A Novel Dual-Band Reconfigurable Square-Ring Microstrip Antenna
Majeed Alkanhal and Abdel Sheta
A novel compact dual-band reconfigurable square-ring microstrip antenna is presented. The tuning is achieved using a single varactor diode connected to a small square patch attached to an inner corner of the square-ring. The square patch perturbs the symmetry and splits the two degenerate modes to create dual-band operation. The frequency ratio in the range of 1.04 to 1.4 can be achieved by the proper selection of the square patch size. The lower resonance frequency can be further decreased by loading the square patch at its corner by a reverse biased varactor diode. The diode has almost no effect on the upper resonance frequency. This technique is used to implement an electronically tunable dual-band antenna on FR4 material with εr = 4.5 and 1.5mm thickness. The size of the ring,the square patch,and the varactor used,are selected to yield a fixed upper resonance frequency at about 1.93 GHz. The resulting lower resonance frequency is tuned from 1.37 to 1.7 GHz in the voltage range from 0 to 30 V,resp ectively. The measurements agree well with simulation
A NOVEL DUAL-BAND RECONFIGURABLE SQUARE-RING MICROSTRIP ANTENNA
2007-02-15
PIER
Vol. 70, 329-336, 2007
download: 235
Multiband CPW-Fed Triangle-Shaped Monopole Antenna for Wireless Applications
Yue Song , Yong-Chang Jiao , Gang Zhao and Fu-Shun Zhang
A multiband CPW-fed triangle-shaped monopole antenna for wireless applications covering 2.4- and 5 GHz WLAN bands and 3.4 GHz WIMAX band in IEEE 802.16 is proposed. Prototype of the proposed antenna have been constructed and tested. The experimental results show that the antenna can provide two separate impedance bandwidths of 140MHz (about 5.8% centered at 2.43 GHz) and 3100MHz (about 61.4% centered at 4.91 GHz), which meet the required bandwidths specification of 2.4/5 GHz WLAN and 3.4 GHz WIMAX standard. Good omnidirectional radiation in the desired frequency bands has been achieved. The proposed antenna with relatively low profile is suitable for multiband wireless applications.
MULTIBAND CPW-FED TRIANGLE-SHAPED MONOPOLE ANTENNA FOR WIRELESS APPLICATIONS
2007-02-14
PIER
Vol. 70, 307-328, 2007
download: 193
Model Computations of Angular Power Spectra for Anisotropic Absorptive Turbulent Magnetized Plasma
George Jandieri , Akira Ishimaru , Vakhtang Jandieri , A. Khantadze and Zh. Diasamidze
Electromagnetic waves scattering in turbulent anisotropic collision magnetized ionospheric plasma is investigated using complex geometrical optics approximation. Correlation function of the phase fluctuations of scattered radiation is obtained taking into account both electron density and magnetic fields fluctuations. The features of the angular power spectrum of scattered radiation are investigated analytically and numerically. The expressions of broadening of the spatial spectrum have been obtained for both powerlaw and anisotropic Gaussian correlation functions of electron density fluctuations. Gaussian spectral function takes into account the axial ratio of the field-aligned irregularities and the angle of inclination of prolate irregularities with respect to the external magnetic field. The variance of the phase and scintillation level of scattered radiation are calculated numerically for F-region irregularities of the ionosphere. The conditions of non-fully and fully developed diffraction patterns have been determined.
MODEL COMPUTATIONS OF ANGULAR POWER SPECTRA FOR ANISOTROPIC ABSORPTIVE TURBULENT MAGNETIZED PLASMA
2007-02-14
PIER
Vol. 70, 297-306, 2007
download: 508
Analysis and Design of Multiple-Band Bandstop Filters
Shihu Han , Xi-Liang Wang and Yong Fan
A new transversal coupling network is proposed to design of multiple-band bandstop filters. The resonators in the proposed transversal coupling network have a few of center frequencies and some of them have similar or the same resonating frequency to realize multiple-band bandstop suppression, which are applied to reject pulse signals or bandwidth signals in broadband technique applications. A triple-band bandstop filter is designed by adopting substrate integrated waveguide to demonstrate the feasibility of this proposed network.
ANALYSIS AND DESIGN OF MULTIPLE-BAND BANDSTOP FILTERS
2007-02-09
PIER
Vol. 70, 281-296, 2007
download: 187
A Comparison of Marching-on in Time Method with Marching-on in Degree Method for the TDIE Solver
Baek-Ho Jung , Zhong Ji , Tapan Kumar Sarkar , Magdalena Salazar-Palma and Mengtao Yuan
One of the most popular methods to solve a time-domain integral equation (TDIE) is the marching-on in time (MOT) method. Recently, a new method called marching-on in degree (MOD) that uses Laguerre polynomials as temporal basis functions has been developed to eliminate the late time instability of the MOT method. The use of an entire domain basis for the time variable eliminates the requirement of a Courant condition, as there is no time variable involved in the field calculation. This is possible as in the procedure the time and the space variables can be separated analytically. A comparison is presented between these two methods from the standpoint of formulation, stability, cost, and accuracy. Numerical results are presented to illustrate these features in the comparison.
