Search Results(14191)

2026-11-09
PIER Letters
Vol. 133, 6-14
A DGS Decoupling Method for PIFA Antennas Based on Common-Mode/Differential-Mode Analysis
Tao Yang and Yafei Wang
To address mutual coupling between antennas in MIMO antenna systems, this paper proposes a decoupling method for a MIMO PIFA using a defected ground structure (DGS) based on common-mode/differential-mode (CM/DM) theory. We use the CM/DM response relationship as an explicit design criterion to guide DGS structure evolution and the selection of critical geometric parameters. Simulation results show that the proposed PIFA MIMO antenna achieves more than 20 dB of port isolation over the 3.8-3.9 GHz band, with a peak isolation of 57 dB, while maintaining good impedance matching. Moreover, the measured results of the fabricated prototype agree well with the simulated results, further validating the effectiveness of the proposed method.
A DGS Decoupling Method for PIFA Antennas Based on Common-Mode/Differential-Mode Analysis
2026-11-09
PIER Letters
Vol. 133, 1-5
Displacement of the Field of a Current Source Located near a Layered Stack Composed of Single-Negative Layers
Leonid Pazynin , Kostyantyn Sirenko and Vadym Pazynin
A rigorous analytical solution is obtained for two-dimensional boundary value problems describing E-polarized fields of a current source located near two- and three-layer stacks composed of single-negative layers. Conditions for complete tunneling of the source field into the half-space behind the multilayer stacks are formulated. It is rigorously demonstrated that such structures exhibit the previously predicted effect of ideal image displacement.
Displacement of the Field of a Current Source Located near a Layered Stack Composed of Single-Negative Layers
2026-11-09
PIER B
Vol. 119, 33-46
Data Augmentation Strategies for Terahertz Spectral Material Classification: A Systematic Study on Model-Strategy Interaction
Zhangchong Ye , Lifeng Zhu , Luoyi Li , Jiangyang Zhan , Lei Zhang , Jie Cai , Jing Shen , Chong Tian , Xiaofeng Zhang and Xianliang Li
Small sample sizes in terahertz (THz) spectroscopy constrain the generalization of machine learning classifiers, motivating data augmentation as a low-cost remedy. However, researchers rarely evaluated the effectiveness of augmentation strategies across diverse classifier architectures. This study cross-evaluates five augmentation strategies (Gaussian noise injection, amplitude scaling, baseline drift, a combined version of the three perturbations, and intra-class Mixup interpolation) on a five-material THz insulating material dataset (129 spectra). Eleven classifiers spanning gradient boosting, bagging ensembles, sequential boosting, kernel methods, linear models, generative models, and neural networks were benchmarked under each augmentation strategy plus a no-augmentation baseline control, yielding 66 independent experiments (6 conditions × 11 models), with hyperparameters tuned via 5-fold stratified cross-validation. On the single fixed partition of the main experiment, the interaction appears large: Mixup improves multi-layer perceptron macro F1 by 83.7% (from 0.416 to 0.765) while AdaBoost degrades by 56.9% (from 0.743 to 0.321), and the best combination, Extra Trees with baseline drift, reaches macro F1 of 0.871. Because such effect sizes may depend on the partition drawn, every cell was reevaluated across 10 independent stratified splits with hyperparameters held fixed. Single-partition magnitudes prove substantially inflated, and the two extreme cases diverge: the MLP gain persists in direction but shrinks to +18.0% (paired ΔF1 = +0.099 ± 0.133), whereas the AdaBoost degradation does not reproduce (+0.064 ± 0.119, 5 of 10 splits negative), its apparent size traceable to a baseline of 0.743 that no repeated split recovered (mean 0.540). What survives is the family structure rather than the individual percentages: augmentation helps neural network (+0.110), kernel (+0.042), and bagging (+0.021 to +0.026) classifiers and harms linear-generative (-0.087) and generative (-0.034) ones. Baseline drift remains the most consistent strategy, its mean gain falling from 0.038 to 0.011. These findings demonstrate that augmentation strategy selection must be guided by classifier architecture, and that effect sizes from a single small-sample partition should be treated as upper bounds. The defensible framework is at the family level: augment neural network, kernel, and bagging classifiers, and avoid augmenting linear-generative and generative ones. Independent-dataset validation is required before generalizing these recommendations.
