Abstract

Nanostructure based perovskite solar cell with high performance is the emphasis of study in current work keeping in view the improvement in cell efficiency. In the first part of the study, a plane-layered solar cell is studied by adding a 1D photonic crystal at the bottom of the cell in order to facilitate the photon rotation process. However, in the second part of the study, it is observed that addition of grating enhances the light absorption due to photons trapping. Following that, the light absorption of three different structures is compared. The observations reveal that short-circuit current density (Jsc) is found to be -39.93 mA/cm², which is 87.29% higher than that for a planar structure exhibiting the Jsc value as -21.32 mA/cm². Ultimately, the efficiencies of these perovskite solar cells based on nanostructures are observed to be significant as well. For the proposed solar cell structure, an 87.24% improvement in the power conversion efficiency (PCE) is observed i.e., from 14.03% for the planar structure to 26.27%.

1. Service, R. F., "Perovskite solar cells keep on surging," Science, Vol. 344, 458-458, 2014.
doi:10.1126/science.344.6183.458

2. McGehee, M. D., "Fast-track solar cells," Nature, Vol. 501, 323-325, 2013.
doi:10.1038/nature12557

3. Kojima, A., K. Teshima, Y. Shirai, and T. O. Miyasaka, "Halide perovskites as visible-light sensitizers for photovoltaic cells," J. Am. Chem. Soc., Vol. 131, 6050-6051, 2009.
doi:10.1021/ja809598r

4. Nie, W., et al. "High-efficiency solution-processed perovskite solar cells with millimeter-scale grains," Science, Vol. 347, 522-525, 2015.
doi:10.1126/science.aaa0472

5. Rühle, S., "Tabulated values of the Shockley-Queisser limit for single junction solar cells," Sol. Energy, 2016.

6. Zhou, H., et al. "Interface engineering of highly efficient perovskite solar cells," Science, Vol. 345, 542-546, 2014.
doi:10.1126/science.1254050

7. Green, M. A., K. Emery, Y. Hishikawa, W. Warta, and E. D. Dunlop, "Solar cell efficiency tables (version 45)," Prog. Photovoltaics Res. Appl., Vol. 23, 1-9, 2015.
doi:10.1002/pip.2573

8. Malinkiewicz, O., et al. "Perovskite solar cells employing organic charge-transport layers," Nature Photon., Vol. 8, 128-132, 2014.
doi:10.1038/nphoton.2013.341

9. Docampo, P., J. M. Ball, M. Darwich, G. E. Eperon, and H. J. Snaith, "Efficient organometal trihalide perovskite planar-heterojunction solar cells on flexible polymer substrates," Nature Commun., Vol. 4, 2761, 2013.
doi:10.1038/ncomms3761

10. Shah, A. V., et al. "Thin-film solar cell technology," Progr. Photovolt. Res. Appl., Vol. 12, 113-142, 2004.
doi:10.1002/pip.533

11. Yu, Z., A. Raman, and S. Fan, PNAS, Vol. 107, No. 41, 17491-17496, 2010, DOI: 10.1073/pnas.1008296107.

12. Tang, Z., W. Tress, and O. Inganäs, Mater Today, Vol. 17, No. 8, 389-396, 2014, DOI: 10.1016/j.mattod.2014.05.008.

13. Nelson, J., The Physics of Solar Cell, Imperial College Press, United Kingdom, London, 2008, DOI: 10.1142/p276.

14. Sathya, P. and R. Natarajan, Int. J. Energy Res., Vol. 41, 1211-1222, DOI: 10.1002/er.3708.

15. Shuba, M. V., et al. J. Opt. Soc. Am. A, Vol. 32, 1222-1230, 2015, DOI: 10.1364/JOSAA.32.001222.
doi:10.1364/JOSAA.32.001222

16. Gabriel, C., Optics And Optoelectronics, Vol. 19, 2021, DOI:10.15598/aeee.v19i2.4140.

17. Bhatnagar, A. and V. Janyani, IEEE International Conference on Computer, Communications and Electronics, 516-520, Jaipur, 2017.

18. Scholtz, L., L. Ladanyi, and J. Mullerova, Applied Physics, Vol. 12, 2014, DOI: 10.15598/aeee.v12i6.1078.

19. Abdelraouf, O. A. and N. K. Allam, Sol. Energy, Vol. 137, 364-370, 2016, https://doi.org/10.1016/j.solener.2016.08.039.
doi:10.1016/j.solener.2016.08.039

20. Abdelraouf, O. A., A. Shaker, and N. K. Allam, Opt. Mater., Vol. 86, 311-317, 2018, https://doi.org/10.1016/j.optmat.2018.10.028.
doi:10.1016/j.optmat.2018.10.028

21. Bendib, T., H. Bencherif, and M. A. Abdi, "Combined optical-electrical modeling of perovskite solar cell with an optimized design," Optical Materials, Vol. 109, 110259, 2020, doi.org/10.1016/j.optmat.2020.110259.
doi:10.1016/j.optmat.2020.110259

22. Hajjiah, A., H. Badran, and I. Kandas, Energies, Vol. 13, 3854, 2020, doi:10.3390/en13153854.
doi:10.3390/en13153854

23. Bhatnagar, A. and V. Janyani, Advanced Materials Letters, Vol. 9, No. 10, 721-726, 2018, DOI: 10.5185/amlett.2018.2108.

Dr. Maroua Chahmi

Dr. Mounir Bouras

Dr. Moufdi Hadjab

Dr. Mohammad Alam Saeed
