Abstract

This paper presents the design of a frequency reconfigurable monopole microstrip patch antenna for wireless communication applications. The proposed antenna functions in one single-band mode and one dual-band mode, depending on the diode switching configuration. When the diode is in the OFF state, the proposed antenna operates at single band 5.8 GHz (WLAN), and in the ON state, the antenna operates at dual bands 1.8 GHz (GPS/RADAR) and 5.2 GHz (WLAN). To enhance the gain of the proposed reconfigurable antenna, a multilayer frequency selective surface (FSS) reflector is presented. A significant enhancement in gain has been achieved in a low-profile design. The average peak gain of the antenna has been increased from 4 dBi to 6 dBi as a consequence of the use of the FSS reflector. The simulation of the proposed design is carried out using CST (Computer Simulation Technology) based on the FIT (Finite Integration Technique) numerical method. To validate the simulated results, a prototype of the antenna was fabricated and measured using PIN diodes. The simulated and measured results of the proposed antenna exhibit a reasonable agreement.

1. Shah, I. A., S. Hayat, A. Basir, M. Zada, S. A. A. Shah, and S. Ullah, "Design and analysis of a hexa-band frequency reconfigurable antenna for wireless communication," AEU --- International Journal of Electronics and Communications, Vol. 98, 80-88, 2019. Google Scholar

2. Ullah, S., S. Ahmad, B. A. Khan, U. Ali, F. A. Tahir, and S. Bashir, "Design and analysis of a hexa-band frequency reconfigurable monopole antenna," IETE Journal of Research, Vol. 64, No. 1, 59-66, 2018. Google Scholar

3. Shah, I. A., S. Hayat, I. Khan, I. Alam, S. Ullah, and A. Afridi, "A compact, tri-band and 9-shape reconfigurable antenna for WiFi, WiMAX and WLAN applications," International Journal of Wireless and Microwave Technologies (IJWMT), Vol. 6, No. 5, 45-53, 2016. Google Scholar

4. Kuo, Y. L. and K. L. Wong, "Printed double-T monopole antenna for 2.4/5.2 GHz dual-band WLAN operations," IEEE Transactions on Antennas and Propagation, Vol. 51, No. 9, 2187-2192, 2003. Google Scholar

5. Saleh, A. A. and A. S. Abdullah, "A novel design of patch antenna loaded with complementary split-ring resonator and L-shape slot for (WiMAX/WLAN) applications," International Journal of Wireless and Microwave Technologies (IJWMT), Vol. 3, 16-25, 2014. Google Scholar

6. Park, Y. K. and Y. Sung, "A reconfigurable antenna for quad-band mobile handset applications," IEEE Transactions on Antennas and Propagation, Vol. 60, No. 6, 3003-3006, 2012. Google Scholar

7. Hayat, S., I. A. Shah, I. Khan, I. Alam, S. Ullah, and A. Basir, "Design of tetra-band frequency reconfigurable antenna for portable wireless applications," 2016 International Conference on Intelligent Systems Engineering (ICISE), 10-13, IEEE, January 2016. Google Scholar

8. Iddi, H. U., M. R. Kamarudin, T. A. Rahman, and R. Dewan, "Design of dual-band B-shaped monopole antenna for MIMO application," Proceedings of the 2012 IEEE International Symposium on Antennas and Propagation, 1-2, IEEE, July 2012. Google Scholar

9. Jing, S., Y. Yin, A. Sun, Y. Wei, and Y. Yang, "Compact E-shaped monopole antenna for dual-band WLAN applications," 2011 IEEE International Conference on Microwave Technology & Computational Electromagnetics, 305-308, IEEE, May 2011. Google Scholar

10. Panda, J. R. and R. S. Kshetrimayum, "A printed F-shaped dual-band monopole antenna for RFID and WLAN applications," 2010 International Conference on Computer and Communication Technology (ICCCT), 789-791, IEEE, September 2010. Google Scholar

11. Song, Y., Y. C. Jiao, H. Zhao, Z. Zhang, Z. B. Weng, and F. S. Zhang, "Compact printed monopole antenna for multiband WLAN applications," Microwave and Optical Technology Letters, Vol. 50, No. 2, 365-367, 2008. Google Scholar

12. Chang, T. H. and J. F. Kiang, "Compact multi-band H-shaped slot antenna," IEEE Transactions on Antennas and Propagation, Vol. 61, No. 8, 4345-4349, 2013. Google Scholar

13. Mahlaoui, Z., E. Antonino-Daviu, A. Latif, and M. Ferrando-Bataller, "Design of a dual-band frequency reconfigurable patch antenna based on characteristic modes," International Journal of Antennas and Propagation, Vol. 2019, Article ID 4512532, 12 pages, 2019. Google Scholar

14. Pandhare, R. A. and M. P. Abegaonkar, "Inset-feed frequency reconfigurable compact E-shape patch with DGS," Progress In Electromagnetics Research C, Vol. 101, 119-132, 2020. Google Scholar

15. Younus, K. M. and K. H. Sayidmarie, "A tri-band frequency reconfigurable slot antenna for wireless applications," The Applied Computational Electromagnetics Society Journal (ACES), Vol. 35, 194-200, 2020. Google Scholar

16. Ellusamy, S. and R. Balasubramanian, "Sub-6 GHz quad-band reconfigurable antenna for 5G cognitive radio applications," The Applied Computational Electromagnetics Society Journal (ACES), Vol. 36, No. 8, 1015-1025, 2021. Google Scholar

17. Pandhare, R. A., M. P. Abegaonkar, and C. Dhote, "UWB antenna with novel FSS reflector for the enhancement of the gain and bandwidth," International Journal of Microwave and Wireless Technologies, 1-16, 2022. Google Scholar

18., https://www.macom.com/products/product-detail/MA4SPS402.

19. Marcuitz, N., Waveguide Handbook, 1st Ed., McGraw-Hill, 1951.

20. Segundo, F. C., A. L. P. Campos, A. Gomes Neto, and M. D. O. Alencar, "Double layer frequency selective surface for ultra wide band applications with angular stability and polarization independence," Journal of Microwaves, Optoelectronics and Electromagnetic Applications, Vol. 18, No. 3, 328-342, 2019. Google Scholar

21. Khalid, N. K. B. A. and F. B. C. Seman, "Double square loop frequency selective surface (FSS) for GSM shielding," Advanced Computer and Communication Engineering Technology, Vol. 315, 223-229, Springer, Cham, 2015. Google Scholar

22. Kushwaha, N. and R. Kumar, "High gain UWB antenna using compact multilayer FSS," 2014 IEEE International Microwave and RF Conference (IMaRC), 100-103, IEEE, December 2014. Google Scholar

23. Pandhare, R., M. Abegaonkar, and C. Dhote, "High gain wideband and multi-band on-demand reconfigurable antenna for modern wireless application," International Journal of Microwave and Wireless Technologies, 1-16, 2022. Google Scholar