Data Augmentation Strategies for Terahertz Spectral Material Classification: A Systematic Study on Model-Strategy Interaction
2026-11-08
PIER Letters
Vol. 132, 72-79
A 180-GHz Chip Filter with Controllable Transmission Zeros Based on TGV Technology
Zhicheng Shen , Yi Wu , Yang Yu , Ming Yin , Zhanfeng Li , Haitao Zhang , Shixiong Liang and Kaixue Ma
This article proposes a 180-GHz substrate-integrated waveguide (SIW) bandpass filter based on through-glass-via (TGV) technology on a 30-μm-thick fused-silica substrate for high-selectivity filtering at sub-terahertz frequencies. We develop an asymmetric cascaded-quadruplet (CQ) coupling topology by adding a cavity-to-load electric-coupling path to the conventional CQ configuration. The additional coupling path provides an independent signal route and generates an extra transmission zero (TZ) through destructive interference with the main coupling path. We establish a coupling-matrix model to describe the proposed topology and clarify the formation and controllability of the TZs. The position of the additional TZ can be controlled by adjusting the dimensions of an S-shaped slot, while the coupling strength between the resonators can be tuned by corresponding geometric parameters Based on the proposed coupling configuration, a fourth-order SIW bandpass filter is designed and fabricated using TGVs with a diameter of 45 μm and a pitch of 75 μm. Furthermore, a half-mode SIW-like (HMSIW-like) configuration is introduced by removing a portion of the cavity and the corresponding TGVs to further reduce the circuit footprint while maintaining the fundamental resonant characteristics. Two prototypes are fabricated and experimentally characterized. The first filter has a measured center frequency of 180 GHz, a fractional bandwidth of 14%, and an insertion loss of 2.5 dB near the center frequency, and the second filter operates at 177 GHz with a fractional bandwidth of 15.8% and an insertion loss of 3 dB near the center frequency. The measured results demonstrate the feasibility of the proposed coupling configuration and the effectiveness of the HMSIW-like structure for compact sub-terahertz SIW filtering.
A 180-GHz Chip Filter with Controllable Transmission Zeros Based on TGV Technology
2026-11-07
PIER C
Vol. 174, 120-125
A Wide-Beamwidth ±45° Dual-Polarized Folded-Dipole Antenna for 5G Application
Yanzheng Chen and Naichang Pei
This paper proposes a novel wide-beamwidth ±45°, dual-polarization folded-dipole antenna for 5G applications. The design uses a folded dipole and an octagonal loop parasitic element to balance the reverse current on the dipole. At low frequencies, the antenna's radiation characteristics are determined by the inner loop of the folded dipoles, but at high frequencies, the outer loop dominates the radiation performance. The antenna operates in the 3.05-3.67 GHz frequency band with VSWR < 1.5 for both ports. At the operating frequencies, a gain of 8.4 ± 0.6 dBi and a port-to-port isolation of > 26 dB are achieved. Besides, the antenna has wide half-power beamwidths of about 90 degrees in the horizontal plane. An experimental prototype has been manufactured and measured. Experimental results are in good agreement with simulations.
A Wide-Beamwidth ±45° Dual-Polarized Folded-Dipole Antenna for 5G Application
2026-11-06
PIER C
Vol. 174, 110-119
Improved LSSVR Uncertainty Quantification Method Based on Hierarchical Dimension-Reduced Sparse Grid
Yujia Song , Jiming Qi , Jiasheng Wang , Yuantai Niu , Jinjun Bai and Shenghang Huo
Uncertainty quantification (UQ) is an important means of characterizing how input-parameter fluctuations affect electromagnetic responses, and it provides a theoretical basis for performance prediction, reliability evaluation, and robust optimization in computational electromagnetics. For high-cost full-wave electromagnetic simulations, the least-squares support vector regression (LSSVR) surrogate model can improve the efficiency of computational electromagnetics UQ within a reasonable accuracy range because of its small-sample learning and nonlinear fitting capabilities. However, the sampling strategy directly affects the accuracy of the surrogate model. Conventional Latin hypercube sampling (LHS) allocates sampling resources equally among all dimensions, which may waste computational resources in LSSVR-based UQ. The paper proposes an LSSVR surrogate-model-based UQ method incorporating a hierarchical dimensionality reduction sparse grid strategy (LSSVR-DRSG-H) to prioritize the allocation of computational resources to highly sensitive input parameters. Validation results from a case study on human head electromagnetic exposure demonstrate that, compared with the conventional LSSVR, which achieves an MEAM of 0.8391 using 100 full-wave simulations, the proposed LSSVR-DRSG-H attains a higher MEAM of 0.8530 with only 85 full-wave simulations.
