Abstract

A reactive power shielding structure working under 150 kHz for small electronic equipment was proposed to reduce the electromagnetic leakage of WPT system. First, the model of LCC-LCC compensation circuit was established. By ensuring transmission efficiency, a comprehensive analysis of nine sets of computational data results was conducted to select the scheme with the best shielding effect. The experimental results showed that the magnetic flux density attenuation was 27.82% at 41 mm transmission distance from the center under the optimal structure of 3 rings and 7 turns, inner diameter of 23 mm and outer diameter of 35 mm. The transmission efficiency can reach 76.73%, which is only 1.32% lower than the situation without shielding. The proposed reactive power shielding structure can significantly reduce the magnetic flux density in the external area of the WPT system without affecting the transmission efficiency of the system.

1. Yang, Deliang, Guoliang Xing, Jun Huang, Xiangmao Chang, and Xiaofan Jiang, "QID: Robust mobile device recognition via a multi-coil qi-wireless charging system," ACM Transactions on Internet of Things, Vol. 3, No. 2, 1-27, 2022.

2. Halimi, Md. Ahsan, Taimoor Khan, Nasimuddin, Ahmed A. Kishk, and Yahia M. M. Antar, "Rectifier circuits for RF energy harvesting and wireless power transfer applications: A comprehensive review based on operating conditions," IEEE Microwave Magazine, Vol. 24, No. 1, 46-61, 2023.

3. Deng, Shuai, Qi Zhang, Zheming Zhuang, Chengcheng Xu, Yuntao Guan, and Jiansheng Dai, "Design and model of a car based on wireless charging," 2022 6th International Conference on Robotics and Automation Sciences (ICRAS), 196-199, IEEE, 2022.

4. Kuang, Ronny JD, Janu Pirakalathanan, Theodore Lau, Daniel Koh, Emily Kotschet, Brian Ko, and Kenneth K. Lau, "An up-to-date review of cardiac pacemakers and implantable cardioverter defibrillators," Journal of Medical Imaging and Radiation Oncology, Vol. 65, No. 7, 896-903, 2021.

5. Wang, Guang-bo, Xiu-Wei Xuan, Dao-Lian Jiang, Kun Li, and Wei Wang, "A miniaturized implantable antenna sensor for wireless capsule endoscopy system," AEU --- International Journal of Electronics and Communications, Vol. 143, 154022, 2022.

6. Setayeshfar, Omid, Karthika Subramani, Xingzi Yuan, Raunak Dey, Dezhi Hong, Kyu Hyung Lee, and In Kee Kim, "ChatterHub: Privacy invasion via smart home hub," 2021 IEEE International Conference on Smart Computing (SMARTCOMP), 181-188, IEEE, 2021.

7. Lv, Si, Zhinong Wei, Guoqiang Sun, Sheng Chen, and Haixiang Zang, "Power and traffic nexus: From perspective of power transmission network and electrified highway network," IEEE Transactions on Transportation Electrification, Vol. 7, No. 2, 566-577, 2021.

8. Dong, Shen, Qiu Dongyuan Du Guiping, and others, "Research status and development trend of electromagnetic compatibility of wireless power transmission system," Transactions of China Electrotechnical Society, Vol. 35, No. 13, 2855-2869, 2020.

9. Chen, J. and Z. Liu, "Research on multi coil reactive shielding of resonant wireless energy supply cardiac pacemaker," Transaction of China Electrotechnical Society, Vol. 37, No. 11, 2673-2685, 2022.

10. Lu, Conghui, Xiutao Huang, Xiong Tao, Cancan Rong, and Minghai Liu, "Comprehensive analysis of side-placed metamaterials in wireless power transfer system," IEEE Access, Vol. 8, 152900-152908, 2020.

11. Rong, Cancan, Conghui Lu, Yingqin Zeng, Xiong Tao, Xiaobo Liu, Renzhe Liu, Xiangrui He, and Minghai Liu, "A critical review of metamaterial in wireless power transfer system," IET Power Electronics, Vol. 14, No. 9, 1541-1559, 2021.

12. Zhou, Jiafeng, Pei Zhang, Jiaqi Han, Long Li, and Yi Huang, "Metamaterials and metasurfaces for wireless power transfer and energy harvesting," Proceedings of the IEEE, Vol. 110, No. 1, 31-55, 2022.
doi:10.1109/JPROC.2021.3127493

13. Rong, Cancan, Lihui Yan, Long Li, Yunhui Li, and Minghai Liu, "A review of metamaterials in wireless power transfer," Materials, Vol. 16, No. 17, 6008, 2023.

14. Campi, Tommaso, Silvano Cruciani, Francescaromana Maradei, and Mauro Feliziani, "Magnetic field mitigation by multicoil active shielding in electric vehicles equipped with wireless power charging system," IEEE Transactions on Electromagnetic Compatibility, Vol. 62, No. 4, 1398-1405, 2020.

15. Li, Jiacheng, Xueliang Huang, Chen Chen, Linlin Tan, Wei Wang, and Jinpeng Guo, "Effect of metal shielding on a wireless power transfer system," AIP Advances, Vol. 7, No. 5, 056675, 2017.

16. He, Xiangrui, Yingqin Zeng, Renzhe Liu, Conghui Lu, Cancan Rong, and Minghai Liu, "A dual-band coil array with novel high-order circuit compensation for shielding design in EV wireless charging system," IEEE Transactions on Industrial Electronics, Vol. 71, No. 3, 2545-2555, 2024.

17. Li, Yanling, Kaiwen Xie, Yangjiang Ying, and Zhonggui Li, "An improved hybrid shielding with LC coil for wireless power transfer system," IEEE Transactions on Electromagnetic Compatibility, Vol. 64, No. 3, 720-731, 2022.

18. Kim, Jedok and Seungyoung Ahn, "Dual loop reactive shield application of wireless power transfer system for leakage magnetic field reduction and efficiency enhancement," IEEE Access, Vol. 9, 118307-118323, 2021.

19. Mi, Mingfa, Qingxin Yang, Yongjian Li, Pengcheng Zhang, and Wenting Zhang, "Multi-objective active shielding coil design for wireless electric vehicle charging system," IEEE Transactions on Magnetics, Vol. 58, No. 2, 1-5, 2022.

20. Cruciani, Silvano, Tommaso Campi, Francescaromana Maradei, and Mauro Feliziani, "Active shielding design for wireless power transfer systems," IEEE Transactions on Electromagnetic Compatibility, Vol. 61, No. 6, 1953-1960, 2019.

21. Park, Jaehyoung, Chanjun Park, Yujun Shin, Dongwook Kim, Bumjin Park, Jaeyong Cho, Junsung Choi, and Seungyoung Ahn, "Planar multiresonance reactive shield for reducing electromagnetic interference in portable wireless power charging application," Applied Physics Letters, Vol. 114, No. 20, 203902, 2019.
