Abstract

In the manuscript a novel design of microstrip patch antenna with moderate degree of complexity is proposed in terms of metamaterial based unit cells as radiating patch on the top as well as metamaterial based periodic structure as defected ground structure at the bottom (MRPMGS) for Intelligent Transportation System (ITS) applications. The novel design of patch antenna exhibited multibands with broad-band transmission patterns, improved high gain and compact structure. The MRPMGS has a three layered structure with overall dimensions of 32 mm × 28 mm × 1.6 mm. The top layer with radiating patch has unit cell(s) with dimensions of 3.6 mm × 3.6 mm, and at the bottom the defective ground structure (DGS) has unit cell(s) with dimensions of 4 mm × 4 mm. The middle layer is of FR4 substrate with 1.6 mm thickness. The MRPMGS has experimental (simulated) transmission frequencies at 11.54 GHz (11.24 GHz), 12.91 GHz (12. 98 GHz), and 13.20 GHz (13.48 GHz) with reflection coefficients of -20.91 dB (-25.16 dB), -26.19 dB (-29.36 dB), and -18.94 dB (-26.02 dB) respectively. The VSWR varies between 1 and 3. The radiation efficiency reaches 80%, and high gain varying between 2.35 and 5.5 is achieved at the desired frequencies.

1. Gupta, Samir D. and M. C. Srivastava, "Design of frequency agile multidielectric microstrip antenna for airborne applications," International Journal of Microwave and Optical Technology (IJMOT), Vol. 5, No. 5, 257-266, 2010. Google Scholar

2. Wu, Junyan, Jiaao Yu, and Qin Tao, "Design of a missile-borne conformal microstrip navigation antenna," MATEC Web of Conferences, Vol. 232, 04080, 2018.
doi:10.1051/matecconf/201823204080

3. Chattha, Hassan T., Maria Hanif, Xiaodong Yang, Inam E. Rana, and Qammer H. Abbasi, "Frequency reconfigurable patch antenna for 4G LTE applications," Progress In Electromagnetics Research M, Vol. 69, 1-13, 2018.
doi:10.2528/pierm18022101 Google Scholar

4. Khattak, Muhammad Irfan, Amir Sohail, Ubaid Khan, Zaka Barki, and Gunawan Witjaksono, "Elliptical slot circular patch antenna array with dual band behaviour for future 5G mobile communication networks," Progress In Electromagnetics Research C, Vol. 89, 133-147, 2019.
doi:10.2528/pierc18101401 Google Scholar

5. Alieldin, Ahmed, Yi Huang, Stephen J. Boyes, and Manoj Stanley, "A reconfigurable broadband dual-mode dual-polarized antenna for sectorial/omnidirectional mobile base stations," Progress In Electromagnetics Research, Vol. 163, 1-13, 2018.
doi:10.2528/pier18050206 Google Scholar

6. Zhang, Q., W. Jiang, P. Liu, K. Wei, W. Hu, and S. Gong, "Metamaterial-based linear phased array antenna with improved wide-angle scanning bandwidth by parasitic metal strips," IET Microwaves, Antennas & Propagation, Vol. 15, 1699-1709, 2021. Google Scholar

7. Naik, Ketavath Kumar and Pasumarthi Amala Vijaya Sri, "Design of hexadecagon circular patch antenna with DGS at Ku band for satellite communications," Progress In Electromagnetics Research M, Vol. 63, 163-173, 2018.
doi:10.2528/pierm17092205 Google Scholar

8. Saroj, Abhishek Kumar, Mohd Gulman Siddiqui, Mukesh Kumar, and Jamshed Ansari, "Design of multiband quad-rectangular shaped microstrip antenna for wireless applications," Progress In Electromagnetics Research M, Vol. 59, 213-221, 2017.
doi:10.2528/pierm17071003 Google Scholar

9. Jabar, Ayia A. S. A. and Dhirgham Kamal Naji, "Design of miniaturized quad-band dual-arm spiral patch antenna for RFID, WLAN and WiMAX applications," Progress In Electromagnetics Research C, Vol. 91, 97-113, 2019.
doi:10.2528/pierc19011706 Google Scholar