Improved LSSVR Uncertainty Quantification Method Based on Hierarchical Dimension-Reduced Sparse Grid
2026-11-06
PIER C
Vol. 174, 99-109
SHAP-Based Explainable Machine Learning for Terahertz Material Classification and Sensor Design Guidance
Lifeng Zhu , Jing Shen , Lei Zhang , Yongbin Sun , Xiaofeng Zhang , Luoyi Li , Xianliang Li , Chong Tian , Zhangchong Ye , Jie Cai , Qingqing Ge and Jiangyang Zhan
The black-box nature of machine learning (ML) models limits their adoption in industrial terahertz (THz) inspection systems where decision transparency is mandatory. We present a SHAP-based explainability framework for THz classification of five insulating materials using a 636-dimensional feature set (625 spectral channels plus 11 morphological descriptors) benchmarked across 11 classifiers. LightGBM achieved the highest performance (Macro F1 = 86.84%, Accuracy = 87.18%) and was selected for in-depth SHAP analysis and four validation experiments. SHAP-guided feature selection showed that 50 features (7.9% of the space) already match the full baseline and are the smallest tested subset that does so. Cross-model analysis showed Gradient_Std to be the single highest-ranked SHAP feature for LightGBM, XGBoost, and Random Forest alike, confirming its discriminative role to be a property of the data rather than of a single learner. Four SHAP-identified spectral windows (113 channels, 18.1%) combined with morphological features retained 95.7% of full-spectrum performance (F1 = 83.07%). A noise robustness sweep from 60 dB to 5 dB SNR, assessed against an explicit reliability criterion (Macro F1≥95% of each subset's own noise-free value), places the minimum usable SNR at 30 dB for the full feature set, shows that the morphological descriptors degrade first (falling below their criterion at 50 dB when used alone), and supports a 40 dB design margin. Engineered morphological descriptors contributed 39.8× more per feature than raw spectral channels. These results provide actionable guidance for compact narrowband sensor design and edge deployment in industrial insulation inspection.
SHAP-Based Explainable Machine Learning for Terahertz Material Classification and Sensor Design Guidance
2026-11-06
PIER M
Vol. 141, 53-64
Lower Band-Edge Frequency Prediction for UWB Antennas via Knowledge-Based Artificial Neural Network
Zekun Zhang , Zihan Xu , Shuling Yin , Xia Cao and Bing Yang
To improve prediction accuracy for lower band-edge frequencies of ultra-wideband (UWB) printed monopole antennas, we propose a knowledge-based artificial neural network (KBANN) method. This approach uses antenna geometric parameters as inputs and introduces the lower band-edge frequency calculated from empirical formulas as prior knowledge into the neural network, integrating electromagnetic knowledge with machine learning. We construct a simulation dataset by performing electromagnetic simulations on antennas with various shapes and feed locations for model training and evaluation. Experimental comparisons show that the proposed knowledge-based artificial neural network achieves higher prediction accuracy and faster convergence than the empirical formula and data-driven models without prior knowledge, while maintaining lower prediction errors under limited-data conditions. Shapley additive explanation (SHAP) analysis further shows that prior knowledge contributes to the model predictions with the dominant antenna geometric parameters. The proposed method provides an efficient approach for lower band-edge frequency prediction of ultra-wideband antennas.
Lower Band-Edge Frequency Prediction for UWB Antennas via Knowledge-Based Artificial Neural Network
2026-11-05
PIER C
Vol. 174, 91-98
Prediction of Dynamic Electromagnetic Interference for Navigation Receiver of UAV
Ceyi Ma , Wei Shang , Ke Li and Meng Li
To effectively improve the dynamic prediction efficiency of external interference coupling at the airborne antenna end of the quadrotor unmanned aerial vehicle (UAV), and realize the dynamic analysis of electromagnetic interference (EMI) of the quadrotor UAV, we proposed a novel two-dimensional dynamic electromagnetic interference (2D-DEMI) prediction method based on bi-cubic interpolation. By using bicubic interpolation to restore the interference-coupling voltage at the antenna end, the number of samples can be reduced effectively, and prediction can be accelerated. Then, the coupling-voltage database at the antenna end is established by predicting the results. Finally, we evaluated the effectiveness and accuracy of the proposed method through experiments. The results show that the CPU time can be reduced by more than 80% using bi-cubic interpolation algorithm. According to the measured results, the prediction root mean squared error (RMSE) of dynamic electromagnetic interference is just 1.6. The results indicate that the proposed method can rapidly predict the dynamic electromagnetic interference of the quadrotor UAV.
