Abstract

In this manuscript, a miniaturized Multi-Input Multi-Output (MIMO) antenna with dual-notch characteristics is designed for Ultra-Wideband (UWB) indoor positioning system. The proposed UWB MIMO antenna has a compact size of 35*35 mm² with four orthogonally placed antenna elements on the print circuit board (PCB) with FR4. Each radiating element utilizes the combination of a rectangle and an irregular pentagon, and etches two inverted L-shaped slits to generate two notches in WLAN (5.00 GHz-5.82 GHz) and X-band (7.11 GHz-8.20 GHz). On the grounding planes, the rectangle grounding units are modified into L-shaped branches, on which stepped open-circuit slots and right-angled triangle truncations are etched to broaden the impedance bandwidth. Furthermore, three equidistant rectangular decoupling slits are etched to improve the isolation. The measured results are in good agreement with the simulated ones, which shows an impedance bandwidth of 116.68% (2.96-11.25 GHz) with isolation better than 17 dB. The antenna also has excellent characteristics of good radiation characteristics, total active reflection coefficient (TARC), diversity gain (DG>9.99), low envelope correlation coefficient (ECC<0.005) and channel capacity loss (CCL<0.4 bits/sec/Hz), which can be used in portable UWB-MIMO indoor positioning system.

1. Gigl, T., G. J. M. Janssen, V. Dizdarevic, et al. "Analysis of a UWB indoor positioning system based on received signal strength," Workshop on Positioning IEEE, 97-101, Hannover, 2007. Google Scholar

2. Mahato, S., S. Modak, T. Khan, et al. "Triple notched-band slots-loaded arrow-head shaped UWB monopole antenna," Advanced Communication Technologies and Signal Processing (ACTS), 1-4, Silchar, 2020. Google Scholar

3. Li, W. A., Z. H. Tu, Q. X. Chu, et al. "Differential stepped-slot UWB antenna with common-mode suppression and dual sharp-selectivity notched bands," IEEE Antennas and Wireless Propagation Letters, Vol. 15, 1120-1123, 2016.
doi:10.1109/LAWP.2015.2496159 Google Scholar

4. Kang, L., H. Li, X. Wang, et al. "Compact offset microstrip-fed MIMO antenna for band-notched UWB applications," IEEE Antennas and Wireless Propagation Letters, Vol. 14, 1754-1757, 2015.
doi:10.1109/LAWP.2015.2422571 Google Scholar

5. Rahman, M. U., A. Haider, and M. Naghshvarianjahromi, "A systematic methodology for the time-domain ringing reduction in UWB band-notched antennas," IEEE Antennas and Wireless Propagation Letters, Vol. 19, No. 3, 482-486, 2020.
doi:10.1109/LAWP.2020.2972025 Google Scholar

6. Liu, Y. Y. and Z. H. Tu, "Compact differential band-notched stepped-slot UWB-MIMO antenna with common-mode suppression," IEEE Antennas and Wireless Propagation Letters, Vol. 16, 593-596, 2017.
doi:10.1109/LAWP.2016.2592179 Google Scholar

7. Abbas, A., N. Hussain, J. Lee, et al. "Triple rectangular notch UWB antenna using EBG and SRR," IEEE Access, Vol. 9, No. 99, 2508-2515, 2020. Google Scholar

8. Sanyal, R., A. Patra, P. P. Sarkar, et al. "Compact UWB monopole antenna with 3.5/ 5.5 GHz enhanced dual band rejection characteristics," Microwave and Optical Technology Letters, Vol. 57, No. 11, 2693-2699, 2015.
doi:10.1002/mop.29406 Google Scholar

9. Jafri, S. I., R. Saleem, and K. Khokhar, "CPW-fed UWB antenna with tri-band frequency notch functionality," Applied Computational Electromagnetics Society Journal, Vol. 34, No. 9, 1274-1279, 2019. Google Scholar

10. Huang, H., Y. Liu, S. Zhang, et al. "Uniplanar differentially driven ultrawideband polarization diversity antenna with band-notched characteristics," IEEE Antennas and Wireless Propagation Letters, Vol. 14, No. 3, 563-566, 2015.
doi:10.1109/LAWP.2014.2374332 Google Scholar

11. Tang, Z., X. Wu, J. Zhan, et al. "Compact UWB-MIMO antenna with high isolation and triple band-notched characteristics," IEEE Access, Vol. 7, No. 62, 19856-19865, 2019.
doi:10.1109/ACCESS.2019.2897170 Google Scholar

12. Raheja, D. K., S. Kumar, and B. K. Kanaujia, "Compact quasi-elliptical-self-complementary four-port super-wideband MIMO antenna with dual band elimination characteristics," AEU - International Journal of Electronics and Communications, Vol. 114, 153001, 2020.
doi:10.1016/j.aeue.2019.153001 Google Scholar