A COMPARISON OF MARCHING-ON IN TIME METHOD WITH MARCHING-ON IN DEGREE METHOD FOR THE TDIE SOLVER
2007-02-08
PIER
Vol. 70, 269-280, 2007
download: 412
Lowpass Filter Design of Hilbert Curve Ring Defected Ground Structure
Jun Chen , Zi-Bin Weng , Yong-Chang Jiao and Fu-Shun Zhang
Abstract-In this paper,a novel Hilbert curve ring (HCR) fractal defected ground structure (DGS) and its equivalent circuit are investigated. Furthermore,an improved HCR DGS cell model with open stubs loaded on the conductor line is then presented to improve the out-band suppression. By employing three cascaded improved HCR DGS cells,an L-band microstrip low-pass is designed and fabricated. This lowpass filter achieves a quite steep rejection property; a low in-band insertion loss of below 0.5 dB and a high out-band suppression of more than 33 dB.
LOWPASS FILTER DESIGN OF HILBERT CURVE RING DEFECTED GROUND STRUCTURE
2007-02-04
PIER
Vol. 70, 257-267, 2007
download: 178
Counter-Propagating Energy-Flows in Nonlinear Left-Handed Metamaterials
Liang Chen , Wei Ding , Xiao-Jie Dang and Chang-Hong Liang
A peculiarity of counter-propagating energy-flows in nonlinear left-handed metamaterials (LHMs) is investigated for the case when the frequency of fundamental wave is in the negativeindex range and second-harmonic wave is in the positive-index range. Based on the electromagnetic theory,the comparisons of Manly-Rowe relations for nonlinear materials and process of secondharmonic generation under phase-matching condition in LHMs and RHMs are shown separately. That a surface of nonlinear left-handed metamaterials operates as an effective mirror which reflects the energy in form of second harmonics is demonstrated. Numerical results of fundamental and second-harmonic field intensity distributions are in agreement with theoretical results.
COUNTER-PROPAGATING ENERGY-FLOWS IN NONLINEAR LEFT-HANDED METAMATERIALS
2007-02-08
PIER
Vol. 70, 247-256, 2007
download: 239
Permeability Measurement of Ferromagnetic Materials in Microwave Frequency Range Using Support Vector Machine Regression
Yunqiu Wu , Zong-Xi Tang , Biao Zhang and Yuehang Xu
A newmetho d based on supported vector regression (SVR) approach is proposed for permeability measurement. The microstrip transmission-line is used as measurement cell, and supported vector machine (SVM) is introduced to extract permeability of ferromagnetic materials. Experiment results showthat thanks to SVM's good ability of generalization, permeability of ferromagnetic materials can be extracted accurately and easily.
PERMEABILITY MEASUREMENT OF FERROMAGNETIC MATERIALS IN MICROWAVE FREQUENCY RANGE USING SUPPORT VECTOR MACHINE REGRESSION
2007-01-31
PIER
Vol. 70, 225-246, 2007
download: 272
Effect of Internal Resonance on the Radar Cross Section and Shield Effectiveness of Open Spherical Enclosures
Khalid Fawzy Ahmed Hussein
In this paper, the effects of the internal resonances of an open conducting spherical enclosure with circular aperture on its radar cross section (RCS) and shield effectiveness (SE) are studied over a wide frequency band. The sizes of the spherical enclosures investigated in the present work range from electrically small (perimeter is less than the wavelength) to electrically large (perimeter is up to ten times the wavelength). It is shown that for such an enclosure, both the RCS and SE, as functions of frequency, have sharp spikes, minima, or maxima at the resonant frequencies corresponding to the internal modes of the closed conducting sphere. Principal and higher order modes are considered. The effects of the aperture width on the perturbation of the field inside and outside of the spherical enclosure, the near field outside the cavity, the RCS and the SE are presented over a wide range of frequency. It is shown that the sharpness and amplitude of the spikes, minima, or maxima of the RCS and SE are decreased with increasing the aperture width. Also, the resonant frequencies of the enclosed spherical cavity are shifted with increasing the aperture width. For the purpose of verifying the accuracy of the obtained results for the SE of an open spherical enclosure at resonance, the obtained field configurations and distributions inside a spherical enclosure of a small aperture are compared to those of the spherical cavity modes which have already been obtained analytically. Also, some of the results concerning the RCS of a spherical enclosure are compared to other published results.
