Abstract

In this paper, a compact quad-port Rhombus-Shaped MIMO Patch (RSMP) antenna with a complete ground structure has been designed for dual-band wireless applications. The RSMP antenna has a common patch configuration and resonates at 12.9 GHz and 16.5 GHz with the reflection coefficients of -17 dB and -25.7 dB, respectively. A rhombus-shaped slot is etched from the patch to generate dual-band frequencies. Microstrip feed lines are connected to the common patch and are used to improve the overall performance of the RSMP antenna. The RSMP antenna has gains of 9.62 dBi and 9.98 dBi at resonating frequencies. The bandwidths of the proposed MIMO antenna model are 300 MHz and 350 MHz, respectively. The proposed RSMP antenna model was fabricated and tested with the vector network analyzer Keysight N9917A for validation. The simulated and measured results for the gain, reflection coefficients, surface current distribution, radiation pattern, envelope correlation coefficient (ECC), diversity gain (DG), total active reflection coefficient (TARC), and channel capacity loss (CCL) are compared, and they are agreed well for wireless applications at Ku-band for broadcasting communications.

1. Kong, Lingyu and Xiaojian Xu, "A compact dual-band dual-polarized microstrip antenna array for MIMO-SAR applications," IEEE Transactions on Antennas and Propagation, Vol. 66, No. 5, 2374-2381, May 2018.
doi:10.1109/TAP.2018.2814222 Google Scholar

2. Lee, S. W. and Y. J. Sung, "Reconfigurable rhombus-shaped patch antenna with Y-shaped feed for polarization diversity," IEEE Antennas and Wireless Propagation Letters, Vol. 14, 163-166, 2015.
doi:10.1109/LAWP.2014.2358651 Google Scholar

3. Sharma, Narinder and Sumeet Singh Bhatia, "Ultra-wideband fractal antenna using rhombus shaped patch with stub loaded defected ground plane: Design and measurement," AEU - International Journal of Electronics and Communications, Vol. 131, 153604, Mar. 2021.
doi:10.1016/j.aeue.2021.153604 Google Scholar

4. Saravanan, Manavalan and Madihally Janardhana Srinivasa Rangachar, "Design of rhombus-shaped slot patch antenna for wireless communications," Journal of Computer Networks and Communications, Vol. 2019, 5149529, 2019.
doi:10.1155/2019/5149529 Google Scholar

5. Liu, Shengying, Kaibo Jiang, Guobing Xu, Xumin Ding, Kuang Zhang, Jiahui Fu, and Qun Wu, "A dual-band shared aperture antenna array in Ku/Ka-bands for beam scanning applications," IEEE Access, Vol. 7, 78794-78802, 2019.
doi:10.1109/ACCESS.2019.2922647 Google Scholar

6. Tang, Hong, Cory J. Bulger, Tom Rovere, Bowen Zheng, Sensong An, Hang Li, Yunxi Dong, Mohammad Haerinia, Clayton Fowler, Stephen Gonya, Wei Guo, and Hualiang Zhang, "A low-profile flexible dual-band antenna with quasi-isotropic radiation patterns for MIMO system on UAVs," IEEE Antennas and Wireless Propagation Letters, Vol. 22, No. 1, 49-53, Jan. 2023.
doi:10.1109/LAWP.2022.3201492 Google Scholar

7. Cheng, Bo and Zhengwei Du, "A wideband low-profile microstrip MIMO antenna for 5G mobile phones," IEEE Transactions on Antennas and Propagation, Vol. 70, No. 2, 1476-1481, Feb. 2022.
doi:10.1109/TAP.2021.3111330 Google Scholar

8. Ambalgi, Ambresh P., S. K. Sujata, and Arti Vaish, "Experimental and simulation study of effects in etched patch antenna with multi slots," WSEAS Transactions on Communications, Vol. 19, 142-148, 2020.
doi:10.37394/23204.2020.19.16 Google Scholar

9. Pasumarthi, Srinivasa Rao, Jagadeesh Babu Kamili, and Mallikarjuna Prasad Avala, "Design of dual band MIMO antenna with improved isolation," Microwave and Optical Technology Letters, Vol. 61, No. 6, 1579-1583, Jun. 2019.
doi:10.1002/mop.31832 Google Scholar