Prediction of Dynamic Electromagnetic Interference for Navigation Receiver of UAV
2026-11-05
PIER M
Vol. 141, 43-52
Study of Lightning-Induced Electromagnetic Interference on Sagging Conductors Above Rough Ground
Keyi Bai and Wei Tian
Lightning pulses are characterized by a wide coverage range, short duration, and high intensity. They can induce transient electromagnetic interference (EMI) on sagging high-voltage lines above the ground, posing a serious threat to the secure operation of power systems. In this paper, a random rough ground surface is simulated using the Monte Carlo method. The catenary function is employed to model the geometry of sagging high-voltage lines. The time-domain waveform of the lightning pulse is obtained based on the discharge current of a multi-component lightning cloud-to-ground stroke. The transient induced currents and power responses of three-phase transmission lines and connected loads under lightning excitation are numerically calculated. The effects of rough surfaces with different root-mean-square heights and tower heights configurations on electromagnetic interference characteristics are investigated. The broadband lightning interference characteristics are comprehensively obtained, providing a theoretical basis for the electromagnetic protection design of transmission lines above practical ground surfaces.
Study of Lightning-Induced Electromagnetic Interference on Sagging Conductors Above Rough Ground
2026-11-05
PIER Letters
Vol. 132, 63-71
High-Efficiency Hybrid Continuous Mode Power Amplifier Based on Power-Dependent Input Nonlinearity
Pingfan Xu , Chuicai Rong , Fubing Ding , Mingxuan Guo , Baoli Chen , Ziye Zheng , Hongxin Ma and Yunpei Feng
This study proposes an input-output waveform-synthesis method for high-efficiency power amplifiers (PAs) operating at multiple power levels. A power-dependent complex input-nonlinearity factor captures gate-voltage distortion caused by the nonlinear gate-source capacitance, linking input second-harmonic impedance to conduction interval and drain-current harmonics. The theoretical high-efficiency load-impedance regions are derived from the prescribed waveforms at selected input-power levels within 27-30 dBm. Their intersection defines common impedance targets for synthesizing a fixed harmonic-control network. To validate the proposed method, this work designs and fabricates a hybrid continuous mode (HCM) power amplifier centered at 3.5 GHz. Under continuous-wave (CW) excitation at 3.5 GHz, the power amplifier achieves a drain efficiency (DE) of 78.2%, a power-added efficiency (PAE) of 72.2%, an output power of 40.1 dBm, and a gain of 11.1 dB. Over 3.35-3.65 GHz, the measured DE ranges from 68.8% to 78.2%.
High-Efficiency Hybrid Continuous Mode Power Amplifier Based on Power-Dependent Input Nonlinearity
2026-11-04
PIER Letters
Vol. 132, 54-62
High-Isolation Four-Port Circularly Polarized MIMO Antenna Using a Metasurface Ground Plane
Jingchang Nan , Fengjun Liang and Shuming Liu
The proposed CP antenna element employs a microstrip feed and a 45° rectangular slot to excite two orthogonal modes with an approximately 90° phase difference, realizing circular polarization. Based on this element, a four-port CP MIMO antenna is constructed, and a 5 × 5 metasurface array (M-array) is integrated into the ground plane to suppress mutual coupling between adjacent antenna elements. The introduced M-array provides additional electromagnetic-wave control paths and suppresses surface-wave propagation between adjacent antenna elements, reducing mutual coupling and improving the radiation performance of the CP MIMO antenna. At 10.8 GHz, the dimensions of the CP MIMO antenna are 32 mm × 32 mm × 1.6 mm. Simulated results show that the CP MIMO antenna with the M-array offers a frequency range of 20.6% (10.5 to 12.7 GHz), an inter-port isolation exceeding 40 dB with a peak value of approximately 64 dB, a 4.7% overlapping 3 dB axial ratio bandwidth from 10.5 to 11 GHz, and a high gain of 9.75 dBi. Diversity metrics ensure good diversity performance, including an envelope correlation coefficient (ECC) below 0.001, a diversity gain (DG) of approximately 10 dB, a channel capacity loss (CCL) below 0.2 bits/Hz, and a total active reflection coefficient (TARC) below -10 dB. The proposed CP MIMO antenna operates over the 10.5-12.7 GHz frequency range, which spans the upper portion of the X-band and the lower portion of the Ku-band. The measured results show good agreement with the simulated ones, validating the proposed CP MIMO antenna for radar applications.