EFFECT OF INTERNAL RESONANCE ON THE RADAR CROSS SECTION AND SHIELD EFFECTIVENESS OF OPEN SPHERICAL ENCLOSURES
2007-01-31
PIER
Vol. 70, 211-223, 2007
download: 178
The Magnetic-Moment Quadric and Conditions of Vanishing Magnetic Moment for a Rotational Charged Body
Guo-Quan Zhou and Wen-Jun Zhou
Based on the concept of charge moment tensor which is different from the existent electric multiple-moment, and the concept of principal axes and principal-axis scalar charge moment, the condition of zero magnetic moment for an arbitrary rotational body with given charge distribution has been given explicitly in this paper. We find the loss of positive definiteness of is its most important characteristic which forms a sharp contrast with that of its mechanic counterpart - the positive definite inertia tensor of rigid bodies. Meanwhile the relationship between the quadric distributive law of magnetic moment and the parameters of tensor is discussed in detail. Accordingto the theory of analytic geometry, we give a series of test formulae, classify and enumerate every kind of possible quadric in a table. Finally, conclusion is given that any rotation axis which passes through origin O and alongwith any of the asymptotic line of the quadric (hyperboloids or hyperbolic cylinders) can lead to a vanishingmag netic moment.
THE MAGNETIC-MOMENT QUADRIC AND CONDITIONS OF VANISHING MAGNETIC MOMENT FOR A ROTATIONAL CHARGED BODY
2007-01-31
PIER
Vol. 70, 199-209, 2007
download: 231
Design and Experiment of One Dimension and Two Dimension Metamaterial Structures for Directive Emission
Zi-Bin Weng , Yong-Chang Jiao , Gang Zhao and Fu-Shun Zhang
Abstract-A new method to improve the gain of monopole and patch antenna with one dimension and two dimension metamaterial structures is presented. The analytical permittivity models of metamaterial are derived using the transmission line method. Then the monopole and patch antenna with the metamaterial are fabricated and measured. The experimental results show that this method is effective and these structures can realize congregating the radiation energy, thus the gain of these antennas with metamaterial increase greatly compared with the conventional ones.
DESIGN AND EXPERIMENT OF ONE DIMENSION AND TWO DIMENSION METAMATERIAL STRUCTURES FOR DIRECTIVE EMISSION
2007-01-30
PIER
Vol. 70, 191-198, 2007
download: 231
Design of a Microstrip Square-Ring Slot Antenna Filled by an h -Shape Slot for UWB Applications
Saeed Sadat , M. Houshmand and Mehdi Roshandel
A novel microstrip slot antenna for UWB (Ultra Wideband) applications is proposed. A square ring slot antenna is filledb y an H shape slot as a parasitic element. This structure is fed by a single microstrip line with a fork like-tuning stub. Experiments are carriedout to investigate its return loss, its radiation andits time domain behavior, which exhibit good radiation pattern and impedance bandwidth over the entire band of frequency. Time domain consideration also exhibits that this antenna can be used with short pulses. Extended from the proposed antenna, one advanced bandnotched( 5.5-7 GHz) design is also presentedas a desirable feature for UWB applications.
DESIGN OF A MICROSTRIP SQUARE-RING SLOT ANTENNA FILLED BY AN H-SHAPE SLOT FOR UWB APPLICATIONS
2007-01-25
PIER
Vol. 70, 175-189, 2007
download: 190
Modal Analysis of Azimuthally Periodic Vane-Loaded Cylindrical Waveguide Interaction Structure for Gyro-TWT
Ghanshyam Singh and B. N Basu
Abstract-This article discusses the gain-frequency characteristics of most competing modes of azimuthally periodic vane-loaded cylindrical waveguide interaction structure for gyrotron traveling wave tube (gyro- TWT) amplifier, which is the device of increasing importance because of its high-power and broad bandwidth capabilities. Vane-loading is identified as a means to achieve a low-beam energy, high-harmonic, low-magnetic field, mode-selective and stable operation of a gyro- TWT, and thus the development of a simple approach to the analysis of a vane-loaded gyro-TWT have been identified as a problem of practical relevance.
MODAL ANALYSIS OF AZIMUTHALLY PERIODIC VANE-LOADED CYLINDRICAL WAVEGUIDE INTERACTION STRUCTURE FOR GYRO-TWT
2007-01-22
PIER
Vol. 70, 79-174, 2007
download: 228
Analytical Methods in Theory of Slot-Hole Coupling of Electrodynamic Volumes
Mikhail Nesterenko , V. Katrich , Yuriy M. Penkin and Sergey L. Berdnik
The approximate analytical solution of the integral equation concerning the equivalent magnetic current in the narrow slot, coupling two electrodynamic volumes, has been obtained by the averaging method. The formulas and the plots for currents and the coupling coefficients of longitudinal and transverse slots in the common walls of rectangular waveguides are represented. By means of the induced magnetomotive forces method using basis functions of current distribution, obtained by the averaging method, the following electrodynamic structures have been considered: the electrically long longitudinal slot in the common broad wall of rectangular waveguides; two symmetrical transverse slots in the common broad wall of rectangular waveguides; the transverse slots system in the common broad wall of rectangular waveguides. The problem about the resonant iris with the arbitrary oriented slot in the plane of cross-section of a rectangular waveguide has been solved by the averaging method. The problem about stepped junction of two semi-infinite rectangular waveguides with the impedance slotted iris has been solved by the induced magnetomotive forces method. The analytical formulas for the distributed surface impedance of homogeneous and inhomogeneous magnetodielectric coatings of iris surface have been obtained. For a greater number of the considered electrodynamic structures the calculated values are compared with the results, obtained by numerical methods (also using commercial programs) and the experimental data.
