Abstract

The feasibility of using passive radiometric detection of chaotic electromagnetic signals emanating from low density plasma plumes of the jet exhaust gases to detect low radar cross section aircrafts is analyzed for the frequency band 3.10⁸-3.10¹² Hz. The aircraft exhaust plume gas formation is modelled with a number of discrete different dimensions ellipsoids, with each having different electron densities and temperatures. Electromagnetic radiation analysis of emitting signals is computed applying fluctuation-dissipation theorem and geometric considerations. The detection range of characteristic military jet aircraft is computed numerically for the whole frequency band, from UHF to 3 THz. It is shown that high range detection can be achieved at upper microwave frequencies.

1. Winther, Morten and Kristin Rypdal, 1.A.3.a, 1.A.5.b Aviation, European Environment Agency, 2017.

2. Starik, A. M., "Gaseous and particulate emissions with jet engine exhaust and atmospheric pollution," Advance on Propulsion Technology for High-Speed Aircraft, Vol. 15, 1-22, 2008.

3. He, Liming, Yunwei Zhang, Hao Zeng, and Bingbing Zhao, "Research progress of microwave plasma ignition and assisted combustion," Chinese Journal of Aeronautics, Vol. 36, No. 12, 53-76, 2023.

4. Haverkamp, H., S. Wilhelm, A. Sorokin, and F. Arnold, "Positive and negative ion measurements in jet aircraft engine exhaust: Concentrations, sizes and implications for aerosol formation," Atmospheric Environment, Vol. 38, No. 18, 2879-2884, 2004.

5. Stix, Thomas H., Waves in Plasmas, Chapter 1, Springer Science & Business Media, New York, 1992.

6. Jones, D. S., Theory of Electromagnetism, Chapter 2, Pergamon Press, 1962.

7. Tsang, L., J. A. Kong, and R. T. Shin, Theory of Microwave Remote Sensing, 42, John Wiley, New York, 1985.

8. Racette, Paul and Roger H. Lang, "Radiometer design analysis based upon measurement uncertainty," Radio Science, Vol. 40, No. 05, 1-22, 2005.

9. Singh, Hitesh, Vivek Kumar, Boncho Bonev, and Kumud Saxena, "A novel method for prediction of attenuation of millimeter waves by fog and smoke," International Journal of Recent Technology and Engineering (IJRTE), Vol. 8, No. 3, 2080-2085, Sep. 2019.
doi:10.35940/ijrte.C3853.098319

10. Frey, T. L., "The effects of the atmosphere and weather on the performance of a mm-Wave communication link," Applied Microwave and Wireless, Vol. 11, 76-81, 1999.

11. Preissner, J., "The influence of the atmosphere on passive radiometric measurements," AGARD Millimeter and Submillimeter Wave Propagation and Circuits, 1979.

12. Technical order 00-105E-9, Revision 11, Chapter 8, Aerospace Emergency Rescue and Mishap Response Information, F-16 aircraft danger areas, Engine Thrusts for F100-PW-229, Feb. 2006.

13. Coutu, Nicholas, William Barrot, William Engblom, and Eric Perrell, "Implementation of microwave transmissions for rocket plume diagnostics," 2013 Proceedings of IEEE Southeastcon, Jacksonville, FL, USA, 2013.

14. Delaney, B. T., Bryan A. Zetlen, Ronald C. Tai, Glenn D. Seitchek, and G. G. Elcock, "Aircraft engine exhaust plume dynamics," Science and Engineering Associates Inc., Seattle, WA, USA, 1986.

Dr. Thomas N. Chatziathanasiou

Prof. Nikolaos Uzunoglu