High-Isolation Four-Port Circularly Polarized MIMO Antenna Using a Metasurface Ground Plane
2026-11-03
PIER C
Vol. 174, 82-90
Design and Implementation of a Compact UWB Filtenna Using a Feed-Line-Integrated Resonator for Mitigating WLAN Interference at 5.8 GHz
Esraa M. Majeed and Ahmed M. A. Sabaawi
This paper presents the design and optimization of a wideband filtering antenna (filtenna) for UWB applications. The design combines a wideband antenna and a feed-line-mounted band-stop filter (BSF) to suppress Wi-Fi (5-6 GHz) interference while keeping the design compact and simple. This antenna is built on a 32 × 32 mm2 FR4 substrate with a partial ground plane and is embedded with a circular ring resonator in the feed line to obtain the desired rejection characteristics. The antenna was designed and simulated using CST Studio Suite. The outcome revealed that the designed filtenna has a wide operating range of 2.78-11.79 GHz with a targeted rejection band around 5-6 GHz. deep resonances are observed at 3.35 GHz and 7.40 GHz, with reflection coefficient of -23.85 dB and -55.14 dB, respectively indicating good impedance matching outside the rejected band. The filtenna was fabricated and experimentally characterized in terms of S11, showing the intended band-rejection behavior with some differences between the simulated and measured response. A parametric study of the ring dimensions shows how the position and bandwidth of the rejection band can be tuned while the UWB response outside the notch is preserved. The filtenna was fabricated, and its measured S11 confirms the band-rejection behavior, with some differences from the simulated response. The results show that a compact feed-line ring resonator is a simple way to introduce WLAN rejection into a UWB antenna, making the design a candidate for sub-6 GHz and IoT applications.
Design and Implementation of a Compact UWB Filtenna Using a Feed-Line-Integrated Resonator for Mitigating WLAN Interference at 5.8 GHz
2026-11-03
PIER C
Vol. 174, 71-81
Photovoltaic Output Power Prediction Based on Thermoelectric Coupling Digital Twin Model of Inverter
Juanjuan Zhang and Xiaoyan Jiang
Accurate photovoltaic (PV) power forecasting requires both meteorological information and a representation of inverter operating states. This study develops a physics-informed DT-LSTM framework in which a reduced-order thermoelectric digital twin converts measured PV power, ambient temperature, wind speed, and irradiance into estimated loss power, thermal load, equivalent temperature, and temperature rise. Field power and weather records from January to June 2024 are aligned causally and divided chronologically into training (January 1-April 15), validation (April 16-30), main testing (May), and external testing (June) periods. At a 5 min resolution over the extended 07:00-22:00 window, DT-LSTM achieves MAE/RMSE values of 65.90/132.12 kW in the main test and 67.07/124.52 kW in the external test, compared with 72.57/137.77 kW and 73.10/130.12 kW for LSTM. The estimated thermal states are model-derived variables rather than measured device temperatures; accordingly, the results demonstrate forecasting utility and physical consistency, not direct temperature-field validation. The study provides a physics-informed virtual-sensing forecasting framework and identifies controlled multi-seed ablation and measured thermal validation as future work.
Photovoltaic Output Power Prediction Based on Thermoelectric Coupling Digital Twin Model of Inverter
2026-11-03
PIER M
Vol. 141, 34-42
NS-FDTD Modeling of Electromagnetic Wave Propagation in High-Loss Metallic Composites for Large-Scale Negative Medium Parameter Structures
Sikha Kolamkanny Simon , Nees Paul , Joe Kizhakooden , Bindu Cherala , Jolly Andrews , Vallikkavumkal Paily Joseph and Jovia Jose
The highly accurate and computationally advantageous nonstandard finite difference time domain (NS-FDTD) method is extensively used to study wave propagation through low-loss media. While applying this method in high-loss cases like metals, it is found that the algorithm fails to converge properly. In the present study, we address these convergence-related issues by analyzing the stability function for a fixed discretization of the computational domain. This novel approach to the NS-FDTD method is verified by exposing a metallic reflector slab to an incident sinusoidal electromagnetic wave, and the results are compared with those of the S-FDTD method. This approach provided a well-defined field distribution at a much lower discretization than that of the S-FDTD algorithm, giving a great advantage of much reduction in computational cost. Hence, this method finds application in simulating, accurately and precisely, composite high-loss media, including trending negative medium parameter structures like metamaterials.