ANALYTICAL METHODS IN THEORY OF SLOT-HOLE COUPLING OF ELECTRODYNAMIC VOLUMES
2007-01-20
PIER
Vol. 70, 53-78, 2007
download: 200
Structural Parameters in the Formation of Omnidirectional High Reflectors
Sudesh Singh , Janardan Pandey , Khem Thapa and Sant Ojha
We investigate the structural parameters for the formation of omnidirectional photonic band gap in one dimensional photonic crystal. Simple transfer matrix method is used for calculations. The effect of two parameters, namely, refractive index contrast and filling fraction on omnidirectional reflection is investigated. We find from our study that when nL, ni, ns and d are fixed, omnidirectional bandgap increases with increasing nH/nL i.e., with increasing nH. Therefore, omnidirectional bandgap can be increased by using the material of high refractive index nH when the low index material nL is fixed. We also find that for the considered system of Si-SiO2, omnidirectional reflection range increases with filling fraction, goes to a maximum value and finally comes to zero. The maximum value of the omnidirectional reflection range is obtained at a value of 0.29 of the filling fraction. The range for allowable values of refractive index of ambient medium ni has also been estimated.
STRUCTURAL PARAMETERS IN THE FORMATION OF OMNIDIRECTIONAL HIGH REFLECTORS
2007-01-20
PIER
Vol. 70, 37-52, 2007
download: 217
Characteristics of Electromagnetic Wave Propagation in Biaxial Anisotropic Left-Handed Materials
Wei Ding , Liang Chen and Chang-Hong Liang
This paper investigates the characteristics of electromagnetic wave propagation in biaxially anisotropic left-handed materials (BA-LHMs) theoretically and numerically. We discuss under what conditions the anomalous refraction or reflection will occur at the interface when a plane wave passes from one isotropic right-handed material into another BA-LHM. Meanwhile the refraction angle of the wave vector and that of the Poynting power are presented when the anomalous refraction takes place. According to the theoretical analysis,sev eral sets of constitutive parameters of BA-LHMs are considered. Then the anomalous refraction or reflection of the continuous-wave (CW) Gaussian Beam passing from free space into BA-LHMs are simulated by the finite difference time domain (FDTD) method based on the Drude dispersive models. The simulated results are in agreement with theoretical results,which validates the theoretical analysis.
CHARACTERISTICS OF ELECTROMAGNETIC WAVE PROPAGATION IN BIAXIAL ANISOTROPIC LEFT-HANDED MATERIALS
2007-01-20
PIER
Vol. 70, 21-36, 2007
download: 361
Amplitude-Only Pattern Nulling of Linear Antenna Arrays with the Use of Bees Algorithm
Kerim Guney and Murat Onay
An efficient method based on bees algorithm (BA) for the pattern synthesis of linear antenna arrays with the prescribed nulls is presented. Nulling of the pattern is achieved by controlling only the amplitude of each array element. Numerical examples of Chebyshev pattern with the single, multiple and broad nulls imposed at the directions of interference are given to show the accuracy and flexibility of the BA.
AMPLITUDE-ONLY PATTERN NULLING OF LINEAR ANTENNA ARRAYS WITH THE USE OF BEES ALGORITHM
2007-01-20
PIER
Vol. 70, 1-20, 2007
download: 267
Analysis and Design of Dual Band High Directive EBG Resonator Antenna Using Square Loop FSS as Superstrate Layer
Abbas Pirhadi , Farshad Keshmiri , Mohammad Hakkak and Majid Tayarani
Asup erstrate layer is used to enhance the directivity of the small radiation sources such as Microstrip Patch Antennas. In this paper, we use square loop frequency selective surface (SLFSS) configuration to design the superstrate layer. To compact the structure, we propose a new single layer square loop FSS configuration that operates in two frequency bands such as multi-layer SL-FSS. Simulation results are shown to have good agreement with experimental results.
ANALYSIS AND DESIGN OF DUAL BAND HIGH DIRECTIVE EBG RESONATOR ANTENNA USING SQUARE LOOP FSS AS SUPERSTRATE LAYER
