PIER Letters | PIER Journals

2026-09-17

PIER Letters

Vol. 131, 68-75, 2026

doi:10.2528/PIERL26071102

download: 105

Design of Triple-Band High-Absorption Electromagnetic Absorber Based on Bandpass Frequency-Selective Surface

Pengzhe Feng, Guang Chen, Dongxue Han and Yufeng Yu

This study proposes a triple-band high-efficiency electromagnetic absorber constructed using a lossy resonant layer, an air spacer, and a bandpass frequency-selective surface (FSS) boundary. The lossy layer adopts bent multi-section metal resonators loaded with two types of lumped resistors to generate a multi-band resonant loss, while the underlying slot-type bandpass FSS provides frequency-dependent boundary responses: it serves as a reflective boundary at the lower two absorption bands and couples with the top-layer resonance at the higher band, while retaining out-of-band transmission. The simulated results reveal effective absorption (absorptivity > 80%) at 5.2-6.1 GHz, 14.5-16.0 GHz, and 20.8-22.2 GHz, with peak absorptivities of 0.92, 1.00, and 0.97, respectively. Thanks to the centrosymmetric layout, the absorber is insensitive to TE/TM polarizations and maintains stable absorption up to 30° under oblique incidence. The operating frequencies can be flexibly tuned the via slot dimensions, metal line size, and resistance values. Due to its low profile and easy processing, the proposed design is suitable for stealth, radar cross-section reduction, and electromagnetic interference mitigation.

Design of Triple-Band High-Absorption Electromagnetic Absorber Based on Bandpass Frequency-Selective Surface

2026-09-05

PIER Letters

Vol. 131, 61-67, 2026

doi:10.2528/PIERL26061702

download: 249

Rectifier with Harmonic Communication for SWIPT Receiver Front-End of QFSK Modulation

Zhoulin Fan, Junfei Ji, Abubaker Ahmed Elobied, Fan Yu and Xuexia Yang

This paper proposes a compact harmonic communication rectifier for a simultaneous wireless information and power transfer (SWIPT) receiver front-end employing quadrature frequency-shift keying (QFSK) modulation. First, we theoretically analyzed the feasibility of communication using the second harmonic of QFSK signals. Second, a compact harmonic communication rectifier is proposed by combining a frequency-selective duplexer and an impedance-matching network. The duplexer with two output branches partially extracts the low-power second harmonic for communication and fully transmits the fundamental wave for wireless power transfer. The matching network with π-type can transmit the fundamental wave to the diode for rectification and adjust the energy-information power ratio for practical requirements. Finally, the proposed rectifier is fabricated and measured with good agreement between simulation and measurement results. A rectifying efficiency of 76.7% is achieved for QFSK-modulated waves with a carrier frequency of 2.5 GHz and a frequency offset of 20 MHz at an input power of 14 dBm. The extracted second-harmonic power is -5.3 dBm with an energy-to-information power ratio of 64:1. The signal-to-noise ratio (SNR) is 30 dB and the bit error rate (BER) is less than 10^-12.

Rectifier with Harmonic Communication for SWIPT Receiver Front-End of QFSK Modulation

2026-08-24

PIER Letters

Vol. 131, 55-60, 2026

doi:10.2528/PIERL26071703

download: 240

A Cross-Coupled SIW Filter with Quasi-Elliptic Response and Enhanced Stopband Suppression Using Opposite-Face GCPW Feeding

Daxue Liu, Liang Li, Darren Trofimczuk, Shunli Hong and Mingyu Cao

This letter presents a cross-coupled SIW filter with a quasi-elliptic response and improved stopband suppression. For cross-coupled SIW filters, suppressing spurious modes often requires rearranging feeding ports, but this rearrangement tends to increase port-to-port crosstalk and limit achievable out-of-band rejection. To address this inherent issue, we keep port positions unchanged and change the port configuration from conventional microstrip lines to an opposite-face GCPW feeding structure. The input and output ports are placed on opposite metal layers, with their ground planes separated by the dielectric substrate. Simulation results show that the port-to-port crosstalk is reduced from -25 to -40 dB to below -100 dB. Measured results show that the proposed filter maintains a similar stopband width as the previous design, while the suppression of the first spurious passband is improved by about 20 dB, reaching better than -50 dB. The improvement is achieved without hybrid structures or extra fabrication steps.