10. Wang, Hongwei, Ruiheng Zhang, Yong Luo, and Guangli Yang, "Compact eight-element antenna array for triple-band MIMO operation in 5G mobile terminals," IEEE Access, Vol. 8, 19433-19449, 2020.
doi:10.1109/ACCESS.2020.2967651 Google Scholar

11. Chattha, Hassan Tariq, Muhammad Kamran Ishfaq, Bilal A. Khawaja, Abubakar Sharif, and Nathirulla Sheriff, "Compact multiport MIMO antenna system for 5G IoT and cellular handheld applications," IEEE Antennas and Wireless Propagation Letters, Vol. 20, No. 11, 2136-2140, Nov. 2021.
doi:10.1109/LAWP.2021.3059419 Google Scholar

12. Li, Zhenya, Chengyou Yin, and Xiaosong Zhu, "Compact UWB MIMO Vivaldi antenna with dual band-notched characteristics," IEEE Access, Vol. 7, 38696-38701, 2019.
doi:10.1109/ACCESS.2019.2906338 Google Scholar

13. Choi, Jaehyun, Woonbong Hwang, Chisang You, Byungwoon Jung, and Wonbin Hong, "Four-element reconfigurable coupled loop MIMO antenna featuring LTE full-band operation for metallic-rimmed smartphone," IEEE Transactions on Antennas and Propagation, Vol. 67, No. 1, 99-107, Jan. 2019.
doi:10.1109/TAP.2018.2877299 Google Scholar

14. Ikram, Muhammad, Emad Al Abbas, Nghia Nguyen-Trong, Khalil H. Sayidmarie, and Amin Abbosh, "Integrated frequency-reconfigurable slot antenna and connected slot antenna array for 4G and 5G mobile handsets," IEEE Transactions on Antennas and Propagation, Vol. 67, No. 12, 7225-7233, Dec. 2019.
doi:10.1109/TAP.2019.2930119 Google Scholar

15. Desai, Arpan, Jayshri Kulkarni, M. M. Kamruzzaman, Štěpán Hubálovský, Heng-Tung Hsu, and Ahmed A. Ibrahim, "Interconnected CPW fed flexible 4-port MIMO antenna for UWB, X, and Ku band applications," IEEE Access, Vol. 10, 57641-57654, 2022.
doi:10.1109/ACCESS.2022.3179005 Google Scholar

16. Dey, Soumik, Sukomal Dey, and Shiban K. Koul, "Isolation improvement of MIMO antenna using novel EBG and hair-pin shaped DGS at 5G millimeter wave band," IEEE Access, Vol. 9, 162820-162834, 2021.
doi:10.1109/ACCESS.2021.3133324 Google Scholar

17. Hannan, Saif, Mohammad Tariqul Islam, Norsuzlin Mohd Sahar, Kamarulzaman Mat, Muhammad E. H. Chowdhury, and Hatem Rmili, "Modified-segmented split-ring based polarization and angle-insensitive multi-band metamaterial absorber for X, Ku and K band applications," IEEE Access, Vol. 8, 144051-144063, 2020.
doi:10.1109/ACCESS.2020.3013011 Google Scholar

18. Yang, Wan Jun, Yong Mei Pan, and Shao Yong Zheng, "Mutual coupling reduction in CP MIMO crossed-dipole antenna array," IEEE Antennas and Wireless Propagation Letters, Vol. 21, No. 12, 2442-2446, Dec. 2022.
doi:10.1109/LAWP.2022.3196371 Google Scholar

19. Krishna, O. N. V. R. and K. Kumar Naik, "Analysis of triangular antenna with two annular rings for multi-band applications," Journal of Critical Reviews, Vol. 7, No. 4, 189-191, 2020. Google Scholar

20. Amala Vijaya Sri, P., G. Srikanth, B. Vamsi Krishna, K. Kousalya, S. Rama Lavanya, K. Ooha, R. P. S. Chaitanya, B. Kalyan Kumar, K. Y. Srinivas, and K. Kumar Naik, "Enhancement of gain with coplanar isosceles triangular patch antenna for dual-band applications," 2017 Progress In Electromagnetics Research Symposium - Fall (PIERS - FALL), 2981-2984, Singapore, Nov. 2017.
