Abstract

This paper presents a compact 39 × 39 mm² quad-port ultra-wideband (UWB) MIMO antenna with dual band-notches and enhanced inter-element isolation. Four orthogonally arranged microstrip-fed circular radiators are employed to reduce mutual coupling, while two U-shaped slots etched on each radiator suppress interference from the C-band (3.1-4.3 GHz) and Wireless LAN (5.2-5.6 GHz) bands. We investigate the antenna using Characteristic Mode Analysis through modal significance and modal current distributions. The proposed diversity antenna is evaluated using envelope correlation coefficient, diversity gain, total active reflection coefficient, channel capacity loss, multiplexing efficiency, and simulated group delay. The antenna achieves an impedance spectrum covering 2.9-10.6 GHz, radiation efficiency of 90%, gain of 5.2 dBi, ECC < 0.02, and isolation of -20 dB. The results demonstrate that the proposed antenna provides an effective combination of small size and high isolation, making it viable for UWB applications.

1. Win, M. Z. and R. A. Scholtz, "Ultra-wide bandwidth time-hopping spread-spectrum impulse radio for wireless multiple-access communications," IEEE Transactions on Communications, Vol. 48, No. 4, 679-689, Apr. 2000.
doi:10.1109/26.843135 Google Scholar

2. Ghavami, M., L. Michael, and R. Kohno, Ultra Wideband Signals and Systems in Communication Engineering, John Wiley & Sons, 2007.
doi:10.1002/9780470060490

3. Schantz, Hans G., The Art and Science of Ultra-Wideband Antennas, Artech House, Norwood, MA, USA, 2005.

4. Balanis, C. A., Antenna Theory: Analysis and Design, 4th Ed., Wiley, Hoboken, NJ, USA, 2016.

5. Taylor, James D., Introduction to Ultra-Wideband Radar Systems, CRC Press, 1994.

6. Qu, S.-W., J.-L. Li, and Q. Xue, "A band-notched ultrawideband printed monopole antenna," IEEE Antennas and Wireless Propagation Letters, Vol. 5, 495-498, 2006.
doi:10.1109/lawp.2006.886303 Google Scholar

7. Zhang, Yan, Wei Hong, Chen Yu, Zhen-Qi Kuai, Yu-Dan Don, and Jian-Yi Zhou, "Planar ultrawideband antennas with multiple notched bands based on etched slots on the patch and/or split ring resonators on the feed line," IEEE Transactions on Antennas and Propagation, Vol. 56, No. 9, 3063-3068, Sep. 2008.
doi:10.1109/tap.2008.928815 Google Scholar

8. Li, Wen Tao, Xiao Wei Shi, and Yong Qiang Hei, "Novel planar UWB monopole antenna with triple band-notched characteristics," IEEE Antennas and Wireless Propagation Letters, Vol. 8, 1094-1098, 2009.
doi:10.1109/lawp.2009.2033449 Google Scholar

9. Liu, Xiang Long, Ying-Zeng Yin, Ping An Liu, Jun Hui Wang, and Bin Xu, "A CPW-fed dual band-notched UWB antenna with a pair of bended dual-L-shape parasitic branches," Progress In Electromagnetics Research, Vol. 136, 623-634, 2013.
doi:10.2528/pier12122507 Google Scholar

10. Zhu, Fuguo, Steven Gao, Anthony T. S. Ho, Raed A. Abd-Alhameed, Chan H. See, Tim W. C. Brown, Jianzhou Li, Gao Wei, and Jiadong Xu, "Multiple band-notched UWB antenna with band-rejected elements integrated in the feed line," IEEE Transactions on Antennas and Propagation, Vol. 61, No. 8, 3952-3960, Aug. 2013.
doi:10.1109/tap.2013.2260119 Google Scholar

11. Ojaroudi, M., G. Ghanbari, N. Ojaroudi, and C. Ghobadi, "Small square monopole antenna for UWB applications with variable frequency band-notch function," IEEE Antennas and Wireless Propagation Letters, Vol. 8, 1061-1064, 2009.
doi:10.1109/lawp.2009.2030697 Google Scholar

12. Ojaroudi, Mohammad and Nasser Ojaroudi, "Ultra-wideband small rectangular slot antenna with variable band-stop function," IEEE Transactions on Antennas and Propagation, Vol. 62, No. 1, 490-494, 2014.
doi:10.1109/tap.2013.2287703 Google Scholar

13. Wang, Qiang and Yan Zhang, "Design of a compact UWB antenna with triple band-notched characteristics," International Journal of Antennas and Propagation, Vol. 2014, No. 1, 892765, 2014.
doi:10.1155/2014/892765 Google Scholar