A Cross-Coupled SIW Filter with Quasi-Elliptic Response and Enhanced Stopband Suppression Using Opposite-Face GCPW Feeding

2026-08-22

PIER Letters

Vol. 131, 48-54, 2026

doi:10.2528/PIERL26042705

download: 174

Design and Fabrication of a Wideband, Low-Cost, Lightweight Open TEM Cell

Alireza Monirihamedani, Mohammad Reza Moniri Hamedani and Shiva Hayati Raad

In‎ this ‎paper, ‎ a low-cost, lightweight open ‎transverse electromagnetic (TEM) ‎cell with an operating bandwidth from DC up to around 1.5 GHz is‎ designed ‎and‎ fabricated‎. Initially, a fully metallic open cell is simulated, and associated TEM modes are exhibited by the spatial electric field distributions. The cell length (L_b), width (W_b), and height (H_b) are respectively 398, 200, and 103.93 mm. In the next step, a printed circuit board (PCB) is used as the septum to reduce the device's overall weight. Moreover, longitudinal slots are cut on both sides of the septum to prevent the transverse currents, which results in the excitation of higher-order modes. For further weight reduction, sub-wavelength slots are cut in the metallic sidewalls without affecting the overall performance. The metal filling factor reduction is of great importance for reaching a portable test facility with reduced cost. Finally, the device's input ports are further manipulated to reduce discontinuity by gradually tapering them. The device is realized by the combination of metal sheet, computer numerical control (CNC) water jet, machining, and PCB technologies. The measured scattering parameters confirm the acceptable performance of the fabricated device.

Design and Fabrication of a Wideband, Low-Cost, Lightweight Open TEM Cell

2026-08-14

PIER Letters

Vol. 131, 40-47, 2026

doi:10.2528/PIERL26061504

download: 267

A Flexible Passive Metasurface Reflector for Absorption, Linear-to-Linear, and Linear-to-Circular Polarization Conversion

Ke Wang, Haofei Zhang, Longsheng Li, Chunlei Xu, Yichao Zhou and Shijie Xie

A flexible multifunctional passive metasurface reflector is proposed, which integrates broadband absorption, linear-to-linear polarization conversion, and dual-band linear-to-circular polarization conversion on a single passive platform. The proposed unit cell consists of a circular split-ring resonator and X-shaped metallic patches loaded with lumped resistors. The metallic patterns were fabricated on a flexible polyimide (PI) substrate, followed by a polymethacrylimide (PMI) spacer layer and a metallic ground plane. Without employing any active components, the metasurface achieves an absorptivity higher than 90% over the 4.45-8.46 GHz band. In the 12.1-15.2 GHz frequency range, the polarization conversion ratio exceeds 90%, enabling efficient linear-to-linear polarization conversion. Furthermore, within the frequency bands of 16.5-17.3 GHz and 17.7-18.2 GHz, the proposed metasurface converts incident linearly polarized waves into right-handed circularly polarized (RHCP) and left-handed circularly polarized (LHCP) waves, respectively, while the output handedness can be interchanged by rotating the incident polarization by 90°. Conformal measurements demonstrate that the proposed metasurface maintains stable absorption performance under moderate bending, with only slight degradation in polarization conversion performance and a small frequency shift in the circular polarization conversion bands. Experimental measurements show good agreement with the simulated results, verifying the effectiveness of the proposed design. Owing to its simple configuration, low cost, multifunctional integration, and conformal capability, the proposed metasurface provides a promising solution for multifunctional electromagnetic manipulation in conformal integrated electromagnetic systems.

A Flexible Passive Metasurface Reflector for Absorption, Linear-to-Linear, and Linear-to-Circular Polarization Conversion

2026-08-07

PIER Letters

Vol. 131, 34-39, 2026

doi:10.2528/PIERL26052102

download: 359

Design of Broadband Gradient-Radius Magnetic Induction Antennas

Mingxuan Hu and Lihua Li

To address the challenge of limited bandwidth in magnetic induction communication, this study proposes a magnetic induction antenna adopted a gradient-radius structure. The antenna adopts a discretized gradient-radius design, which effectively broadens the system bandwidth by increasing the antenna's resistance-to-inductance ratio. The study integrates theoretical analysis, simulation, and experimental testing to systematically investigate the effects of different taper ratio structures on resistance, inductance, and bandwidth. Experimental results demonstrated that the gradient-radius structure can significantly extend the bandwidth, and the extension effect became stronger as the taper ratio increased. Meanwhile, combined with simulation and experimental data, the attenuation effect of this structure on the near-zone magnetic field was evaluated, verifying that the bandwidth improvement came at the cost of coupling strength. Specifically, when the bandwidth was extended to nearly twice its original value, the received signal strength decreased by approximately 6.4 dBm. This study provides a simple and practical implementation approach for the broadband design of magnetic induction communication systems.

