Abstract

This paper presents a compact, low-cost, frequency-domain bistatic radar system using two identical square microstrip patch antennas fabricated on an FR-4 substrate (εr = 4.4, thickness = 1.6 mm). The antenna incorporates a suspended air-gap configuration to enhance bandwidth and radiation efficiency, and is designed to resonate near 3.3 GHz. The antenna was designed and optimised using CST Microwave Studio and experimentally validated using a Vector Network Analyser (VNA). Simulation results demonstrate a peak gain of 6.6 dBi and radiation efficiency of 83.2%. The fabricated antenna exhibits a measured peak gain of 7.0 dBi at 3.23 GHz and a |S₁₁| ≤ −10 dB bandwidth from approximately 3.0 to 3.5 GHz, with a measured resonance minimum of −14.3 dB at 3.27 GHz. The bistatic radar system operates over a swept frequency range of 2.8 to 3.8 GHz, acquiring complex S₂₁ parameters at each discrete frequency step. The received S₂₁ data is processed using background subtraction to suppress antenna coupling and background clutter, followed by an Inverse Fast Fourier Transform (IFFT) for range-domain target localisation. The proposed system is experimentally validated in single-target and multiple-target scenarios. Closely spaced targets are further characterised using a CLEAN iterative deconvolution algorithm as a post-processing step. Consistent target localisation across all scenarios is confirmed by two-dimensional radar images obtained from cross-range scanning. The results demonstrate the feasibility of a low-cost bistatic radar platform for short-range sensing applications including security scanning, remote target localisation, and multi-target detection

1. Saeidi, Tale, Adam R. H. Alhawari, Abdulkarem H. M. Almawgani, Turki Alsuwian, Muhammad Ali Imran, and Qammer Abbasi, "High gain compact UWB antenna for ground penetrating radar detection and soil inspection," Sensors, Vol. 22, No. 14, 5183, Jul. 2022.
doi:10.3390/s22145183 Google Scholar

2. Acar, Yunus Emre, Ismail Saritas, and Ercan Yaldiz, "An S-band zero-IF SFCW through-the-wall radar for range, respiration rate, and DOA estimation," Measurement, Vol. 186, 110221, Dec. 2021.
doi:10.1016/j.measurement.2021.110221 Google Scholar

3. Kozlov, Roman, Konstantin Gavrilov, Timofey Shevgunov, and Vladimir Kirdyashkin, "Stepped-frequency continuous-wave signal processing method for human detection using radars for sensing rooms through the wall," Inventions, Vol. 7, No. 3, 79, Sep. 2022.
doi:10.3390/inventions7030079 Google Scholar

4. Kocur, Dušan, Mária Švecová, and Jana Rovňáková, "Through-the-wall localization of a moving target by two independent ultra wideband (UWB) radar systems," Sensors, Vol. 13, No. 9, 11969-11997, Sep. 2013.
doi:10.3390/s130911969 Google Scholar

5. Šipoš, Danijel and Dušan Gleich, "SFCW radar with an integrated static target echo cancellation system," Sensors, Vol. 21, No. 17, 5829, Aug. 2021.
doi:10.3390/s21175829 Google Scholar

6. Hu, Zhipeng, Zhaofa Zeng, Kun Wang, Weike Feng, Jianmin Zhang, Qi Lu, and Xiaoqian Kang, "Design and analysis of a UWB MIMO radar system with miniaturized Vivaldi antenna for through-wall imaging," Remote Sensing, Vol. 11, No. 16, 1867, Aug. 2019.
doi:10.3390/rs11161867 Google Scholar

7. Jia, Yong, Yong Guo, Chao Yan, Haoxuan Sheng, Guolong Cui, and Xiaoling Zhong, "Detection and localization for multiple stationary human targets based on cross-correlation of dual-station SFCW radars," Remote Sensing, Vol. 11, No. 12, 1428, Jun. 2019.
doi:10.3390/rs11121428 Google Scholar