10. Khajepour, Somayeh, Mohammad Saeid Ghaffarian, and Gholamreza Moradi, "Design of novel multiband folded printed quadrifilar helical antenna for GPS/WLAN applications," Electronics Letters, Vol. 53, No. 2, 58-60, 2017.
doi:10.1049/el.2016.3889 Google Scholar

11. Sun, Xin, Gang Zeng, Hong-Chun Yang, Yang Li, Xue-Jie Liao, and Lei Wang, "Design of an edge-fed quad-band slot antenna for GPS/WiMAX/WLAN applications," Progress In Electromagnetics Research Letters, Vol. 28, 111-120, 2012.
doi:10.2528/pierl11080407 Google Scholar

12. Yu, Junnan, Yufa Sun, Haoran Zhu, Fan Li, and Yade Fang, "Stacked-patch dual-band & dual-polarized antenna with broadband baluns for WiMAX & WLAN applications," Progress In Electromagnetics Research M, Vol. 68, 41-52, 2018.
doi:10.2528/pierm18022501 Google Scholar

13. Liu, Chi-Sheng, Cheng-Nan Chiu, and Sheng-Ming Deng, "A compact disc-slit monopole antenna for mobile devices," IEEE Antennas and Wireless Propagation Letters, Vol. 7, 251-254, 2008.
doi:10.1109/lawp.2008.920751 Google Scholar

14. Kishore, Nand, Arun Prakash, and Vijay Shanker Tripathi, "A reconfigurable ultra wide band antenna with defected ground structure for ITS application," AEU --- International Journal of Electronics and Communications, Vol. 72, 210-215, 2017.
doi:10.1016/j.aeue.2016.12.009 Google Scholar

15. Kishore, Nand, Gaurav Upadhyay, Vijay Shanker Tripathi, and Arun Prakash, "Dual band rectangular patch antenna array with defected ground structure for ITS application," AEU --- International Journal of Electronics and Communications, Vol. 96, 228-237, 2018.
doi:10.1016/j.aeue.2018.09.039 Google Scholar

16. Alqadami, Abdulrahman Shueai Mohsen, Mohd Faizal Jamlos, Imtiaz Islam, Ping Jack Soh, Rizalman Mamat, Khairil Anuar Khairi, and Adam Narbudowicz, "Multi-band antenna array based on double negative metamaterial for multi automotive applications," Progress In Electromagnetics Research, Vol. 159, 27-37, 2017.
doi:10.2528/pier16091203 Google Scholar

17. Mishra, Naveen and Raghvendra Kumar Chaudhary, "A compact CPW fed CRR loaded four element metamaterial array antenna for wireless application," Progress In Electromagnetics Research, Vol. 159, 15-26, 2017.
doi:10.2528/pier17021304 Google Scholar

18. Weng, Wei-Chung and Chia-Liang Hung, "An H-fractal antenna for multiband applications," IEEE Antennas and Wireless Propagation Letters, Vol. 13, 1705-1708, 2014.
doi:10.1109/lawp.2014.2351618 Google Scholar

19. Song, Zhi, Shucheng Zhao, Siqi Li, Jiayi Chen, and Yanbing Xue, "High-isolation compact MIMO antenna with distributed metamaterial loading," Progress In Electromagnetics Research M, Vol. 128, 51-59, 2024.
doi:10.2528/pierm24060507 Google Scholar

20. Naik, Ketavath Kumar, Gopi Dattatreya, Ramadugu P. S. Chaitanya, Ravikumar Palla, and Sriram Sandhya Rani, "Enhancement of gain with corrugated Y-shaped patch antenna for triple-band applications," International Journal of RF and Microwave Computer-Aided Engineering, Vol. 29, No. 3, e21624, 2019.
doi:10.1002/mmce.21624 Google Scholar

21. Mood, Yugender and Ramasamy Pandeeswari, "Complementary folded line metamaterial loaded MIMO antenna for S-band applications," Progress In Electromagnetics Research C, Vol. 150, 145-155, 2024.
doi:10.2528/pierc24060604 Google Scholar

22. Upadhyay, Gaurav, Nand Kishore, Saurabh Raj, Shivesh Tripathi, and Vijay Shanker Tripathi, "Dual-feed CSRR-loaded switchable multiband microstrip patch antenna for ITS applications," IET Microwaves, Antennas & Propagation, Vol. 12, No. 14, 2135-2140, 2018.
doi:10.1049/iet-map.2018.5269 Google Scholar

