Abstract

This study proposes a dual-band microwave sensor based on a split-ring resonator (SRR) coupled with a pair of L-shaped structures. The proposed sensor has dual functionalities, including the detection of liquid permittivity and solid displacement. An ethanol-water mixture is selected as a sample to measure the permittivity of the liquid. Moreover, FR4 is chosen as the test sample to measure the displacement of the solid. As a result, the maximum frequency detection resolution (FDR) is 1.64, and the average FDR is 1.40. The maximum and average normalized sensitivity (NS) values are 0.073% and 0.06%, respectively. The maximum displacement sensitivity is 10.0 MHz/mm for f_DS2 and 10.5 MHz/mm for f_DS1, while the average displacement sensitivity values are 4.98 MHz/mm and 8.02 MHz/mm for f_DS2 and f_DS1, respectively. These values confirm the sensor's reliable performance and sensitivity across different measurements. In general, the proposed sensor offers several advantages: 1) it operates independently by isolating the electric fields generated by each sensor; 2) it demonstrates dual functionalities, including the detection of liquid permittivity and solid displacement; and 3) it is capable of handling both liquid and solid samples.

1. Abdolrazzaghi, Mohammad and Mojgan Daneshmand, "Exploiting sensitivity enhancement in micro-wave planar sensors using intermodulation products with phase noise analysis," IEEE Transactions on Circuits and Systems I: Regular Papers, Vol. 67, No. 12, 4382-4395, 2020. Google Scholar

2. Zhu, Liang, Mohamed Farhat, Yi-Chao Chen, Khaled N. Salama, and Pai-Yen Chen, "A compact, passive frequency-hopping harmonic sensor based on a microfluidic reconfigurable dual-band antenna," IEEE Sensors Journal, Vol. 20, No. 21, 12495-12503, 2020. Google Scholar

3. Alam, Syah, Indra Surjati, Lydia Sari, Yuli K. Ningsih, Munanda Y. Fathanah, Yessi K. Gultom, Ghathfan Daffin, Teguh Firmansyah, and Zahriladha Zakaria, "UHF-band solid sensor based on tweaking electric field coupled resonator for material characterization," Progress In Electromagnetics Research M, Vol. 126, 11-18, 2024.
doi:10.2528/PIERM24020201 Google Scholar

4. Bait-Suwailam, Mohammed M., "Numerical assessment of red palm weevil detection mechanism in palm trees using CSRR microwave sensors," Progress In Electromagnetics Research Letters, Vol. 100, 63-71, 2021. Google Scholar

5. Kobayashi, Yusuke, Toshiki Tsuchiya, Masaya Okazaki, Yuuki Asao, Kenya Hashimoto, and Shinichi Shikata, "High-frequency surface acoustic wave resonator with ScAlN/hetero-epitaxial diamond," Diamond and Related Materials, Vol. 111, 108190, 2021. Google Scholar

6. Go, David B., Massood Z. Atashbar, Zeinab Ramshani, and Hsueh-Chia Chang, "Surface acoustic wave devices for chemical sensing and microfluidics: A review and perspective," Analytical Methods, Vol. 9, No. 28, 4112-4134, 2017. Google Scholar

7. Shilton, Richie J., Marco Travagliati, Fabio Beltram, and Marco Cecchini, "Nanoliter-droplet acoustic streaming via ultra high frequency surface acoustic waves," Advanced Materials, Vol. 26, No. 29, 4941-4946, 2014. Google Scholar

8. Ebrahimi, Amir, James Scott, and Kamran Ghorbani, "Dual-mode resonator for simultaneous permittivity and thickness measurement of dielectrics," IEEE Sensors Journal, Vol. 20, No. 1, 185-192, 2020. Google Scholar

9. Albishi, Ali M., Mohamed K. El Badawe, Vahid Nayyeri, and Omar M. Ramahi, "Enhancing the sensitivity of dielectric sensors with multiple coupled complementary split-ring resonators," IEEE Transactions on Microwave Theory and Techniques, Vol. 68, No. 10, 4340-4347, 2020. Google Scholar

10. Tseng, Chao-Hsiung and Cheng-You Yang, "Novel microwave frequency-locked-loop-based sensor for complex permittivity measurement of liquid solutions," IEEE Transactions on Microwave Theory and Techniques, Vol. 70, No. 10, 4556-4565, 2022. Google Scholar

11. Kulkarni, Savita and Madhuri S. Joshi, "Design and analysis of shielded vertically stacked ring resonator as complex permittivity sensor for petroleum oils," IEEE Transactions on Microwave Theory and Techniques, Vol. 63, No. 8, 2411-2417, 2015. Google Scholar

12. Kiani, Sina, Pejman Rezaei, Moein Navaei, and Mohammad Sadegh Abrishamian, "Microwave sensor for detection of solid material permittivity in single/multilayer samples with high quality factor," IEEE Sensors Journal, Vol. 18, No. 24, 9971-9977, 2018. Google Scholar

13. Su, Lijuan, Jonathan Muñoz-Enano, Paris Vélez, Pau Casacuberta, Marta Gil, and Ferran Martin, "Phase-variation microwave sensor for permittivity measurements based on a high-impedance half-wavelength transmission line," IEEE Sensors Journal, Vol. 21, No. 9, 10647-10656, 2021. Google Scholar