8. Tahar, Ziani, Xavier Dérobert, and Malek Benslama, "An ultra-wideband modified Vivaldi antenna applied to through the ground and wall imaging," Progress In Electromagnetics Research C, Vol. 86, 111-122, 2018.
doi:10.2528/pierc18051502 Google Scholar

9. Li, Zhi, Tian Jin, Yongpeng Dai, and Yongkun Song, "Through-wall multi-subject localization and vital signs monitoring using UWB MIMO imaging radar," Remote Sensing, Vol. 13, No. 15, 2905, Jul. 2021.
doi:10.3390/rs13152905 Google Scholar

10. Rittiplang, Artit and Pattarapong Phasukkit, "1-Tx/5-Rx through-wall UWB switched-antenna-array radar for detecting stationary humans," Sensors, Vol. 20, No. 23, 6828, Nov. 2020.
doi:10.3390/s20236828 Google Scholar

11. Li, Xinhui, Shengbo Ye, Zihao Wang, Yubing Yuan, Xiaojun Liu, Guangyou Fang, and Deyun Ma, "A compact stepped frequency continuous waveform through-wall radar system based on dual-channel software-defined radio," Electronics, Vol. 14, No. 3, 527, Jan. 2025.
doi:10.3390/electronics14030527 Google Scholar

12. Prakasam, V., P. Sandeep, and K. R. Anudeep LaxmiKanth, "Design and analysis of rectangular microstrip patch antenna for 2.4 GHz wireless communication applications using CST microwave studio," Computer Networks and Inventive Communication Technologies, Vol. 58, 1113-1125, Springer, Singapore, 2021.
doi:10.1007/978-981-15-9647-6_89

13. Youssef, Amraoui, Imane Halkhams, Rachid El Alami, Mohammed Ouazzani Jamil, and Hassan Qjidaa, "Study and design of a microstrip patch antenna array for 2.4 GHz applications," International Conference on Digital Technologies and Applications, Vol. 668, 309-317, Springer, Cham, 2023.
doi:10.1007/978-3-031-29857-8_31

14. Kafedziski, Venceslav and Sinisha Pecov, "Implementation of a high resolution stepped frequency radar on a USRP," 2017 13th International Conference on Advanced Technologies, Systems and Services in Telecommunications (TELSIKS), 236-239, Nis, Serbia, 2017.
doi:10.1109/TELSKS.2017.8246271

15. Ehrnsperger, Matthias G., Maximilian Noll, Uwe Siart, and Thomas F. Eibert, "Background and clutter removal techniques for ultra short range radar," 2020 17th European Radar Conference (EuRAD), 78-81, Utrecht, Netherlands, Jan. 2021.
doi:10.1109/EuRAD48048.2021.00031

16. Freedman, Avraham, Ranjan Bose, and Bernard D. Steinberg, "Techniques to improve the CLEAN deconvolution algorithm," Journal of the Franklin Institute, Vol. 332, No. 5, 535-553, Sep. 1995.
doi:10.1016/0016-0032(95)00079-8 Google Scholar

17. Bose, R., A. Freedman, and B. D. Steinberg, "Sequence CLEAN: A modified deconvolution technique for microwave images of contiguous targets," IEEE Transactions on Aerospace and Electronic Systems, Vol. 38, No. 1, 89-97, Jan. 2002.
doi:10.1109/7.993231 Google Scholar

18. Bose, Ranjan, "Lean CLEAN: Deconvolution algorithm for radar imaging of contiguous targets," IEEE Transactions on Aerospace and Electronic Systems, Vol. 47, No. 3, 2190-2199, Jul. 2011.
doi:10.1109/taes.2011.5937291 Google Scholar

19. Chen, Xingyu, Chen Yao, Guoqiang Zhao, and Hao Liu, "An improved CLEAN algorithm for multi-target detection in LFM pulse radar," IET International Radar Conference (IRC 2023), Vol. 2023, 1858-1863, Chongqing, China, Dec. 2023.
doi:10.1049/icp.2024.1367

Dr. Ankita Malhotra

Dr. Priyal Veera

Dr. Aryan Bhalkar

Dr. Rajiv Datta

Dr. Shubham Tayade

Professor Amit A. Deshmukh
