The Finite Element Method for the Spatially-Variant Lattice Algorithm for Volumes and Doubly-Curved Surfaces
By
Progress In Electromagnetics Research M, Vol. 134, 47-57, 2025
Abstract
A 2D flat, 2D curved, and 3D finite element method (FEM) implementation of the spatially-variant lattice (SVL) algorithm is presented. This powerful algorithm is used in electromagnetics to preserve the electromagnetic properties and geometry of periodic structures that are bent, twisted, conformed, or otherwise spatially varied. Applications of the SVL algorithm include photonic crystals, metamaterials, conformal frequency selective surfaces, cloaking devices, and volumetric circuits over complex geometries. The present work shows examples of SVLs over a planar surface lattice, a doubly-curved surface lattice, and a volumetric lattice.
Citation
Edgar Bustamante, and Raymond C. Rumpf, "The Finite Element Method for the Spatially-Variant Lattice Algorithm for Volumes and Doubly-Curved Surfaces," Progress In Electromagnetics Research M, Vol. 134, 47-57, 2025.
doi:10.2528/PIERM25021203
