Abstract

Microwave heating, widely employed in the food industry, offers significant advantages due to its volumetric heating capabilities. However, its efficiency is often hindered by non-uniform heating patterns. This study aims to analyse heating patterns in a rectangular, single-fed domestic microwave oven, leveraging cost-effective methodologies. Theoretical analyses, electromagnetic simulations, and experimental measurements were conducted to characterise the resonant modes within an empty cavity and with a load. The mathematical computation of multiple mode superposition within the cavity was performed for two domestic microwave ovens. Mathematical and experimental analyses demonstrate a close agreement in results. The findings reveal that mode distribution, influenced by cavity dimensions, load properties, load placement, and magnetron characteristics, significantly impacts heating patterns. This study helps us understand that in spite of the dynamic nature of magnetron, it is important to superimpose multiple resonant modes prevalent within the cavity to understand influences on microwave heating pattern of any food materials.
