Abstract

To address the challenges of coordinating local reactive power compensation with cross-station harmonic interaction suppression in hybrid multi-infeed HVDC (HMIDC) systems, this study proposes an optimal AC filter configuration method based on sensitivity analysis. A harmonic impedance equivalent model was established for a hybrid three-infeed HVDC system, and a comprehensive harmonic interaction index was constructed based on harmonic current interaction influence coefficients. Normalized sensitivity analysis was then performed on the AC filter impedance, receiving-end AC system impedance, and tie-line impedance at the 11th and 13th harmonics. The results indicate that the AC filter impedance serves as the dominant adjustable factor. On this basis, a discrete optimization model was developed, with the number of DT11/24 and DT13/36 double-tuned filter groups in service as decision variables. In addition, this model considers equipment limits, minimum filtering requirements, reactive power compensation, and harmonic voltage constraints. Case study results show that the optimized configuration reduces the overall harmonic coupling among HVDC infeed systems; in particular, the interaction strength from the second conventional HVDC link to the modular multilevel converter-based high-voltage direct current (MMC-HVDC) link at the 13th harmonic decreases by approximately 32%. The proposed method provides a practical reference for coordinated AC filter switching in HMIDC.
