Abstract

In recent years, active Radio Frequency Identification (RFID) tags have crossed into ultra low power domain. With obvious advantages over passive tags, a setback for active tag growth is the need for battery replacement and limited operational life. Battery life could be extended by scavenging surrounding Wi-Fi signals using rectenna architecture which consists of a receiving antenna attached to a rectifying circuit. A seven stage Cockroft-Walton voltage multiplier optimized for low input power (below 0 dBm) is proposed. Prototype was fabricated on RT/Duroid 5880 (RO5880) printed circuit board (PCB) substrate with dielectric constant and loss tangent of 2.2 and 0.0009 respectively. Experimental results show that 2 V output voltage can be harvested from an operating frequency of 2.48 GHz with -9 dBm (0.13 mW) sensitivity with 1.57 mm board thickness.

1. Roussos, G. and V. Kostakos, "RFID in pervasive computing: State-of-the-art and outlook," Pervasive and Mobile Computing, Vol. 5, 110-131, 2009.
doi:10.1016/j.pmcj.2008.11.004 Google Scholar

2. Harrop, P. and R. Das, "Active RFID and Sensor Networks 2011-2021,", RFID Report, IDTechEx, Cambridge, UK, Jun. 2011. Google Scholar

3. Wireless Broadband Alliance Ltd. "Global developments in public Wi-Fi,", http://www.wballiance.com/wba/wp-content/uploads/downloads/2012/07/ 16 WBA-Industry-Report-2011- Global-Developments-in-Public-Wi-Fi-1.00.pdf, Accessed on Mar. 24, 2013. Google Scholar

4. Hande, A., R. Bridgelall, and B. Zoghi, "Vibration energy harvesting for disaster asset monitoring using active RFID tags," Proceedings of the IEEE, Vol. 98, No. 9, 1620-1628, 2010.
doi:10.1109/JPROC.2010.2050670 Google Scholar

5. Pillai, V., H. Heinrich, D. Dieska, P. V. Nikitin, R. Martinez, and K. V. S. Rao, "An ultra-low-power long range battery/passive RFID tag for UHF and microwave bands with a current consumption of 700 nA at 1.5 V," IEEE Transactions on Circuits and Systems I: Regular Papers, Vol. 54, No. 7, 1500-1512, Jul. 2007. Google Scholar

6. Usman, A. D., W. F. Wan Ahmad, M. Z. A. Ab Kadir, M. Mokhtar, and M. A. Zainal Abidin, "Densitometry of electromagnetic field exposure due to Wi-Fi frequency," PIERS Proceedings, 1385-1390, Marrakesh, Morocco, Mar. 20-23, 2011. Google Scholar

7. Epp, L. W., A. R. Khan, H. K. Smith, and R. P. Smith, "A compact dual-polarized 8.51 GHz rectenna for high-voltage (50 V) actuator applications," IEEE Transactions on Microwave Theory and Techniques, Vol. 48, No. 11, 112-120, Jan. 2000. Google Scholar

8. Park, J. Y., S. M. Han, and T. Itoh, "A rectenna design with harmonic rejecting circular-sector antenna," IEEE Antennas Wireless Propagation Letters, Vol. 3, 52-54, Feb. 2004.
doi:10.1109/LAWP.2004.827889 Google Scholar

9. Curty, J. P., M. Declercq, C. Dehollain, and N. Joehl, Design and Optimization of Passive UHF RFID Systems, Springer, New York, 2010.

10. Nintanavongsa, P., U. Muncuk, D. R. Lewis, and K. R. Chowdhury, "Design optimization and implementation for RF energy harvesting circuits," IEEE Journal on Emerging and Selected Topics in Circuits and System, Vol. 2, No. 1, 24-33, Mar. 2012.
doi:10.1109/JETCAS.2012.2187106 Google Scholar

11. Chow, E. Y., C.-L. Yang, Y. Ouyang, A. L. Chlebowski, P. P. Irazoqui, and W. J. Chappell, "Wireless powering and the study of RF propagation through ocular tissue for development of implantable sensors," IEEE Transactions on Antennas and Propagation, Vol. 59, No. 6, 2379-2387, Jun. 2011.
doi:10.1109/TAP.2011.2144551 Google Scholar

12. Yeoh, W. S., "Wireless power transmission (WPT) application at 2.45 GHz in common network,", Ph.D. Thesis, RMIT University, Melbourne, Australia, 2010. Google Scholar

13. Chen, R. H., Y. C. Lee, and J. S. Sun, "Design and experiment of a loop rectenna for RFID wireless power transmission and data communication applications," PIERS Proceedings, 528-531, Beijing, China, Mar. 23-27, 2009. Google Scholar

14. Harrist, D. W., "Wireless battery charging system using RF energy harvesting,", M.Sc. Thesis, University of Pittsburgh, 2004. Google Scholar

15. Fritzin, J., C. Svensson, and A. Alvandpour, "Design and analysis of a class-D stage with harmonic suppression," IEEE Transanctions on Circuits and Systems I: Regular Papers, Vol. 59, No. 6, 1178-1186, Jun. 2012.
doi:10.1109/TCSI.2011.2173389 Google Scholar

16. Kim, Y. and S. Lim, "A highly efficient rectenna using harmonic rejection capability," Journal of the Korean Institute of Electromagnetic Engineering and Science, Vol. 11, No. 4, 257-261, Dec. 2011.
doi:10.5515/JKIEES.2011.11.4.257 Google Scholar

17. Witte, R. A., Electronic Test Instruments: Analog and Digital Measurements, Prentice-Hall, New Jersey, 2002.

18. Bianchi, G. and R. Sorrentino, Electronic Filter Simulation & Design, McGraw-Hill, New York, 2007.

19. Chen, W.-K., Passive and Active Filters Theory and Implementations, John Wiley & Sons, 1986.

20. Choma, J., "Coupled inductor, constant resistance, broadband delay filter," Analog Integrated Circuits and Signal Processing, Vol. 54, No. 1, 7-20, Dec. 2007.
doi:10.1007/s10470-007-9115-z Google Scholar

21. Samanta, K. K. and I. D. Robertson, "Dielectric thickness and ground width effect on multilayer coplanar components and circuits for ceramic multichip modules," Microwave and Optical Technology Letters, Vol. 54, No. 5, 1127-1132, May 2012.
doi:10.1002/mop.26759 Google Scholar

22. Mikeka, C. and H. Arai, "Design issues in radio frequency energy harvesting system,", http://cdn.intechopen.com/pdfs/25376/InTech-Design issues in radio frequency energy harvesting system.pdf, Accessed on May 7, 2013. Google Scholar

23. Din, N. M., C. K. Chakrabarty, A. Bin Ismail, K. K. A. Devi, and W.-Y. Chen, "Design of RF energy harvesting system for energizing low power devices," Progress In Electromagnetics Research, Vol. 132, 49-69, Sep. 2012. Google Scholar
