Abstract

This paper investigates the circuit theory of elementary passive topology exhibiting reconfigurable positive/negative delay (RPND) effect. This novel evaluated framework enables identification of the first-order L-topology constituted by RC-network operating under RPND effect. The investigated passive L-cell can operate in both negative and positive group delay (NGD or PGD) mode depending on the RC-network parameter. After establishing the NGD existence condition, the design equations versus the RPND effect including the target parameter values are formulated. To validate the theory, an RC-circuit representing a RPND Proof-of-Concept (PoC) was designed, implemented and tested especially in the time-domain by verifying the time-advance signature corresponding to the NGD operation mode. By tuning a PoC resistor, experimentation of pulse and arbitrary waveform signals confirm the feasibility to observe RPND reconfigurability. In the NGD mode, it is observed that outputs in time-advance of their own inputs about -3 ms. The RPND circuit is particularly useful for adjusting delay effect and signal synchronization in the communication system.