13. Tan, X., W. Wang, Y. Wu, et al. "Enhancing isolation in dual-band meander-line multiple antenna by employing split EBG structure," IEEE Transactions on Antennas and Propagation, Vol. 67, No. 4, 2769-2774, 2019.
doi:10.1109/TAP.2019.2897489 Google Scholar

14. Chaabane, A. and F. Djahli, "A compact planar UWB antenna with triple controllable band-notched characteristics," International Journal of Antennas and Propagation, Vol. 2014, 1-10, 2015. Google Scholar

15. Sultan, K. S., O. Dardeer, and H. A. Mohamed, "Design of compact dual notched self-complementary UWB antenna," Open Journal of Antennas & Propagation, Vol. 5, No. 3, 99-109, 2017.
doi:10.4236/ojapr.2017.53008 Google Scholar

16. Xu, J. M., C. Z. Du, G. Y. Jin, et al. "A coplanar feed quad-band notched UWB antenna," International Workshop on Electromagnetics: Applications and Student Innovation Competition (iWEM), 1-2, Qingdao, 2019. Google Scholar

17. Li, Z., C. Yin, and X. Zhu, "Compact UWB MIMO vivaldi antenna with dual band-notched characteristics," IEEE Access, Vol. 7, No. 99, 38696-38701, 2019.
doi:10.1109/ACCESS.2019.2906338 Google Scholar

18. Elkazmi, E., C. H. See, N. A. Jan, et al. "Design of a wideband printed MIMO monopole antenna using neutralisation lines technique," Asia-Pacific Microwave Conference, 983-985, Sendai, 2014. Google Scholar

19. Raheja, D. K., B. K. Kanaujia, and S. Kumar, "Compact four-port MIMO antenna on slotted-edge substrate with dual-band rejection characteristics," International Journal of RF and Microwave Computer-Aided Engineering, Vol. 29, No. 7, 1-10, 2019.
doi:10.1002/mmce.21756 Google Scholar

20. Selvan, K., R. Sampath, and A. A. Arulraj, "Isolation improvement of UWB MIMO antenna utilizing molecule fractal structure," Electronics Letters, Vol. 10, No. 55, 576-579, 2019. Google Scholar

21. Khan, A. A., S. A. Naqvi, M. S. Khan, and B. Ijaz, "Quad port miniaturized MIMO antenna for UWB 11 GHz and 13 GHz frequency bands," AEU - International Journal of Electronics and Communications, Vol. 131, 153618, 2021.
doi:10.1016/j.aeue.2021.153618 Google Scholar

22. Kamel, S. S. and H. H. Abdullah, "Planar UWB MIMO-diversity antenna with dual notch characteristics," Progress In Electromagnetics Research C, Vol. 93, 119-129, 2019. Google Scholar

23. Tiwaria, R. N., P. Singh, B. K. Kanaujia, and K. Srivastava, "Neutralization technique based two and four port high isolation MIMO antennas for UWB communication," AEU-International Journal of Electronics and Communications, Vol. 110, Article 152828, July 2019. Google Scholar

24. Naktong, W. and A. Ruengwaree, "Four-port rectangular monopole antenna for UWB-MIMO applications," Progress In Electromagnetics Research B, Vol. 87, 19-38, 2020.
doi:10.2528/PIERB19102902 Google Scholar

25. Deepika, S., et al., "Compact planar 2×2 and 4×4 UWB MIMO antenna arrays for portable wireless devices," Microwave and Optical Technology Letters, Vol. 60, No. 1, 86-92, 2017. Google Scholar

26. Ali, W. and A. A. Ibrahim, "A compact double-sided MIMO antenna with an improved isolation for UWB applications," AEU - International Journal of Electronics and Communications, Vol. 82, 7-13, 2017.
doi:10.1016/j.aeue.2017.07.031 Google Scholar

27. Wang, L., Z. Du, H. Yang, et al. "Compact UWB MIMO antenna with high isolation using fence-type decoupling structure," IEEE Antennas and Wireless Propagation Letters, Vol. 18, No. 8, 1641-1645, 2019.
doi:10.1109/LAWP.2019.2925857 Google Scholar

28. Alfakhri, A., M. A. Ashraf, A. Alasaad, et al. "A compact size ultra wideband MIMO antenna with simple decoupling structure," International Symposium on Antenna Technology & Applied Electromagnetic, 1-2, Montreal, QC, 2016. Google Scholar

29. Wu, W., B. Yuan, and A. Wu, "A quad-element UWB-MIMO antenna with band-notch and reduced mutual coupling based on EBG structures," International Journal of Antennas and Propagation, Vol. 25, No. 2, 1-10, 2018. Google Scholar

Dr. Xuan Lu

Ms. Shushu Linghu

Dr. Furong Peng

Dr. Ting Zhang