NS-FDTD Modeling of Electromagnetic Wave Propagation in High-Loss Metallic Composites for Large-Scale Negative Medium Parameter Structures
2026-11-03
PIER B
Vol. 119, 19-32
TMCFNet: Triple-Stage Mamba Cross-Modal Fusion Network for Visible-Infrared Remote Sensing Object Detection
Cheng Zhang , Xiao-Zhen Ren , Xiaqiong Fan , Zhipeng Guo and Gang Liu
Unimodal remote-sensing data is susceptible to interference such as illumination changes and texture loss. Visible and infrared images have respective limitations in object detection, which multimodal fusion can address. To address these challenges, this study proposes a Triple-stage Mamba Cross-modal Fusion Network (TMCFNet) for cross-modal remote-sensing object detection. The model performs cross-modal image fusion at the input stage to preserve each modality's inherent information while keeping computational cost low. It consists of three key components: the Adaptive Multi-scale Convolution Module (AMC), Cross-Modal Shared Mamba Interaction Module (SMIM), and Dual-Global Pooling Enhanced Multimodal Feature Fusion Module (G2MFF). They are responsible for unimodal feature enhancement, cross-modal information alignment, and in-depth feature fusion, which effectively improve the model's detection accuracy and generalization ability in complex scenarios. To comprehensively evaluate the model performance, we conducted experiments on multiple public real-world multimodal datasets and dedicated remote sensing datasets. Compared with state-of-the-art unimodal and multimodal detection methods, the proposed model achieved mean average precision mAP@0.5:0.95 values of 58.5% and 69.0% on the DroneVehicle and LLVIP datasets, respectively. Results demonstrate that deep multimodal feature fusion can remarkably boost object detection performance in complex environments.
TMCFNet: Triple-Stage Mamba Cross-Modal Fusion Network for Visible-Infrared Remote Sensing Object Detection
2026-11-01
PIER C
Vol. 174, 62-70
FSS-Enabled Modified Bow-Tie Antenna Design for High-Gain, Low-SAR Applications
Kesavalu Naidu Keerthi Naidu and Selvaraj Imaculate Rosaline
This work presents a modified, wide-band, bow-tie antenna integrated with a Frequency Selective Surface (FSS) designed to enhance gain and significantly reduce the Specific Absorption Rate (SAR). The proposed antenna, with a compact profile of 0.47λg × 0.77λg, operates at a center frequency of 2.4 GHz and exhibits a high radiation efficiency. By employing a flared polygonal radiating element, the antenna achieves wide-band performance across an operational spectrum of 1.97 GHz to 3.09 GHz, yielding a fractional bandwidth of 46.7%. An FSS array, functioning as a spatial filter, was designed and positioned 39 mm from the antenna, thereby forming an integrated system. Through numerical simulations, this system shows the gain improvement of the antenna from 2.51 dBi to 6.5 dBi and simultaneously reduces the SAR from 3.9 W/kg to 1.6 W/kg per 10 g of tissue, falling well below the permitted safety limit. The antenna and FSS array prototypes were fabricated and tested for scattering parameters, gain improvement, and radiation pattern. The measured results were in close alignment with the simulations, demonstrating the efficiency of the antenna for safe and high-performance off-body biomedical applications.
