A Compact Ultra-Wide Band Antenna with a Notched Band for Wireless Communication Systems
By
Progress In Electromagnetics Research Letters, Vol. 108, 31-39, 2023
Abstract
An ultra-wide band (UWB) antenna with C-band and X-band notches for wireless communication is presented. The designed structure is printed on a material of ``Rogers 4350B'' with εr = 3.66, tanδ = 0.0037 and a thickness of 0.508 mm. This structure is designed to operate at a UWB range starting from 3.3 GHz up to 10.15 GHz with a stopband range from 6.75 GHz to 8.5 GHz. The rejected bands are the upper C-band (6.75 GHz-8 GHz) and the uplink X-band of the satellite (space to earth) from 7.25 GHz to 7.75 GHz. The overall antenna size is optimized, and its dimensions are 21 × 30 × 0.508 mm3. The antenna gain varies from 2.1 to 4.2 dBi at the passband, and its total radiation efficiency is 96.4%. The suggested structure is designed and simulated using CSTMWS software. Moreover, a prototype of the proposed structure is fabricated and measured. The fabrication process was done using photolithography techniques, and the measurements were done using an R&S vector network analyzer. Good agreement is achieved between the simulated and measured results.
Citation
Basma M. Yousef, Allam M. Ameen, Bassant H. El Swiefy, and Reham Arnous, "A Compact Ultra-Wide Band Antenna with a Notched Band for Wireless Communication Systems," Progress In Electromagnetics Research Letters, Vol. 108, 31-39, 2023.
doi:10.2528/PIERL22101503
References

1. Kaur, K., A. Kumar, and N. Sharma, "A review of ultra wideband antennas with band notched characteristics," Proceedings of the International Conference on Innovative Computing & Communications (ICICC), March 2020.

2. Mullick, T. U., M. E. Ershad, M. A. Matin, and A. Rahman, "Design of UWB antenna with a band-notch at 5 GHz," Loughborough Antennas & Propagation Conference (LAPC), 1-4, 2012.

3. Liu, H., C. Ku, T. Wang, and C. Yang, "Compact monopole antenna with band-notched characteristic for UWB applications," IEEE Antennas and Wireless Propagation Letters, Vol. 9, 397-400, 2010.
doi:10.1109/LAWP.2010.2049633

4. Madany, Y. M., A. I. Almahallawy, and H. M. Elkamchouchi, "Methodology of band rejection/addition for microstrip antennas design using slot line theory and current distribution analysis," 2014 Loughborough Antennas and Propagation Conference (LAPC), 602-606, IEEE, 2014.
doi:10.1109/LAPC.2014.6996464

5. Goyal, P., "UWB antenna with dual notch functionality for reducing VSWR," Journal of Adv Research in Dynamical & Control Systems, Vol. 12, No. 3, 91-96, 2020.
doi:10.5373/JARDCS/V12I3/20201170

6. Moradi, N., F. Nazari, H. Aliakbarian, and F. A. Namin, "Compact ultrawideband monopole antenna with continuously tunable notch band characteristics," Progress In Electromagnetics Research C, Vol. 118, 71-81, 2022.
doi:10.2528/PIERC21120207

7. Wang, X. and Y. Sun, "Ultra-wideband MIMO antenna with double notched band," Cross Strait Radio Science & Wireless Technology Conference (CSRSWTC), 1-3, 2020.

8. Alotaibi, S. and A. Alotaibi, "Design of a planar tri-band notch UWB antenna for X-band, WLAN, and WiMAX engineering," Technology & Applied Science Research, Vol. 10, 6557-6562, 2020.
doi:10.48084/etasr.3904

9. Rashid, M. A., S. M. Shah, H. Majid, A. Ponniran, and F. Hassan, "A highly miniaturized ultra-wideband antenna with a triple-band notch for wearable applications," International Journal of Electrical and Electronic Engineering & Telecommunications, 74-81, 2022.
doi:10.18178/ijeetc.11.1.74-81

10. Khan, M., "Design and analysis of a compact UWB band notch antenna for wireless communication," Engineering Proceedings, Vol. 3, 2020.

11. Karanam, P., A. Tejasri, K. Sandeep, U. Kumar, and G. Swarupa, "Design of UWB antenna with WLAN & X-band notch for wireless communication," Design of UWB antenna with WLAN & X-band notch for wireless communication, Vol. 7, 484-488, 2018.
