Abstract

This paper introduces the configuration of a microstrip antenna array with a new Archimedean spiral sequential feed network (SSFN) for the upper half of the C-band application. The Archimedean SSFN mechanism uses four circular patch elements to structure the proposed antenna array. The optimized reflection loss (S₁₁) of the proposed SSFN mechanism was obtained by tuning the dimensions of each transformer and then connected with an antenna array. Aiming to make the suggested antenna array compact in size, bending feed lines were utilized. The antenna array is designed with overall physical dimensions of 75 mm × 75 mm × 1.575 mm, with an electrical size of 1.85λ_o mm, 1.85λ_o mm, 0.038λ_o at a frequency of 7.43 GHz. An equivalent circuit model (ECM) is designed and analyzed to verify the proposed Archimedean SSFN and the designed antenna array. Reflection losses of SSFN and microstrip spiral antenna array (SAA) were confirmed with the suggested circuit model utilizing Computer Simulation Technology (CST) Microwave Studio and Applied Wave Research (AWR) Microwave Office software. According to the empirical results, the SAA has a reflection loss bandwidth of 2.08 GHz (6.15-8.23 GHz) and a maximum gain of 10.2 dBi at 7.43 GHz. The axial ratio (AR) of the proposed antenna covers a bandwidth of 1.6 GHz (6.2-7.8 GHz), which is approximately 22.85% of the entire bandwidth. These results demonstrate a perfect agreement between the simulated and measured outcomes, making the suggested SAA suitable for the C-band wireless application.

1. Al-Gburi, Ahmed Jamal Abdullah, Zahriladha Zakaria, Hussein Alsariera, Muhammad Firdaus Akbar, Imran Mohd Ibrahim, Khalid Subhi Ahmad, Sarosh Ahmad, and Samir Salem Al-Bawri, "Broadband circular polarised printed antennas for indoor wireless communication systems: A comprehensive review," Micromachines, Vol. 13, No. 7, 1048, 2022. Google Scholar

2. Siahcheshm, A., J. Nourinia, and Ch. Ghobadi, "Circularly polarized antenna array with a new sequential phase feed network utilizing directional coupler," AEU --- International Journal of Electronics and Communications, Vol. 93, 75-82, 2018. Google Scholar

3. Siahcheshm, A., J. Nourinia, Ch. Ghobadi, M. Karamirad, and B. Mohammadi, "A broadband circularly polarized cavity-backed archimedean spiral array antenna for C-band applications," AEU --- International Journal of Electronics and Communications, Vol. 81, 218-226, 2017. Google Scholar

4. Ahmad, Khalid Subhi, Fauziahanim Che Seman, and Shipun Anuar Hamzah, "Dual microstrip antenna patches with orthogonal i-shaped defected ground structure for beam steering realization," 2016 IEEE Asia-Pacific Conference on Applied Electromagnetics (APACE), 174-178, 2016.

5. Ahmad, Khalid Subhi, Mohamad Zoinol Abidin Abd Aziz, and Nuruliswa Binti Abdullah, "Microstrip antenna array with defected ground structure and copper tracks for bandwidth enhancement," 2020 IEEE International RF and Microwave Conference (RFM), 1-5, Kuala Lumpur, Malaysia., 2020.

6. Hall, P. S. and C. M. Hall, "Coplanar corporate feed effects in microstrip patch array design," IEE Proceedings H (Microwaves, Antennas and Propagation), Vol. 135, No. 3, 180-186, 1988.

