A Low-Profile and Low-Cost Dual Circularly Polarized Patch Antenna
By
Progress In Electromagnetics Research Letters, Vol. 107, 67-74, 2022
Abstract
This paper presents a low profile and low-cost patch antenna with dual circularly polarized (CP) capability in X-band at a canter frequency of 8.3 GHz. The dual-CP antenna is divided into three layers, composed of a parasitic square patch, radiation square patch with four equal arms, and 90˚ patch coupler. Two arms of the radiation patch are connected to the 90˚ hybrid coupler using two metalized vias. right-handed circular polarization (RHCP) and Left-handed circular polarization (LHCP) is achieved by exciting two different ports. To validate the proposed design, the prototype of dual-CP antenna is fabricated and measured. Based on the measurement, the structure of proposed antenna has an excellent circular-polarization purity of less than 3-dB over the whole operational frequency bandwidth of the antenna (8 GHz-8.47 GHz) with a wide 3-dB axial ratio (AR) beamwidth of 133˚ across the angular range from -55° to +78° at 8.3 GHz.
Citation
Zahra Mousavirazi, Hassan Naseri, Mohamed Mamdouh M. Ali, Pejman Rezaei, and Tayeb Denidni, "A Low-Profile and Low-Cost Dual Circularly Polarized Patch Antenna," Progress In Electromagnetics Research Letters, Vol. 107, 67-74, 2022.
doi:10.2528/PIERL22070603
