Abstract

This paper presents a four-port quarter-mode substrate integrated waveguide (QMSIW) MIMO antenna designed for 2.1 GHz wireless applications. The antenna employs orthogonally positioned complementary square-split ring resonator slots to achieve substantial miniaturization. Additionally, mutual coupling between the antenna elements is effectively minimized by incorporating cross-shaped slots between them, enhancing overall performance. The proposed four-port MIMO antenna achieves high isolation of 40 dB and features a compact electrical size of 0.19λ₀ × 0.19λ₀. The antenna demonstrates outstanding MIMO performance, with simulated and measured gains of 5.32 dBi and 5.44 dBi, respectively. Its efficiency is further supported by key performance metrics, including a low envelope correlation coefficient (ECC) of 0.0841 and a high diversity gain (DG) of 9.22 dB, ensuring enhanced signal reliability and reduced interference. With its compact structure, excellent isolation, and strong diversity performance, the proposed antenna serves as a highly suitable candidate for directional Wi-Fi applications.