7. Jazi, M. N. and M. N. Azarmanesh, "Design and implementation of circularly polarised microstrip antenna array using a new serial feed sequentially rotated technique," IEE Proceedings --- Microwaves, Antennas and Propagation, Vol. 153, No. 2, 133-140, 2006. Google Scholar

8. Ta, Son Xuat and Ikmo Park, "Compact wideband circularly polarized patch antenna array using metasurface," IEEE Antennas and Wireless Propagation Letters, Vol. 16, 1932-1936, 2017. Google Scholar

9. Chu, Jian-Yi, Lin Peng, Xiao-Feng Li, and Xing Jiang, "Archimedean spiral antenna loaded by frequency selective surface," Progress In Electromagnetics Research M, Vol. 95, 199-209, 2020. Google Scholar

10. Supreeyatitikul, Nathapat, Danai Torrungrueng, and Chuwong Phongcharoenpanich, "Quadri-cluster broadband circularly-polarized sequentially-rotated metasurface-based antenna array for C-band satellite communications," IEEE Access, Vol. 9, 67015-67027, 2021. Google Scholar

11. Xie, Ji-Yang, Lin Peng, Bao-Jian Wen, and Xing Jiang, "Archimedean spiral antenna with two opposite uni-directional circularly polarized radiation bands designed by resonance based reflectors," Progress In Electromagnetics Research Letters, Vol. 70, 23-30, 2017. Google Scholar

12. Inserra, Daniele, Wei Hu, and Guangjun Wen, "Design of a microstrip series power divider for sequentially rotated nonuniform antenna array," International Journal of Antennas and Propagation, Vol. 2017, No. 1, 9482979, 2017. Google Scholar

13. Maddio, Stefano, "A compact two-level sequentially rotated circularly polarized antenna array for C-band applications," International Journal of Antennas and Propagation, Vol. 2015, No. 1, 830920, 2015. Google Scholar

14. Deng, Changjiang, Yue Li, Zhijun Zhang, and Zhenghe Feng, "A wideband sequential-phase fed circularly polarized patch array," IEEE Transactions on Antennas and Propagation, Vol. 62, No. 7, 3890-3893, 2014. Google Scholar

15. Hall, P. S., J. S. Dahele, and J. R. James, "Design principles of sequentially fed, wide bandwidth, circularly polarised microstrip antennas," IEE Proceedings H (Microwaves, Antennas and Propagation), Vol. 136, No. 5, 381-389, 1989.

16. Smith, M. S. and P. S. Hall, "Analysis of radiation pattern effects in sequentially rotated arrays," IEE Proceedings --- Microwaves, Antennas and Propagation, Vol. 141, No. 4, 313-320, 1994. Google Scholar

17. Chen, Aixin, Yanjun Zhang, Zhizhang Chen, and Shunfeng Cao, "A Ka-band high-gain circularly polarized microstrip antenna array," IEEE Antennas and Wireless Propagation Letters, Vol. 9, 1115-1118, 2010. Google Scholar

18. Chen, Aixin, Yanjun Zhang, Zhizhang Chen, and Chuo Yang, "Development of a Ka-band wideband circularly polarized 64-element microstrip antenna array with double application of the sequential rotation feeding technique," IEEE Antennas and Wireless Propagation Letters, Vol. 10, 1270-1273, 2011. Google Scholar

19. Jalili, F., Javad Pourahmadazar, J. Nourinia, and V. Rafii, "Circularly polarized circular slot antenna array using sequentially rotated feed network," Journal of Communication Engineering, Vol. 1, No. 1, 38-46, 2016. Google Scholar

20. Maddio, Stefano, "A compact wideband circularly polarized antenna array for C-band applications," IEEE Antennas and Wireless Propagation Letters, Vol. 14, 1081-1084, 2015. Google Scholar

21. Zheng, Qi, Chenjiang Guo, Guy A. E. Vandenbosch, and Jun Ding, "Low-profile circularly polarized array with gain enhancement and RCS reduction using polarization conversion EBG structures," IEEE Transactions on Antennas and Propagation, Vol. 68, No. 3, 2440-2445, 2020. Google Scholar

22. Fu, Shiqiang, Shaojun Fang, Zhongbao Wang, and Xiaoming Li, "Broadband circularly polarized slot antenna array fed by asymmetric CPW for L-band applications," IEEE Antennas and Wireless Propagation Letters, Vol. 8, 1014-1016, 2009. Google Scholar

23. Rafii, Vahid, Javad Nourinia, Changiz Ghobadi, Javad Pourahmadazar, and Bal S. Virdee, "Broadband circularly polarized slot antenna array using sequentially rotated technique for C-band applications," IEEE Antennas and Wireless Propagation Letters, Vol. 12, 128-131, 2013. Google Scholar

