Abstract

In this paper, a compact ultra-wideband (UWB) bandpass filter (BPF) with triple-notch bands (TNBs) is proposed and demonstrated. We present a cross-shaped anti-shorted coupled-line structure employing a single coupled multi-mode resonator (MMR), whose resonant characteristics and intrinsic transmission zeros are investigated by employing the even-odd mode analysis method. In addition, the three notch bands are generated from the resonator's intrinsic transmission zeros without requiring any additional notch circuits. At the same time, their center frequencies can be quasi-independently controlled by properly adjusting the microstrip electrical lengths. For demonstration, the proposed filter is designed, fabricated, and measured. Simulated and measured results are in good agreement. The measured results agree well with theoretical predictions, which exhibit superior performance, such as triple-notch bands, high skirt selectivity, an ultra-wide passband from 2.8 to 12.5 GHz with a fractional bandwidth of 138%, a compact size of only 7.7 mm × 9.2 mm, and effective notched-band suppression levels.