14. Sun, Haoran, Rongqiang Li, Gui Yun Tian, Tao Tang, Guohong Du, and Bin Wang, "Determination of complex permittivity of thin dielectric samples based on high-Q microstrip resonance sensor," Sensors and Actuators A: Physical, Vol. 296, 31-37, 2019. Google Scholar

15. Yeo, Junho and Jong-Ig Lee, "Slot-loaded microstrip patch sensor antenna for high-sensitivity permittivity characterization," Electronics, Vol. 8, No. 5, 502, 2019. Google Scholar

16. Li, Yang, Nicola Bowler, and David Bennett Johnson, "A resonant microwave patch sensor for detection of layer thickness or permittivity variations in multilayered dielectric structures," IEEE Sensors Journal, Vol. 11, No. 1, 5-15, 2011. Google Scholar

17. Coromina, J., J. Muñoz-Enano, P. Vélez, A. Ebrahimi, J. Scott, K. Ghorbani, and F. Martín, "Capacitively-loaded slow-wave transmission lines for sensitivity improvement in phase-variation permittivity sensors," 2020 50th European Microwave Conference (EuMC), 491-494, Utrecht, Netherlands, Jan. 2021.

18. Alam, Syah, Zahriladha Zakaria, Indra Surjati, Noor Azwan Shairi, Mudrik Alaydrus, and Teguh Firmansyah, "Dual-band independent permittivity sensor using single-port with a pair of U-shaped structures for solid material detection," IEEE Sensors Journal, Vol. 22, No. 16, 16111-16119, 2022. Google Scholar

19. Saghlatoon, Hossein, Rashid Mirzavand, Mohammad Mahdi Honari, and Pedram Mousavi, "Sensor antenna transmitter system for material detection in wireless-sensor-node applications," IEEE Sensors Journal, Vol. 18, No. 21, 8812-8819, 2018. Google Scholar

20. Adhikary, Moitreya, Animesh Biswas, and M. Jaleel Akhtar, "Active integrated antenna based permittivity sensing tag," IEEE Sensors Letters, Vol. 1, No. 6, 1-4, 2017. Google Scholar

21. Sekar, Vikram, William J. Torke, Samuel Palermo, and Kamran Entesari, "A self-sustained microwave system for dielectric-constant measurement of lossy organic liquids," IEEE Transactions on Microwave Theory and Techniques, Vol. 60, No. 5, 1444-1455, 2012. Google Scholar

22. Abduljabar, Ali A., David J. Rowe, Adrian Porch, and David A. Barrow, "Novel microwave microfluidic sensor using a microstrip split-ring resonator," IEEE Transactions on Microwave Theory and Techniques, Vol. 62, No. 3, 679-688, 2014. Google Scholar

23. Gargari, Ali Maleki, Mohammad Hossein Zarifi, and Loïc Markley, "Passive matched mushroom structure for a high sensitivity low profile antenna-based material detection system," IEEE Sensors Journal, Vol. 19, No. 15, 6154-6162, 2019. Google Scholar

24. Radonić, Vasa, Slobodan Birgermajer, and Goran Kitić, "Microfluidic EBG sensor based on phase-shift method realized using 3D printing technology," Sensors, Vol. 17, No. 4, 892, 2017.
doi:10.3390/s17040892 Google Scholar

25. Martín, Ferran, Miguel Durán-Sindreu, and Ferran Martín, "Alignment and position sensors based on split ring resonators," Sensors, Vol. 12, No. 9, 11790-11797, 2012. Google Scholar

26. Mehrjoo, Zahra, Amir Ebrahimi, and Kamran Ghorbani, "Microwave resonance-based reflective mode displacement sensor with wide dynamic range," IEEE Transactions on Instrumentation and Measurement, Vol. 71, 1-9, 2021. Google Scholar

27. Horestani, Ali K., Jordi Naqui, Zahra Shaterian, Derek Abbott, Christophe Fumeaux, and Ferran Martín, "Two-dimensional alignment and displacement sensor based on movable broadside-coupled split ring resonators," Sensors and Actuators A: Physical, Vol. 210, 18-24, 2014. Google Scholar

28. Mandel, Christian, Bernd Kubina, Martin Schüßler, and Rolf Jakoby, "Passive chipless wireless sensor for two-dimensional displacement measurement," 2011 41st European Microwave Conference, 79-82, Manchester, UK, Oct. 2011.