24. Jiang, Xiaolei, Zhijun Zhang, Yue Li, and Zhenghe Feng, "A low-cost wideband circularly polarized slot array with integrated feeding network and reduced height," IEEE Antennas and Wireless Propagation Letters, Vol. 15, 222-225, 2015. Google Scholar

25. Rupčić, Slavko and Vanja Mandrić, "Spiral antenna array configurations on spherical surface," ICECom 2013, 1-5, Dubrovnik, Croatia, 2013.

26. Gao, Steven, Yi Qin, and Alistair Sambell, "Low-cost broadband circularly polarized printed antennas and array," IEEE Antennas and Propagation Magazine, Vol. 49, No. 4, 57-64, 2007. Google Scholar

27. Evans, H., P. Gale, B. Aljibouri, E. G. Lim, E. Korolkeiwicz, and A. Sambell, "Application of simulated annealing to design of serial feed sequentially rotated 2 × 2 antenna array," Electronics Letters, Vol. 36, No. 24, 1987-1988, 2000. Google Scholar

28. Subhi, Khalid, Fauziahanim Che Seman, Shipun Anuar Hamzah, Goh Chin Hock, and Shaharil Mohd Shah, "Circuit model for microstrip array antenna with defected ground structures for mutual coupling reduction and beamforming applications," International Journal of Integrated Engineering, Vol. 13, No. 1, 101-119, 2021. Google Scholar

29. Shang, Xiaobang and Michael J. Lancaster, "Patch antenna with integrated bandpass filter," 4th Annual Seminar on Passive RF and Microwave Components, 17-21, Birmingham, UK, 2013.

30. Chen, Aixin, Yanjun Zhang, Zhizhang Chen, and Chuo Yang, "Development of a Ka-band wideband circularly polarized 64-element microstrip antenna array with double application of the sequential rotation feeding technique," IEEE Antennas and Wireless Propagation Letters, Vol. 10, 1270-1273, 2011. Google Scholar

31. Singh, Anil Kumar, Ravi Kumar Gangwar, and Binod K. Kanaujia, "Wideband and compact slot loaded annular ring microstrip antenna using L-probe proximity-feed for wireless communications," International Journal of Microwave and Wireless Technologies, Vol. 8, No. 7, 1085-1093, 2016. Google Scholar

32. Sagiroglu, Seref and Adem Kalinli, "Determining resonant frequencies of various microstrip antennas within a single neural model trained using parallel tabu search algorithm," Electromagnetics, Vol. 25, No. 6, 551-565, 2005. Google Scholar

33. Ray, K. P. and Girish Kumar, "Determination of the resonant frequency of microstrip antennas," Microwave and Optical Technology Letters, Vol. 23, No. 2, 114-117, 1999. Google Scholar

34. Garg, Ramesh, Microstrip Antenna Design Handbook, Artech House, 2001.

35. Badjian, Mohammad Hadi, Chandan Kumar Chakrabarty, Sanjay Devkumar, and Goh Chin Hock, "Lumped element circuit model approximation of an UWB patch antenna," 2009 IEEE 9th Malaysia International Conference on Communications (MICC), 28-32, Kuala Lumpur, Malaysia, 2009.

36. Hong, Jia-Shen G. and Michael J. Lancaster, Microstrip Filters for RF/microwave Applications, John Wiley & Sons, 2004.

37. Pozar, David M. and Daniel H. Schaubert, "Comparison of three series fed microstrip array geometries," Proceedings of IEEE Antennas and Propagation Society International Symposium, 728-731, Ann Arbor, MI, USA, 1993.

Dr. Khalid Subhi Ahmad

Dr. Fauziahanim Che Seman

Dr. Shipun Anuar Hamzah

Dr. Khaled Alhassoon

Dr. Tale Saeidi

Dr. Zahriladha Zakaria

Professor Ahmed Jamal Abdullah Al-Gburi