23. Kakhki, Mehri Borhani and Pejman Rezaei, "Reconfigurable microstrip slot antenna with DGS for UWB applications," International Journal of Microwave & Wireless Technologies, Vol. 9, No. 7, 1517-1522, 2017.
doi:10.1017/s1759078717000034 Google Scholar

24. Ziolkowski, Richard W. and Aycan Erentok, "Metamaterial-based efficient electrically small antennas," IEEE Transactions on Antennas and Propagation, Vol. 54, No. 7, 2113-2130, 2006.
doi:10.1109/tap.2006.877179 Google Scholar

25. Upadhyay, Kunal K., Alkesh Agrawal, and Mukul Misra, "Wide-band log-periodic microstrip antenna with defected ground structure for C-band applications," Progress In Electromagnetics Research C, Vol. 112, 127-137, 2021.
doi:10.2528/pierc21031106 Google Scholar

26. Veselago, V. G., "The electrodynamics of substances with simultaneously negative values of ε and µ," Soviet Physics Uspekhi, Vol. 10, No. 4, 509, 1968.
doi:10.1070/PU1968v010n04ABEH003699 Google Scholar

27. Pendry, J. B., A. J. Holden, D. J. Robbins, and W. J. Stewart, "Magnetism from conductors and enhanced nonlinear phenomena," IEEE Transactions on Microwave Theory and Techniques, Vol. 47, No. 11, 2075-2084, 1999.
doi:10.1109/22.798002 Google Scholar

28. Smith, D. R., Willie J. Padilla, D. C. Vier, S. C. Nemat-Nasser, and S. Schultz, "Composite medium with simultaneously negative permeability and permittivity," Physical Review Letters, Vol. 84, No. 18, 4184, 2000.
doi:10.1103/physrevlett.84.4184 Google Scholar

29. Selvi, Nambiyappan Thamil, Ramasamy Pandeeswari, and Palavesa Nadar Thiruvalar Selvan, "An inset-fed rectangular microstrip patch antenna with multiple split ring resonator loading for WLAN and RF-ID applications," Progress In Electromagnetics Research C, Vol. 81, 41-52, 2018.
doi:10.2528/pierc17110102 Google Scholar

30. Hassan, Khan Md. Zobayer, Nantakan Wongkasem, and Heinrich Foltz, "A Ka-band omnidirectional metamaterial-inspired antenna for sensing applications," Sensors, Vol. 25, No. 11, 3545, 2025.
doi:10.3390/s25113545 Google Scholar

31. Jackson, D. R. and N. G. Alexopoulos, "Simple approximate formulas for input resistance, bandwidth, and efficiency of a resonant rectangular patch," IEEE Transactions on Antennas and Propagation, Vol. 39, No. 3, 407-410, 1991.
doi:10.1109/8.76341 Google Scholar

32. Agrawal, Alkesh, Mukul Misra, and Ashutosh Singh, "Oblique incidence and polarization insensitive multiband metamaterial absorber with quad paired concentric continuous ring resonators," Progress In Electromagnetics Research M, Vol. 60, 33-46, 2017.
doi:10.2528/pierm17061302 Google Scholar

33. Tuloti, S. H. Ramazannia, P. Rezaei, and F. Tavakkol Hamedani, "Unit cell with flexible transmission phase slope for ultra-wideband transmitarray antennas," IET Microwaves, Antennas & Propagation, Vol. 13, No. 10, 1522-1528, 2019.
doi:10.1049/iet-map.2018.5288 Google Scholar

34. Tuloti, Seyed Hashem Ramazannia, Pejman Rezaei, and Farzad Tavakkol Hamedani, "High-efficient wideband transmitarray antenna," IEEE Antennas and Wireless Propagation Letters, Vol. 17, No. 5, 817-820, 2018.
doi:10.1109/lawp.2018.2817363 Google Scholar

35. Chandrasekhar, Maloth and Ketavath Kumar Naik, "Design a dual-band with CSRR cascaded patch antenna array for wireless communications," Progress In Electromagnetics Research C, Vol. 149, 155-163, 2024.
doi:10.2528/pierc24090602 Google Scholar

Dr. Sunil K. Dubey

Dr. Ashok Kumar Shankhwar

Dr. Nand Kishore

Dr. Alkesh Agrawal
