2025-09-30
Exploitation of Scattering of VHF Electromagnetic Waves from Jet Engine Exhaust Plasma Formations to Improve Detection Low RCS Aircrafts
By
Progress In Electromagnetics Research C, Vol. 160, 169-174, 2025
Abstract
The feasibility of utilization of VHF radars, radiating at lower and just above the plasma frequency of the gas formation exhausts of jet engine aircrafts, is investigated as a means to propose anti-stealth detection method. In the first step, the scattering of electromagnetic waves by a plasma sphere is studied, and comparison with Physical Optics (P.O.) Radar Cross Section (RCS) computations is done. This shows the possibility of using P.O. to compute the RCS under the assumption of jet engine exhaust plume structured modelled as multilayer prolate spheroid. Also, in case of radiation frequencies just above the plasma resonance, under the condition of weak scattering - refractive index being close to unity - the Rayleigh-Gans approximation is used to compute the RCS. Furthermore, computations based on this model shows the possibility to enhance the RCS of aircrafts by combining the ``specular'' reflection of part of the exhaust with plasma resonance frequency being higher than the radar frequency and also the part of exhaust having plasma frequency just below the radar radiation frequency. The numerical results show promising mechanisms to compete to improve the detectability of aircrafts with RCS as low as 0,001 m2.
Citation
Thomas N. Chatziathanasiou, Athanasios Douklias, and Nikolaos Uzunoglu, "Exploitation of Scattering of VHF Electromagnetic Waves from Jet Engine Exhaust Plasma Formations to Improve Detection Low RCS Aircrafts," Progress In Electromagnetics Research C, Vol. 160, 169-174, 2025.
doi:10.2528/PIERC25061802
References

1. Arvind Dhananjayan, Countering Stealth Technology in Military Aviation, https://indiandefencereview.com/countering-stealth-technology-in-military-aviation/.

2. Chatziathanasiou, Thomas N. and Nikolaos Uzunoglu, "Theoretical analysis of detection of flying vehicles based on the passive radiometric detection of microwave-millimeter-terahertz wavelength electromagnetic emissions from exhaust plasma gases," Progress In Electromagnetics Research C, Vol. 154, 267-275, 2025.
doi:10.2528/PIERC25021602

3. Winther, M. and K. Rypdal, 1.A.3.a, 1.A.5.b Aviation, European Environment Agency, 2017.

4. Starik, A. M., "Gaseous and particulate emissions with jet engine exhaust and atmospheric pollution," Advances on Propulsion Technology for High-Speed Aircraft, Vol. 15, 1-22, 2008.

5. Technical order 00-105E-9, Revision 11, Chapter 8, Aerospace Emergency Rescue and Mishap Response Information, F-16 aircraft danger areas, Engine Thrusts for F100-PW-229, http://www.0x4d.net/files/AF1/to00-105e-9.htm, 2006.

6. He, Liming, Yunwei Zhang, Hao Zeng, and Bingbing Zhao, "Research progress of microwave plasma ignition and assisted combustion," Chinese Journal of Aeronautics, Vol. 36, No. 12, 53-76, 2023.
doi:10.1016/j.cja.2023.04.029

7. Abu-Shady, M., Hijaz Ahmad, Hammad Alotaibi, and Ahmed Refaie Ali, "Investigating the fractional wave function and the impact of topological defects with anisotropic plasma on the dissociation of bottomonium in the fractional non-relativistic quark model," AIP Advances, Vol. 14, No. 4, 045011, 2024.
doi:10.1063/5.0179489

8. Chen, Victor C., D. Tahmoush, and William J. Miceli, Radar Micro-Doppler Signatures: Processing and Applications, IET, 2014.
doi:10.1049/PBRA034E

9. Stix, Thomas H., Waves in Plasmas, Chapter 1, Springer Science & Business Media, New York, 1992.

10. Kerker, M., The Scattering of Light and Other Electromagnetic Radiation, Elsevier, Jun. 2016.

11. Yang, Xiao-Jun, Abdulrahman Ali Alsolami, and Ahmed Refaie Ali, "An even entire function of order one is a special solution for a classical wave equation in one-dimensional space," Thermal Science, Vol. 27, No. 1B, 491-495, 2023.
doi:10.2298/tsci221111008y

12. Refaie Ali, Ahmed, Md. Nur Alam, and Mst. Wahida Parven, "Unveiling optical soliton solutions and bifurcation analysis in the space-time fractional Fokas-Lenells equation via SSE approach," Scientific Reports, Vol. 14, No. 1, 2000, 2024.
doi:10.1038/s41598-024-52308-9

13. Crispin, J. W. and K. M. Siegel, Methods of Radar Cross-Section Analysis, Chapter 4, Academic Press, New York, 1968.

14. Trott, Keith D., "Stationary phase derivation for RCS of an ellipsoid," IEEE Antennas and Wireless Propagation Letters, Vol. 6, 240-243, 2007.
doi:10.1109/lawp.2007.891521

15. https://militaryembedded.com/radar-ew/signal-processing/radar-cross-section-the-measure-of-stealth (F-22 RCS = 0.0001m2).

16. https://www.linkedin.com/posts/taits_it-is-amazing-that-an-f35-has-a-smaller-radar-activity-7265068792848756736-NKVU (F-35 RCS = 0.005 m², F-117 RCS = 0.003 m²).

17. https://www.globalsecurity.org/military/world/stealth-aircraft-rcs.htm (F-35 RCS = 0.005 m², F-117 RCS =0.003 m², F-22 RCS = 0.0001 m²).

18. Jones, Douglas Samuel, The Theory of Electromagnetism, 532, Pergamon Press, Oxford, 1964.

19. Jahnke, Eugene and Fritz Emde, Tables of Functions, Chapter VIII, Dover Pub., New York, 1945.

20. Roy, Amit Kaniyattu and V. S. Karthik, "A critical review of composite materials and stealth technology in modern aerospace engineering," Int. Jour. of Scientific and Research Publications, Vol. 14, No. 3, 185-193, Mar. 2024.
doi:10.29322/IJSRP.14.03.2024.p14720