29. Naqui, Jordi and Ferran Martín, "Transmission lines loaded with bisymmetric resonators and their application to angular displacement and velocity sensors," IEEE Transactions on Microwave Theory and Techniques, Vol. 61, No. 12, 4700-4713, 2013. Google Scholar

30. Teng, Cheng, Chi Hou Chio, Kam Weng Tam, and Pui Yi Lau, "An angular displacement microwave sensor with 360° dynamic range using multi-mode resonator," IEEE Sensors Journal, Vol. 21, No. 3, 2899-2907, 2021. Google Scholar

31. Chio, Chi Hou, Roberto Gómez-García, Li Yang, Kam Weng Tam, Wai-Wa Choi, and Sut Kam Ho, "An angular displacement sensor based on microwave transversal signal interference principle," IEEE Sensors Journal, Vol. 20, No. 19, 11237-11246, 2020. Google Scholar

32. Zhu, Hong-Xu, Pedro Cheong, Kam-Weng Tam, Sut-Kam Ho, and Wai-Wa Choi, "An angular displacement sensor based on microstrip wideband impedance transformer with quasi-Chebyshev frequency response," IEEE Sensors Journal, Vol. 20, No. 8, 4200-4206, 2020. Google Scholar

33. Naqui, Jordi and Ferran Martín, "Angular displacement and velocity sensors based on electric-LC (ELC) loaded microstrip lines," IEEE Sensors Journal, Vol. 14, No. 4, 939-940, 2014. Google Scholar

34. Chio, Chi-Hou, Kam-Weng Tam, and Roberto Gómez-García, "Filtering angular displacement sensor based on transversal section with parallel-coupled-line path and U-shaped coupled slotline," IEEE Sensors Journal, Vol. 22, No. 2, 1218-1226, 2022. Google Scholar

35. Chio, Chi-Hou, Roberto Gómez-García, Li Yang, Kam-Weng Tam, Wai-Wa Choi, and Sut-Kam Ho, "An angular-displacement microwave sensor using an unequal-length-bi-path transversal filtering section," IEEE Sensors Journal, Vol. 20, No. 2, 715-722, 2020. Google Scholar

36. Pozar, David M., Microwave Engineering, 4th Ed., 752, John Wiley & Sons, 2011.

37. Verma, Anand K., Introduction to Modern Planar Transmission Lines: Physical, Analytical, and Circuit Models Approach, John Wiley & Sons, 2021.
doi:10.1002/9781119632443

38. Ebrahimi, Amir, James Scott, and Kamran Ghorbani, "Ultrahigh-sensitivity microwave sensor for microfluidic complex permittivity measurement," IEEE Transactions on Microwave Theory and Techniques, Vol. 67, No. 10, 4269-4277, 2019. Google Scholar

39. Firmansyah, Teguh, Supriyanto Praptodiyono, Imamul Muttakin, Ken Paramayudha, Syah Alam, Teguh Handoyo, Dian Rusdiyanto, Mudrik Alaydrus, Habib Nurseha Anggradinata, Tomy Abuzairi, Gunawan Wibisono, and Jun Kondoh, "Multifunctional glass microfluidic microwave sensor attenuator for detection of permittivity and conductivity with device protection," IEEE Sensors Journal, Vol. 24, No. 4, 4574-4585, 2024. Google Scholar

40. Firmansyah, Teguh, Supriyanto Praptodiyono, Imamul Muttakin, Muh. Wildan, Dwi Astuti Cahyasiwi, Yusnita Rahayu, Hepi Ludiyati, Ken Paramayudha, Yuyu Wahyu, Syah Alam, Mudrik Alaydrus, and Jun Kondoh, "Integrated and independent solid microwave sensor with dual-band bandpass filter through unified mux-demux structure," IEEE Sensors Journal, Vol. 24, No. 12, 19253-19261, 2024. Google Scholar

41. Abdolrazzaghi, Mohammad, Mojgan Daneshmand, and Ashwin K. Iyer, "Strongly enhanced sensitivity in planar microwave sensors based on metamaterial coupling," IEEE Transactions on Microwave Theory and Techniques, Vol. 66, No. 4, 1843-1855, 2018. Google Scholar

42. Kiani, Sina and Pejman Rezaei, "Microwave substrate integrated waveguide resonator sensor for non-invasive monitoring of blood glucose concentration: Low cost and painless tool for diabetics," Measurement, Vol. 219, 113232, 2023. Google Scholar

43. Sepulveda, Lyda Vanessa Herrera, Jose Luis Olvera Cervantes, and Carlos E. Saavedra, "Multifrequency coupled-resonator sensor for dielectric characterization of liquids," IEEE Transactions on Instrumentation and Measurement, Vol. 70, 1-7, 2021. Google Scholar

44. Alam, Syah, Zahriladha Zakaria, Indra Surjati, Noor Azwan Shairi, Mudrik Alaydrus, Teguh Firmansyah, Yuli Kurnia Ningsih, and Lydia Sari, "Collaboratively far-field and near-field regions for dual-modalities microwave permittivity sensor using T-shaped resonator embedded with IDC," IEEE Sensors Letters, Vol. 8, No. 7, 1-4, 2024. Google Scholar

45. Han, Xueyun, Ke Liu, and Siyu Zhang, "High-sensitivity dual-band microfluidic microwave sensor for liquid dielectric characterization," IEEE Sensors Journal, Vol. 24, No. 22, 36689-36697, 2024. Google Scholar

46. Rezaee, Morteza and Mojtaba Joodaki, "Two-dimensional displacement sensor based on CPW line loaded by defected ground structure with two separated transmission zeroes," IEEE Sensors Journal, Vol. 17, No. 4, 994-999, 2017. Google Scholar