14. Liang, Jianxin, C. C. Chiau, Xiaodong Chen, and C. G. Parini, "Study of a printed circular disc monopole antenna for UWB systems," IEEE Transactions on Antennas and Propagation, Vol. 53, No. 11, 3500-3504, Nov. 2005.
doi:10.1109/tap.2005.858598 Google Scholar

15. Ma, Tzyh-Ghuang and Shyh-Kang Jeng, "Planar miniature tapered-slot-fed annular slot antennas for ultrawide-band radios," IEEE Transactions on Antennas and Propagation, Vol. 53, No. 3, 1194-1202, Mar. 2005.
doi:10.1109/tap.2004.842648 Google Scholar

16. Azim, Rezaul, Mohammad Tariqul Islam, and Norbahiah Misran, "Compact tapered-shape slot antenna for UWB applications," IEEE Antennas and Wireless Propagation Letters, Vol. 10, 1190-1193, 2011.
doi:10.1109/lawp.2011.2172181 Google Scholar

17. Liu, Ying, Zhe Chen, and Shuxi Gong, "Triple band-notched aperture UWB antenna using hollow-cross-loop resonator," Electronics Letters, Vol. 50, No. 10, 728-730, May 2014.
doi:10.1049/el.2013.4256 Google Scholar

18. Cai, L. Y., Y. Li, G. Zeng, and H. C. Yang, "Compact wideband antenna with double-fed structure having band-notched characteristics," Electronics Letters, Vol. 46, No. 23, 1534-1536, Nov. 2010.
doi:10.1049/el.2010.2574 Google Scholar

19. Liu, J., S. Gong, Y. Xu, X. Zhang, C. Feng, and N. Qi, "Compact printed ultra-wideband monopole antenna with dual band-notched characteristics," Electronics Letters, Vol. 44, No. 12, 710-711, 2008.
doi:10.1049/el:20080931 Google Scholar

20. Ding, Jiechen, Zhili Lin, Zhinong Ying, and Sailing He, "A compact ultra-wideband slot antenna with multiple notch frequency bands," Microwave and Optical Technology Letters, Vol. 49, No. 12, 3056-3060, 2007.
doi:10.1002/mop.22892 Google Scholar

21. Molisch, A. F., Wireless Communications, 2nd Ed., Wiley, Hoboken, NJ, USA, 2011.

22. Tse, D. and P. Viswanath, Fundamentals of Wireless Communication, Cambridge University Press, Cambridge, U.K., 2005.

23. Larsson, Erik G., Ove Edfors, Fredrik Tufvesson, and Thomas L. Marzetta, "Massive MIMO for next generation wireless systems," IEEE Communications Magazine, Vol. 52, No. 2, 186-195, Feb. 2014.
doi:10.1109/mcom.2014.6736761 Google Scholar

24. Sharawi, Mohammad S., Printed MIMO Antenna Engineering, Artech House, MA, USA, 2014.

25. Sharawi, Mohammad S., "Current misuses and future prospects for printed multiple-input, multiple-output antenna systems [wireless corner]," IEEE Antennas and Propagation Magazine, Vol. 59, No. 2, 162-170, Apr. 2017.
doi:10.1109/map.2017.2658346 Google Scholar

26. Blanch, S., J. Romeu, and I. Corbella, "Exact representation of antenna system diversity performance from input parameter description," Electronic Letters, Vol. 39, No. 9, 705-707, May 2003.
doi:10.1049/el:20030495 Google Scholar

27. Zhang, Shuai and Gert Frølund Pedersen, "Mutual coupling reduction for UWB MIMO antennas with a wideband neutralization line," IEEE Antennas and Wireless Propagation Letters, Vol. 15, 166-169, 2016.
doi:10.1109/lawp.2015.2435992 Google Scholar

28. Li, Jian-Feng, Qing-Xin Chu, Zhi-Hui Li, and Xing-Xing Xia, "Compact dual band-notched UWB MIMO antenna with high isolation," IEEE Transactions on Antennas and Propagation, Vol. 61, No. 9, 4759-4766, Sep. 2013.
doi:10.1109/tap.2013.2267653 Google Scholar

29. Iqbal, Amjad, Omar A. Saraereh, Amal Bouazizi, and Abdul Basir, "Metamaterial-based highly isolated MIMO antenna for portable wireless applications," Electronics, Vol. 7, No. 10, 267, 2018.
doi:10.3390/electronics7100267 Google Scholar

30. Singh, Harsh Verdhan and Shrivishal Tripathi, "Compact UWB MIMO antenna with cross-shaped unconnected ground stub using characteristic mode analysis," Microwave and Optical Technology Letters, Vol. 61, No. 7, 1874-1881, Jul. 2019.
doi:10.1002/mop.31792 Google Scholar

