A Novel Beam-Switching Algorithm for Programmable Phased Array Antenna

Salil Sanyal,

Dr. Salil Sanyal

Department of Electronics & Telecom Engineering

Jadavpur University

India

Homepage

Quazi Alfred,

Prof. Quazi Alfred

Department of Electronics & Communication Engineering

University Institute of Technology, University of Burdwan

India

Homepage

Tapas Chakravarty

Dr. Tapas Chakravarty

TCS Research

India

Homepage

, Vol. 60, 187-196, 2006

doi:10.2528/PIER05122502 | Google Scholar

Abstract

In this paper a programmable beam-switching algorithm for planar phased array antenna is presented. Using micro-controller the planar array can be steered over 49 directions over the complete hemisphere. Each element is connected to delay lines and switching module. The bits at micro-controller output after being amplified by driver circuit are fed to the switching modules which control the insertion of fixed phase tapering. Switching is performed on a unique set of delay lines to steer the beam in particular direction in the horizon. For high frequency application PIN diode is used as switch. In total 12 bits are used to select 49 beam positions with some bit patterns being redundant.

Download Full Article (369) View Full Article volume

Citation

Copy Export

Salil Sanyal, Quazi Alfred, and Tapas Chakravarty, "A Novel Beam-Switching Algorithm for Programmable Phased Array Antenna," , Vol. 60, 187-196, 2006.
doi:10.2528/PIER05122502

References

1. Gu, J., H. Stark, and Y. Yang, "Design of tapped-delay line antenna array using vector space pro jections," IEEE Trans. Antenna Propag., Vol. 53, No. 12, 4178-4182, 2005.
doi:10.1109/TAP.2005.860004 Google Scholar

2. Chakraborty, A. and B. N. Das, "Phase scanning of one dimensional pattern," IEEE Trans. Antennas Propag., Vol. 32, No. 2, 189-192, 1984.
doi:10.1109/TAP.1984.1143276 Google Scholar

3. Karmakar, N. C. and M. E. Bialkowski, "A beam-forming network for a circular switched-beam phased array antenna," IEEE Microwave and Wireless Component Letters, Vol. 11, No. 1, 7-9, 2001.
doi:10.1109/7260.905951 Google Scholar

4. Sanyal, S. K., A. Goswami, D. R. Poddar, and S. K. Chowdhury, "A microprocessor controlled programmable switching module for phased array applications," Proceedings of IEEE, Vol. 76, No. 5, 636-638, 1988.
doi:10.1109/5.4451 Google Scholar

5. Balanis, C. A., Antenna Theory: Analysis and design, John Wiley & Sons, 1982.
