A T-Shaped Polyomino Subarray Design Method for Controlling Sidelobe Level
By
Progress In Electromagnetics Research C, Vol. 126, 243-251, 2022
Abstract
Partitioning large planar antenna arrays into smaller subarrays reduces the system costs and gives many other advantages. In this article, symmetrical T-shaped tetromino subarrays are suggested to perform the partition process of the large planar arrays. Different structures of T-shaped tetromino subarrays have been obtained by simply rotating its orientation by multiple angles of 90 degrees such that the entire planar array aperture can be filled. Two array architectures based on different T-shaped tetrominoes are constructed. The amplitude weights of the designed subarrays are optimized by means of the genetic algorithm such that the resulting array patterns have low sidelobe level. In the first architecture, all the elements in the original array are divided into several subarrays based on three T-shape structures, while in the second architecture all the elements are combined into eight different T-shapes. To control the sidelobe level in the proposed T-shaped tetromino subarrays, a surface mask boundary function is included in the optimization process to find the optimum weights of the T-shaped subarrays. Simulation results showed that the sidelobes can be reduced to less than -20 dB in the first architecture, and less than -25 dB in the second architecture, in addition to a significant reduction in the complexity of the feeding network for each one. Moreover, detailed connections of the feeding network circuitry of the used T-shaped tetromino subarray structures are given for practical implementation.
Citation
Ahmed Jameel Abdulqader Jafar Ramadhan Mohammed Yaser Ahmed Ali , "A T-Shaped Polyomino Subarray Design Method for Controlling Sidelobe Level," Progress In Electromagnetics Research C, Vol. 126, 243-251, 2022.
doi:10.2528/PIERC22080803
http://www.jpier.org/PIERC/pier.php?paper=22080803