31. Wong, Hang, Kwai-Man Luk, Chi Hou Chan, Quan Xue, Kwok Kan So, and Hau Wah Lai, "Small antennas in wireless communications," Proceedings of the IEEE, Vol. 100, No. 7, 2109-2121, Jul. 2012.
doi:10.1109/jproc.2012.2188089 Google Scholar

32. Wong, Kin-Lu, Chih-Yu Tsai, and Jun-Yu Lu, "Two asymmetrically mirrored gap-coupled loop antennas as a compact building block for eight-antenna MIMO array in the future smartphone," IEEE Transactions on Antennas and Propagation, Vol. 65, No. 4, 1765-1778, 2017.
doi:10.1109/tap.2017.2670534 Google Scholar

33. Chen, Yikai and Chao-Fu Wang, Characteristic Modes: Theory and Applications in Antenna Engineering, John Wiley & Sons, Hoboken, NJ, USA, 2015.

34. Harrington, R. and J. Mautz, "Theory of characteristic modes for conducting bodies," IEEE Transactions on Antennas and Propagation, Vol. 19, No. 5, 622-628, Sep. 1971.
doi:10.1109/tap.1971.1139999 Google Scholar

35. Cabedo-Fabres, Marta, Eva Antonino-Daviu, Alejandro Valero-Nogueira, and Miguel Ferrando Bataller, "The theory of characteristic modes revisited: A contribution to the design of antennas for modern applications," IEEE Antennas and Propagation Magazine, Vol. 49, No. 5, 52-68, Oct. 2007.
doi:10.1109/map.2007.4395295 Google Scholar

36. Zhang, Qianyun, Runbo Ma, Wei Su, and Yue Gao, "Design of a multimode UWB antenna using characteristic mode analysis," IEEE Transactions on Antennas and Propagation, Vol. 66, No. 7, 3712-3717, Jul. 2018.
doi:10.1109/tap.2018.2835370 Google Scholar

37. Zhang, Qianyun and Yue Gao, "Compact low-profile UWB antenna with characteristic mode analysis for UHF TV white space devices," IET Microwaves, Antennas & Propagation, Vol. 11, No. 11, 1629-1635, Aug. 2017.
doi:10.1049/iet-map.2016.0993 Google Scholar

38. Wu, Weixia and Y. P. Zhang, "Analysis of ultra-wideband printed planar quasi-monopole antennas using the theory of characteristic modes," IEEE Antennas and Propagation Magazine, Vol. 52, No. 6, 67-77, Dec. 2010.
doi:10.1109/map.2010.5723225 Google Scholar

39. Kumar, Praveen, Tanweer Ali, Sameena Pathan, Krishnamurthy Nayak, Taimoor Khan, Ahmed A. Kishk, et al. "A quad port dual band notch UWB MIMO antenna using hybrid decoupling structure," Results in Engineering, Vol. 23, 102551, 2024.
doi:10.1016/j.rineng.2024.102551 Google Scholar

40. Kumar, Praveen, Tanweer Ali, and Manohara M. M. Pai, "A compact highly isolated two- and four-port ultrawideband Multiple Input and Multiple Output antenna with wireless LAN and X-band notch characteristics based on Defected Ground Structure," International Journal of Communication Systems, Vol. 35, No. 17, e5331, 2022.
doi:10.1002/dac.5331 Google Scholar

41. Modak, Sumon, Taimoor Khan, Tayeb A. Denidni, and Yahia M. M. Antar, "Miniaturized self-isolated UWB MIMO planar/cuboidal antenna with dual X-band interference rejection," AEU --- International Journal of Electronics and Communications, Vol. 143, 154020, 2022.
doi:10.1016/j.aeue.2021.154020 Google Scholar

42. Sushma, Thotakura, Rajesh Gogineni, Nallagonda Vijaya Ratnam, Sadineni Ramesh Babu, Sunitha Mandava, and Paruchuri Venkata Krishna Kanth, "A miniaturized quad port highly isolated triple band notched UWB-MIMO diversity antenna," Progress In Electromagnetics Research C, Vol. 152, 43-53, 2025.
doi:10.2528/pierc24111702 Google Scholar

43. Thotakura, Haritha, Rajesh Gogineni, K. Srinivasa Rao, Chunduri Kiran Kumar, Ramesh Babu Sadineni, and Sunitha Mandava, "A miniaturized highly isolated two port triple band-notched UWB MIMO antenna verified by characteristic mode analysis," Progress In Electromagnetics Research C, Vol. 160, 133-142, 2025.
doi:10.2528/pierc25082303 Google Scholar

Dr. Sunitha Mandava

Dr. Thotakura Sushma

Dr. Rajesh Gogineni

Dr. Chunduri Kiran Kumar

Dr. Ramesh Babu Sadineni

Dr. Veeravalli Ramakoteswara Rao
