Abstract

In this paper, a miniaturized millimeter-wave (mm-wave) antipodal Vivaldi antenna (AVA) is proposed. The AVA structure is modeled using MWSCST2022 optimization tools. The AVA exhibits good impedance matching, high gain, and a small optimum size of 5x2.5x1.5 mm³, fabricated on an FR-4 substrate. An array of square and circular director units is modeled and loaded at the front and back of the AVA. The spacing between directors is studied and positioned at a tuned distance from the antenna for gain improvements and optimum radiation parameters. The AVA has an operating spectrum from 58 GHz up to 62 GHz. The finalized AVA, along with directors, obtained a high gain of 12.9 dBi with directors, while the AVA achieved 9.22 dBi without directors. The proposed antenna model is simulated and measured for short-range communications and imaging. The results of the modeling techniques and measurements agree well with each other.

1. Koga, Yohei and Manabu Kai, "A transparent double folded loop antenna for IoT applications," 2018 IEEE-APS Topical Conference on Antennas and Propagation in Wireless Communications (APWC), 762-765, Cartagena, Colombia, Sep. 2018.

2. Hu, Ruiyue, Feng Zhang, Shengbo Ye, and Guangyou Fang, "Ultra-wideband and high-gain Vivaldi antenna with artificial electromagnetic materials," Micromachines, Vol. 14, No. 7, 1329, 2023. Google Scholar

3. Ding, Manlai, Xuemei Wang, Yinshen Wang, Zhiwei Hu, Gang Liu, Ziyan Liu, and Bingnan Wang, "A high gain Vivaldi antenna with multiple near-field dielectric lenses and grooved edges," International Journal of RF and Microwave Computer-Aided Engineering, Vol. 2023, Article ID 2405200, 2023. Google Scholar

4. Cheng, Houyuan, Helin Yang, Jiong Wu, Yujun Li, Yang Fu, Aidong Zhang, and Jing Jin, "Leaky-Vivaldi antenna covered with metasurface with leaky wave radiation and aperture radiation," Optics Express, Vol. 31, No. 11, 17291-17303, 2023. Google Scholar

5. Ghaffar, Farhan A., Noben K. Roy, and Atif Shamim, "A single layer wideband Vivaldi antenna with a novel feed structure," IET Microwaves, Antennas & Propagation, Vol. 17, No. 7, 558-564, 2023. Google Scholar

6. Rohaninezhad, Mohammadreza, Meysam Jalali Asadabadi, Changiz Ghobadi, and Javad Nourinia, "Design and fabrication of a super-wideband transparent antenna implanted on a solar cell substrate," Scientific Reports, Vol. 13, No. 1, 9977, 2023. Google Scholar

7. Nasir, Muhammad, Adnan Iftikhar, Muhammad Farhan Shafique, Birsen Saka, Symeon Nikolaou, and Dimitris E. Anagnostou, "Broadband dual‐podal multilayer Vivaldi antenna array for remote sensing applications," IET Microwaves, Antennas & Propagation, Vol. 17, No. 7, 505-517, 2023. Google Scholar

8. Azari, Abolfazl, Anja Skrivervik, Hadi Aliakbarian, and Ramezan Ali Sadeghzadeh, "A super wideband dual-polarized Vivaldi antenna for 5G mmWave applications," IEEE Access, Vol. 11, 80761-80768, 2023. Google Scholar

9. Ibrahim, Ahmed A. and Shaymaa M. Gaber, "Frequency reconfigurable antipodal Vivaldi 2-port antenna based on graphene for terahertz communications," Optical and Quantum Electronics, Vol. 55, No. 9, 786, 2023. Google Scholar

10. Özmen, Hüseyin and M. Bahaddin Kurt, "A novel gain enhanced Vivaldi antenna for a breast phantom measurement system," Electromagnetics, Vol. 43, No. 1, 24-36, 2023.
doi:10.1080/02726343.2023.2177394 Google Scholar

11. Yu, Xiaoyan, Jianxing Li, Jianping Hu, Yuan Yao, Jianwu Li, and Sen Yan, "Low-profile dual-polarized antenna integrated with horn and Vivaldi antenna in millimeter-wave band," Applied Sciences, Vol. 13, No. 17, 9627, 2023. Google Scholar

12. Jaiswal, Pawan Kumar, Rajarshi Bhattacharya, and Amit Kumar, "A UWB antipodal Vivaldi antenna with high gain using metasurface and notches," AEU - International Journal of Electronics and Communications, Vol. 159, 154473, 2023. Google Scholar

13. Tangwachirapan, Shalermchon, Wanwisa Thaiwirot, and Prayoot Akkaraekthalin, "Design and analysis of antipodal Vivaldi antennas for breast cancer detection," Computers, Materials & Continua, Vol. 73, No. 1, 411, 2022.
doi:10.32604/cmc.2022.028294 Google Scholar

14. Ibrahim, Islam M., Mohamed I. Ahmed, Hala M. Abdelkader, and M. M. Elsherbini, "A novel compact high gain wide-band log periodic dipole array antenna for wireless communication systems," Journal of Infrared, Millimeter, and Terahertz Waves, Vol. 43, No. 11-12, 872-894, 2022. Google Scholar

15. Zhao, Chengwei, Yanping Bai, and Qiang Wei, "A 2 to 50 GHz all-metal Vivaldi antenna for ultra-wideband (UWB) application," AEU - International Journal of Electronics and Communications, Vol. 148, 154162, 2022. Google Scholar

16. Wang, Jingjing, Jianwei Liu, Yucheng Fan, and Yuxi Bai, "A novel Vivaldi antenna for UWB detection," Microwave and Optical Technology Letters, Vol. 65, No. 3, 826-843, 2023. Google Scholar

17. Paul, Liton Chandra and Md. Mohiminul Islam, "A super wideband directional compact Vivaldi antenna for lower 5G and satellite applications," International Journal of Antennas and Propagation, Vol. 2021, 1-12, 2021. Google Scholar

18. Paik, Harikrishna and Kambham Premchand, "A compact antipodal Vivaldi antenna for modern surveillance systems," International Journal of Electronics Letters, 1-12, 2023. Google Scholar

19. Rodas, Allan Estuardo and Kai Ren, "A wideband Vivaldi antenna for drone-based microwave imaging system," ASEE-NE 2022, Boston, MA, Apr. 2022.

20. Dixit, Amruta S., Sumit Kumar, and Mahesh Abegaonkar, "A corrugated and lens based miniaturized antipodal Vivaldi antenna for 28 GHz and 38 GHz bands applications," Frequenz, Vol. 77, No. 4, 475-484, Oct. 2023. Google Scholar

21. Bhattacharjee, Anindita, Abhirup Bhawal, Anirban Karmakar, Anuradha Saha, and Diptendu Bhattacharya, "Vivaldi antennas: A historical review and current state of art," International Journal of Microwave and Wireless Technologies, Vol. 13, No. 8, 833-850, 2021. Google Scholar

22. Sasikala, Shanmugam, Kandasamy Karthika, Shanmugam Arunkumar, Karunakaran Anusha, Srinivasan Adithya, and Ahmed Jamal Abdullah Al-Gburi, "Design and analysis of a low-profile tapered slot UWB Vivaldi antenna for breast cancer diagnosis," Progress In Electromagnetics Research M, Vol. 124, 43-51, 2024.
doi:10.2528/PIERM23110702 Google Scholar