Design of Broadband Gradient-Radius Magnetic Induction Antennas

2026-07-11

PIER Letters

Vol. 131, 26-33, 2026

doi:10.2528/PIERL26041807

download: 328

Front-to-Back Ratio Improvement of Wideband Circularly Polarized Antenna with Tilted-Slot Fences

Bei-Wen Lin, Tian-Yuan Gao and Rui Wu

This paper presents a wideband circularly polarized (CP) antenna featuring a significantly enhanced front-to-back ratio (FBR). The proposed design employs a composite structure that integrates a dipole with a loop resonator and is fabricated using a multilayer architecture. The top layer is a dielectric substrate loaded with a cyclic zigzag patch. The middle layer contains an L-shaped radiating patch with etched rectangular grooves, and the bottom layer comprises a metal ground plane and surrounding vertically tilted-slot fences. Circular polarization is achieved by exciting orthogonal degenerate modes via strategic rectangular-groove perturbations that work in concert with the loop resonator's inherent asymmetric current path. The tilted-slot fences, in conjunction with the zigzag patch layer, function collectively to suppress backward radiation and improve the FBR. Measured results demonstrate that the antenna achieves a 3 dB axial ratio (AR) bandwidth of 54% from 2.45 to 4.3 GHz, a stable FBR of more than 27.5 dB with 2.5 dB variation, and a peak gain of 9.3 dBic. This design offers a high-performance, planar antenna solution well-suited for satellite communication and radar systems.

Front-to-Back Ratio Improvement of Wideband Circularly Polarized Antenna with Tilted-Slot Fences

2026-07-06

PIER Letters

Vol. 131, 18-25, 2026

doi:10.2528/PIERL26040203

download: 432

A High-Reliability Fiber-Optic Transmission System with Hybrid Power Supply

Lichao Zhang, Zheng Sun, Qi Zhang and Lihua Shi

Conventional fiber-optic measurement systems for pulsed electromagnetic fields are limited by power-supply instability due to the temperature sensitivity of photocells. To address this issue, we developed a highly reliable broadband fiber-optic transmission system featuring a hybrid power supply. In our design, a lithium battery serves as the primary power source for the optical transmitter, while a compact photocell provides short-term supplemental power and simultaneously recharges the battery. An additional shunt resistor (5-50 Ω) is added to avoid damping oscillations. Results: The system achieves a -3 dB bandwidth from 5 Hz to 122 MHz. The optical transmitter volume is reduced to one-fifth of a previous design. Ten repeated electric-field measurements show relative errors below 3%. Conclusion: The proposed system offers stable operation, low power consumption, wide dynamic range, and strong anti-interference capability, making it well-suited for harsh electromagnetic environments.

A High-Reliability Fiber-Optic Transmission System with Hybrid Power Supply

2026-06-05

PIER Letters

Vol. 131, 9-17, 2026

doi:10.2528/PIERL26041704

download: 424

A Compact Four-Port Circularly Polarized MIMO Antenna Using a Polarization Conversion Superstrate

Jingchang Nan, Siyao Zhao and Yifei Wang

A compact four-port circularly polarized multiple-input multiple-output (CP-MIMO) antenna with a dual-layer architecture is proposed for low-altitude communication applications. In compact MIMO arrays of CP-capable monopole elements, strong mutual coupling makes stable CP radiation difficult to achieve. To address this issue, the proposed antenna uses a lower layer for dual-polarized MIMO generation and an upper layer for polarization conversion. The antenna is fabricated on two FR-4 substrates with an overall size of 0.85λ × 0.85λ × 0.084λ. In the lower layer, a dual-polarized feed backplane (DPFB) forms a ±45° dual-polarized MIMO array with port isolation exceeding 17 dB. In the upper layer, a polarization conversion superstrate (PCS) converts the incident dual-polarized waves into CP radiation. The PCS extends the impedance bandwidth by 36%, from 7.55 to 10.08 GHz, and enables LHCP radiation with a 3 dB AR bandwidth of 8.22-8.89 GHz. A gain enhancement of 48% is also achieved. Measured results verify the design and show good MIMO diversity performance.

A Compact Four-Port Circularly Polarized MIMO Antenna Using a Polarization Conversion Superstrate

2026-05-17

PIER Letters

Vol. 131, 1-8, 2026

doi:10.2528/PIERL26021601

download: 466

Terahertz Wave Shielding of Carbon Nanotube-Organic Silicone

Jin-Rong Li, Jiu-Sheng Li and Ri-Hui Xiong

We have developed a carbon nanotube organic silicone rubber (CNT-OSR) composite medium, composed of methyl trifluoropropyl silicone rubber as the matrix, with different mass fractions of carbon nanotubes added and formed through vulcanization using a bis (cyclopentadiene) vulcanizing agent. The CNT-OSR composite media with carbon nanotube contents of 2wt%, 5wt%, and 8wt% were tested, and the maximum absorption and shielding efficiencies of the media for terahertz waves in the 0.5-1.0 THz frequency range were found to be 69.77 dB, 76.28 dB, and 63.69 dB, respectively. Through impedance matching theory analysis, the absorption and shielding effectiveness of the medium for terahertz waves were confirmed. Additionally, the composite medium exhibits excellent hydrophobic properties. It provides a simple and feasible approach for developing lightweight, efficient, and multifunctional terahertz wave absorbing and shielding materials for the next generation of terahertz wireless communication.
