The electromagnetic scattering from a 2D chiral circular cylinders, illuminated by either a TEz or a TMz plane wave, is investigated using an iterative scattering procedure. The developed formulation and the implemented code simulate different types of cylinders, where the cylinders can be made of anisotropic chiral material with uniform or non-uniform chiral admittance distribution, homogeneous isotropic dielectric material, perfectly conducting material or a combination of all of them. The technique applies the boundary conditions on the surface of each cylinder in an iterative procedure in order to solve for the field expansion coefficients. Numerical verifications are presented to prove the validity of the formulation before presenting the scattering from an array of chiral cylinders showing significant RCS reduction in forward or backward directions based on the selection of the chirality parameter.
1. Al-Kanhal, M. A. and E. Arvas, "Electromagnetic scattering from a chiral cylinder of arbitrary cross section," IEEE Trans. Antennas Propagat., Vol. AP-44, No. 7, 1996.
2. Engheta, N. and D. L. Jaggard, "Electromagnetic chirality and its applications," IEEE Antennas Propagat. Soc. Newsletter, Vol. 30, No. 5, 6-12, 1988.
3. Mahmoud, S. F., "Mode characteristics in chirowaveguides with constant impedance walls," Journal of Electromagnetic Waves and Applications (JEMWA), Vol. 6, 625-640, 1992.
4. Mahmoud, S. F., "Characteristics of a chiral coated slotted cylindrical antenna," IEEE Trans. Antennas Propagat., Vol. AP- 44, No. 6, 814-821, 1996. doi:10.1109/8.509885
5. Graglia, R. D., P. L. E. Uslenghi, and C. L. Yu, "Electromagnetic oblique scattering by a cylinder coated with chiral layers and anisotropic jump-admittance sheets," Journal of Electromagnetic Waves and Applications (JEMWA), Vol. 6, 625-719, 1992.
6. Elsherbeni, A. Z., M. Hamid, and G. Tian, "Iterative scattering of a gaussian beam by an array of circular conducting and dielectric cylinders," Journal of Electromagnetic Waves and Applications (JEMWA), Vol. 7, No. 10, 1323-1342, 1993.
7. Hamid, A.-K., I. R. Ciric, and M. Hamid, "Iterative technique for scattering by a linear array of spheres," IEEE Antennas Propagat. Soc. Int. Symp., Vol. 1, No. 6, 30-33, 1991.
8. Hamid, A.-K., I. R. Ciric, and M. Hamid, Iterative solution of the scattering by an arbitrary configuration of conducting or dielectric spheres, IEE Proc. Microwave, Vol. 1, No. 6, 565-572, 1991.
9. Kluskens, M. S. and E. H. Newman, "Scattering by a chiral cylinder of arbitrary cross section," IEEE Trans. Antennas Propagat., Vol. AP- 38, No. 9, 1990.
10. Elsherbeni, A. Z., "A Comparative study of two-dimensional multiple scattering techniques," Radio Science, Vol. 29, No. 4, 1023-1033, 1994. doi:10.1029/94RS00327
