Abstract

This work presents a unified analytical and full-wave investigation of the monostatic radar cross section (RCS) of trihedral corner reflectors (TCRs) and their arrays, covering both metallic and dielectric configurations. Accurate analytical prediction of the monostatic RCS of trihedral corner reflector arrays (TCRAs), particularly for tightly packed mosaic geometries and dielectric materials, remains challenging due to the lack of general closed-form models accounting for multiple reflector orientations and array effects. To address this gap, closed-form RCS expressions are derived for single reflectors and mosaic arrays incorporating two distinct reflector orientations. The proposed formulation extends classical geometrical-optics models through a corrected complex-target phase treatment and explicit inclusion of multi-orientation effects. The analytical results are validated using full-wave finite-element simulations in COMSOL Multiphysics®. For metallic reflectors, geometrical optics is shown to be accurate for electrically large elements, whereas diffraction, resonance, and phase-distortion effects emerge as the reflector size decreases. Dielectric TCRAs exhibit strongly non-symmetrical scattering and reversed boresight offsets in the φ = π/2 plane; nevertheless, grating-lobe locations remain predictable using the metal-array analytical model. The study concludes with practical design guidelines for mosaic TCRAs, including peak-RCS scaling, grating-lobe placement, and the transition from corner-reflector to plate-like scattering.

1. Hockel, Heidi, Ricardo F. Martins, Jinwon Sung, and Eric G. Johnson, "Design and fabrication of trihedral corner-cube arrays using analog exposure based on phase masks," Proc. SPIE 5720, Micromachining Technology for Micro-Optics and Nano-Optics III, Vol. 5720, 78-85, San Jose, California, USA, 2005.
doi:10.1117/12.591996

2. Brinksmeier, E., R. Gläbe, and C. Flucke, "Manufacturing of molds for replication of micro cube corner retroreflectors," Production Engineering, Vol. 2, No. 1, 33-38, 2008.
doi:10.1007/s11740-008-0082-8 Google Scholar

3. Gao, Jiashun, Yu Lei, and Zhilong Xu, "Research on micro-triangular pyramid array-based fly-cutting technology using the orthogonal test method," Coatings, Vol. 14, No. 7, 806, 2024.
doi:10.3390/coatings14070806 Google Scholar

4. Wu, Lingang, Jianghu Xu, Shengliang Hu, and Zhong Liu, "High-frequency backscattering properties of quasi-omnidirectional corner reflector: The great-icosahedral-like reflector," AIP Advances, Vol. 12, No. 10, 105225, 2022.
doi:10.1063/5.0123981 Google Scholar

5. Wu, Lingang, Shengliang Hu, Jianghu Xu, and Zhong Liu, "Dynamic sequential radar cross section properties of airborne corner reflector in array," IET Radar, Sonar & Navigation, Vol. 17, No. 9, 1405-1419, 2023.
doi:10.1049/rsn2.12429 Google Scholar

6. He, Yaomin, Huafeng He, Changhua Hu, Junjun Yin, and Jian Yang, "Polarization analysis of trihedral corner reflector with high-frequency approximation," IEEE Transactions on Antennas and Propagation, Vol. 70, No. 10, 9607-9620, 2022.
doi:10.1109/tap.2022.3177536 Google Scholar

7. Gou, Yuewen, Yikai Chen, and Shiwen Yang, "Radar cross section reduction of wideband Vivaldi antenna arrays with array-level scattering cancellation," IEEE Transactions on Antennas and Propagation, Vol. 70, No. 8, 6740-6750, 2022.
doi:10.1109/tap.2022.3162082 Google Scholar

8. Groot, Jos, "Letter: Cross section computation of trihedral corner reflectors with the geometrical optics approximation," European Transactions on Telecommunications, Vol. 3, No. 6, 637-642, 1992.
doi:10.1002/ett.4460030618 Google Scholar

9. Buchberger, Christian, Florian Pfeiffer, and Erwin Biebl, "Dielectric corner reflectors for mmWave applications," Advances in Radio Science, Vol. 17, 197-203, 2019.
doi:10.5194/ars-17-197-2019 Google Scholar

10. Skolnik, M. I., Introduction to Radar Systems, 2nd Ed., McGraw-Hill, New York, 1980.

11. Shyfryn, Y. S., Antenny [Antennas], VYRTA im. L. A. Hovorova, Kharkov, Ukraine, 1976.

12. Balanis, C. A., Antenna Theory: Analysis and Design, 3rd Ed., Wiley, Hoboken, NJ, USA, 2005.

13. Doerry, A. W. and B. C. Brock, "Radar cross section of triangular trihedral reflector with extended bottom plate," Sandia Report, Sandia National Laboratory, 2009.

14. Ruck, G. T., Radar Cross Section Handbook, Plenum Press, New York, NY, USA, 1970.

15. Sarabandi, K. and Tsen-Chieh Chiu, "Optimum corner reflectors for calibration of imaging radars," IEEE Transactions on Antennas and Propagation, Vol. 44, No. 10, 1348-1361, 1996.
doi:10.1109/8.537329 Google Scholar

16. Crispin, J. W. and K. M. Siegel, Methods of Radar Cross-Section Analysis, Academic Press, New York, NY, USA, 1968.

17. Korn, G. A. and T. M. Korn, Mathematical Handbook for Scientists and Engineers, Dover/Courier, Mineola, NY, USA, 2000.

18. Skolnik, Merrill I., Radar Handbook, 3rd Ed., McGraw Hill, New York, NY, USA, 2008.

19. Weng, Yin-Kan, Song Li, Jin-Ling Yang, Hui Zhou, Hong Yi, and Hong Wang, "Efficient solution to the RCS of trihedral corner reflector," International Journal of Applied Electromagnetics and Mechanics, Vol. 47, No. 2, 533-539, 2015.
doi:10.3233/jae-130156 Google Scholar

20. Yokoyama, Tomoki, Tomohiro Asami, Kazuyoshi Mori, and Akio Hasegawa, "Radiation characteristics of hexagonal transducer array," Japanese Journal of Applied Physics, Vol. 44, No. 6S, 4702, Jun. 2005.
doi:10.1143/jjap.44.4702 Google Scholar

21. COMSOL Multiphysics® "Comsol multiphysics v. 6.4," https://www.comsol.com, cOMSOL AB, Stockholm, Sweden, 2025.

22. Knott, E. F., Radar Cross Section Measurements, Springer, New York, NY, USA, 2012.