FSS-Enabled Modified Bow-Tie Antenna Design for High-Gain, Low-SAR Applications
2026-11-01
PIER C
Vol. 174, 49-61
Online Adaptive Vibration Compensation Control for an Inverter-Driven Six-Pole Active Magnetic Bearing Based on a Fuzzy-Optimized RDC-HWCLMS Algorithm
Zhihao Ma , Yichen Liu and Huangqiu Zhu
To address the inherent trade-off between convergence speed and steady-state error in conventional least mean square (LMS) algorithms for inverter-driven six-pole active magnetic bearings (AMBs), this paper proposes an online adaptive vibration compensation control strategy. In this strategy, a fuzzy-optimized Rayleigh-distribution-curve hybrid-weighted coefficient LMS (RDC-HWCLMS) algorithm is integrated with the influence coefficient method (ICM). First, the rotor unbalance dynamic model is derived, and the LMS-based synchronous vibration extraction principle is analyzed. Second, a Rayleigh-based variable-step-size law is constructed to improve transient convergence, and a hybrid-weighted coefficient update is introduced to suppress steady-state weight fluctuations under noisy displacement measurements. Furthermore, a fuzzy inference system (FIS) is introduced to enhance self-adaptability by dynamically tuning the step-size scaling parameter according to real-time error states. The extracted synchronous vibration components are then used by the ICM to generate compensation current references, which are injected into the AMB control system through the three-phase inverter. Finally, comparative simulated and experimental results on a 4-DOF inverter-driven six-pole AMB platform verify that the proposed online adaptive compensation control method achieves faster convergence, lower residual vibration, and stronger dynamic tracking adaptability than conventional LMS algorithms.
Online Adaptive Vibration Compensation Control for an Inverter-Driven Six-Pole Active Magnetic Bearing Based on a Fuzzy-Optimized RDC-HWCLMS Algorithm
2026-10-30
PIER C
Vol. 174, 42-48
Study on the Effect of Magnetic Field on the Performance of a 5 kW Hall Thruster under High Discharge Voltage
Le Yang , Na Hui , Guoheng Zhang , Ling Guo and Peiyu Wang
This paper studies the changes in plasma discharge characteristics and thruster performance using a two-dimensional PIC-MCC model and performance testing experiments when adjusting the magnetic field configuration in the discharge channel through an additional excitation coil at a propellant flow rate of 5 mg/s and a discharge voltage range of 300-1000 V. The research results indicate that optimizing the magnetic field configuration in the discharge channel can improve the performance of the thruster under high discharge voltage, especially in the discharge voltage range of 600--1000\,V. The simulation results of plasma characteristics show that by adjusting the magnetic field configuration, the ion ionization efficiency can be improved; the wall loss of ions can be reduced; and the acceleration and focusing of ions can be improved. The simulation and experiments results of the thruster performance show that adjusting the magnetic field configuration can improve the efficiency of the thruster, avoid the decrease in thruster efficiency when the discharge voltage increases, and ensure high efficiency while achieving high specific impulse.
Study on the Effect of Magnetic Field on the Performance of a 5 kW Hall Thruster under High Discharge Voltage
2026-10-30
PIER C
Vol. 174, 34-41
A Recursive Semi-Circular Fractal Patch Antenna with Alternating Conductive-Void Arc Topology for UWB Applications
Irsal Djeroud , Habib Khouni , Muhammad Inam Abbasi and Maizatul Alice Meor Said
This study proposes a printed ultra-wideband (UWB) antenna based on a recursive semi-circular fractal topology. The radiating element is generated via the hierarchical decomposition of a primary semi-circular structure into self-similar conductive and void arc segments. This alternating conductive-void arrangement lengthens the effective current path and excites several closely spaced resonant modes that merge into a single continuous band. The antenna is printed on a Rogers RT/duroid 5880 substrate with a thickness of 0.508 mm, characterized by a relative permittivity of εeff = 2.2 and a loss tangent of tanδ = 0.0009, and excited by a 50-Ω microstrip feed line over a notched partial ground plane. Occupying 28 × 30 × 0.508 mm3, corresponding to 0.287λ0 × 0.307λ0 × 0.0052λ0. The design achieves a simulated impedance bandwidth from 3.07 to 13.92 GHz (128% fractional bandwidth), and the measured impedance bandwidth extends from 3.03 to 14.05 GHz (129% fractional bandwidth). The simulated peak realized gain is 5.2 dBi, and the measured peak gain reaches 4.97 dBi. Simulated radiation efficiency above 93.8% across the entire operating band was obtained, and it reaches approximately 98.2% around 8 GHz. The measured radiation patterns show good agreement with simulated results at the investigated frequencies. The experimental validation of the proposed antenna with its thin, low-loss profile supports its potential use in diverse UWB wireless applications and sensing systems.
A Recursive Semi-Circular Fractal Patch Antenna with Alternating Conductive-Void Arc Topology for UWB Applications
