennas," IET Microwaves Antennas & Propagation, Vol. 5, No. 8, 909-920, Jun. 2011.
doi:10.1049/iet-map.2010.0463

27. Akkader, S., H. Bouyghf, and A. Baghdad, "Unloaded quality factor optimization of substrate integrated waveguide resonator using genetic algorithm," IJECE, Vol. 13, 2857, 2023.

28. Lin, Gu and Yuandan Dong, "A compact, hybrid SIW filter with controllable transmission zeros and high selectivity," IEEE Transactions on Circuits and Systems II: Express Briefs, Vol. 69, No. 4, 2051-2055, Apr. 2022.
doi:10.1109/TCSII.2022.3144268

29. Varcheh, Hamed Nimehvari, Pejman Rezaei, and Sina Kiani, "Planar substrate integrated waveguide-based resonators and its usage to compact X-band small phase noise oscillator," Microwave and Optical Technology Letters, Vol. 65, No. 1, 54-61, Jan. 2023.
doi:10.1002/mop.33453
