Abstract

To address the problems that the traditional permanent magnet synchronous motor air-gap flux is difficult to adjust and that the weak magnetic speed expansion ability is poor, a new series-connected hybrid excitation permanent magnet synchronous motor is proposed. A DC excitation winding is added to the rotor, allowing the excitation field generated by this winding to form a series connection with the magnetic field of the permanent magnets. The structure of this paper includes an overview of the novel rotor structure and principle of operation. For the complex rotor structure, a multi-objective genetic algorithm is used for optimisation, followed by finite element analysis to compare the performance of the initial motor, the optimised motor and the conventional motor in terms of no-load air-gap magnetism, reverse electromotive force as well as output torque and efficiency. The magnetic load of the motor in the demagnetized state is increased from 0.2 to 0.266 compared to the unexcited state, and the magnetization capacity is improved by 33%. The output torque of the optimized motor is 252 N.m at low speed; the output torque of the conventional motor is 220 N.m; and the starting torque of the motor is improved by 14.5%. The maximum speed is increased from 10,000 rpm to 11,500 rpm, and the speed expansion capacity is improved by 15%. The effectiveness and feasibility of the series-connected hybrid excitation permanent magnet synchronous motor are verified.

1. Liu, Zhongwu, Jiayi He, and Chaochao Zeng, "Recent progress and future prospects of grain boundary diffusion technology for high-performance NdFeB permanent magnets," Magnetic Materials and Devices, Vol. 54, No. 04, 97-106, 2023. Google Scholar

2. Liu, Zhongwu and Jiayi He, "Several issues on the development of grain boundary diffusion process for Nd-Fe-B permanent magnets," Acta Metall Sin, Vol. 57, No. 9, 1155-1170, 2021. Google Scholar

3. Amara, Yacine, Sami Hlioui, Hamid Ben Ahmed, and Mohamed Gabsi, "Power capability of hybrid excited synchronous motors in variable speed drives applications," IEEE Transactions on Magnetics, Vol. 55, No. 8, 1-12, Aug. 2019. Google Scholar

4. Ai, Qiang, Hongqian Wei, Tao Li, Likang Fan, and Youtong Zhang, "Optimisation of reverse salient rotor for interior permanent magnet synchronous motor and experimental validation," IET Electric Power Applications, Vol. 15, No. 12, 1547-1563, 2021. Google Scholar

5. Gao, Mingling, Zhenhai Yu, Wenjie Jiao, Wenjing Hu, Huihui Geng, Yixin Liu, Shiqiang Liu, and Yishuo Liu, "Study on electromagnetic performance of permanent magnet rotor and dual stator starter generator for electric vehicle range extender," Progress In Electromagnetics Research B, Vol. 106, 39-55, 2024. Google Scholar

6. Wu, Yulun, Xinhong Xiong, and Rongtai Ge, "Optimization study on high power density of high power naturally cooled motor based on NS-GA-III algorithm," Digital Manufacturing Science, Vol. 21, No. 4, 272-275, 2023. Google Scholar

7. Lin, Qi, Zhixin Huang, and Zhuobo You, "Optimization analysis of high torque density industrial rare earth permanent magnet synchronous motor based on electromagnetic and temperature field coupling," Fujian Metallurgy, Vol. 52, No. 05, 61-63, 2023. Google Scholar

8. Wang, Wei, Shuhong Wang, and Yibo Zhang, "Research on weak magnetic control strategy of built-in permanent magnet synchronous motor," Journal of Northwestern Polytechnical University, Vol. 36, No. 05, 970-977, 2018. Google Scholar

9. Gao, Gan, Ronghai Qu, and Haochen Shi, "A review of control strategies for the full-domain high-efficiency operation of wide-speed permanent magnet synchronous motors," Chinese Journal of Electrical Engineering, Vol. 43, No. 07, 2496-2512, 2023. Google Scholar

10. Wang, Jiankun, Haisheng Yu, and Xiangxiang Meng, "Voltage closed-loop adaptive weak magnetism control of asynchronous motor considering reverse electromotive force," Journal of Electrical Engineering, 1-8, 2023. Google Scholar

11. Xu, Pengcheng, "Identification method of permanent magnet synchronous motor rotational error angle based on d-axis current error," Electrical Drives, Vol. 51, No. 20, 56-59, 2021. Google Scholar

12. Zhang, Jianya, Kai Wang, and Lingling Gu, "Singlephase outofphase compromise fault-tolerant control of dual three-phase permanent magnet motor based on minimum copper consumption and maximum torque," Flight Control and Detection, Vol. 5, No. 01, 67-74, 2022. Google Scholar

13. Xu, Lu and Ting Dong, "Application of improved overmodulation strategy in wide speed range control of automotive IPMSM," Electrotechnology, No. 21, 20-22, 2022. Google Scholar

14. Zhao, Hao, "Topology optimization of synchronous reluctance machines," Henan Science and Technology, Vol. 42, No. 20, 12-16, 2023. Google Scholar

15. Lu, Ruipan, Zhangqi Liu, Xiping Liu, Jianwei Liang, Weiliang Wu, and Wenrui Wang, "Electromagnetic characteristic analysis and optimization of a novel reverse salient PMSM for wide speed range," Progress In Electromagnetics Research C, Vol. 140, 105-115, 2024. Google Scholar

16. Qiu, Hongbo, Xiaolu Ma, and Bin Xiong, "Working principle and characteristic study of magnetic moment double-regulating axial radial hybrid excitation motor," Journal of Electrical Machines and Control, 1-17, 2023. Google Scholar

17. Zou, Yongling, Xiping Liu, and TongZe Sun, "Design and electromagnetic characterization of a novel mechanical variable drainage permanent magnet motor," Electric Drive, Vol. 52, No. 4, 2022. Google Scholar

18. Tessarolo, Alberto, Mario Mezzarobba, and Roberto Menis, "Modeling, analysis, and testing of a novel spoke-type interior permanent magnet motor with improved flux weakening capability," IEEE Transactions on Magnetics, Vol. 51, No. 4, 1-10, Apr. 2015. Google Scholar

19. Tessarolo, A., M. Mezzarobba, and R. Menis, "A new rotor design for flux weakening capability improvement in spoke-type interior permanent magnet synchronous machines," 2014 Ninth International Conference on Ecological Vehicles and Renewable Energies (EVER), 1-9, Monte-Carlo, Monaco, 2014.

20. Cinti, Luca, Chiara Contò, and Nicola Bianchi, "A comparison between hybrid excited permanent magnet and wound rotor motor," 2022 International Symposium on Power Electronics, Electrical Drives, Automation and Motion (SPEEDAM), 14-19, Sorrento, Italy, 2022.

21. Feng, Wei and Kaikai Guo, "Optimized design of rotor structure for low-torque pulsating permanent magnet-assisted synchronous reluctance motor," Electric Machines and Control Application, Vol. 51, No. 9, Sep. 2024. Google Scholar

Dr. Jianwei Liang

Ms. Tian Song

Dr. Peiyao Guo

Dr. Xiubin Zhu

Dr. Zhangsheng Liu

Dr. Yuqian Zhao
