Antenna-on-Display (AoD) for Wireless Mobile Devices: Retrospect and Prospect
By
Huan-Chu Huang,

    Dr. Huan-Chu Huang

    Hefei Govisionox Technology Co. Ltd

    China

    Homepage

Jie Wu,

    Dr. Jie Wu

    Hefei Govisionox Technology Co. Ltd

    China

    Homepage

Shuang Cui,

    Dr. Shuang Cui

    Hefei Govisionox Technology Co. Ltd

    China

    Homepage

Dua-Chyrh Chang

    Prof. Dua-Chyrh Chang

    Bojay Electronics Company Ltd.

    China

    Homepage

Progress In Electromagnetics Research, Vol. 183, 91-106, 2025
doi:10.2528/PIER25021204
Abstract
This article presents the first comprehensive retrospect on an innovative and emerging antenna technology termed antennaon-display (AoD) for wireless mobile devices of 5G and beyond 5G (B5G, including 6G). The main backgrounds, benefits, stack-ups, ingredients, performance requirements, and various representative types of AoD are systematically introduced, analyzed, and discussed. Beyond its original role in wireless communication applications, AoD is also highly suitable for radar-based sensing or even for integrated sensing and communication (ISAC) to enable and enrich human-device interactions for more powerful artificial intelligence (AI) devices. Furthermore, the prospect of integrated millimeter-wave and microwave AoD designs is proposed as a promising development trend for AoD. Finally, an on-site demonstration of a smartphone featuring an AoD solution for real-time wireless video transmission at 28.0 GHz is presented.
