Abstract

Electromagnetic wave propagation and scattering in materials with time-variant parameters is subject of an active field of research. The theory is usually restricted to transverse-electric or transverse-magnetic modes in one- or two-dimensional settings. Here we discuss the theory of three-dimensional, multi-component electromagnetic waves in a homogeneous, time-variant material. We present 3 × 3 causal and acausal Green's matrices and a 6 × 6 propagator matrix. We derive a number of fundamental properties such as conservation of momentum density for a piecewise continuous, time-variant material, symmetry properties of the propagator matrix, and a relation between the causal and acausal Green's matrices. These properties are used in derivation of a general wave-field representation (the counterpart of the Kirchhoff integral for a time-invariant material) and an expression for Green's function retrieval with space-correlations (the counterpart of Green's function retrieval with time-correlations in a time-invariant material).

1. Morgenthaler, F. R., "Velocity modulation of electromagnetic waves," IRE Transactions on Microwave Theory and Techniques, Vol. 6, No. 2, 167-172, 1958.
doi:10.1109/tmtt.1958.1124533 Google Scholar

2. Jiang, Ching-Lin, "Wave propagation and dipole radiation in a suddenly created plasma," IEEE Transactions on Antennas and Propagation, Vol. 23, No. 1, 83-90, 1975.
doi:10.1109/tap.1975.1141007 Google Scholar

3. Mendonça, J. T. and P. K. Shukla, "Time refraction and time reflection: Two basic concepts," Physica Scripta, Vol. 65, No. 2, 160-163, 2002.
doi:10.1238/physica.regular.065a00160 Google Scholar

4. Koutserimpas, Theodoros T. and Romain Fleury, "Electromagnetic waves in a time periodic medium with step-varying refractive index," IEEE Transactions on Antennas and Propagation, Vol. 66, No. 10, 5300-5307, 2018.
doi:10.1109/tap.2018.2858200 Google Scholar

5. Caloz, Christophe and Zoé-Lise Deck-Léger, "Spacetime metamaterials --- Part I: General concepts," IEEE Transactions on Antennas and Propagation, Vol. 68, No. 3, 1569-1582, 2020.
doi:10.1109/tap.2019.2944225 Google Scholar

6. Ramaccia, Davide, Alessandro Toscano, and Filiberto Bilotti, "Light propagation through metamaterial temporal slabs: Reflection, refraction, and special cases," Optics Letters, Vol. 45, No. 20, 5836-5839, 2020.
doi:10.1364/ol.402856 Google Scholar

7. Apffel, Benjamin and Emmanuel Fort, "Frequency conversion cascade by crossing multiple space and time interfaces," Physical Review Letters, Vol. 128, No. 6, 064501, 2022.
doi:10.1103/physrevlett.128.064501 Google Scholar

8. Moussa, Hady, Gengyu Xu, Shixiong Yin, Emanuele Galiffi, Younes Ra'di, and Andrea Alù, "Observation of temporal reflection and broadband frequency translation at photonic time interfaces," Nature Physics, Vol. 19, No. 6, 863-868, 2023.
doi:10.1038/s41567-023-01975-y Google Scholar

9. Pacheco-Peña, Victor, Mathias Fink, and Nader Engheta, "Temporal chirp, temporal lensing, and temporal routing via space-time interfaces," Physical Review B, Vol. 111, No. 10, L100306, 2025.
doi:10.1103/physrevb.111.l100306 Google Scholar

10. Stefanini, Luca, Emanuele Galiffi, Shixiong Yin, Sahitya Singh, Diego M. Solís, Nader Engheta, Alessandro Toscano, Davide Ramaccia, Filiberto Bilotti, and Andrea Alù, "Theory and experimental observation of scattering by a space-time corner," Physical Review Letters, Vol. 135, No. 11, 113802, 2025.
doi:10.1103/1p4g-wt7h Google Scholar

11. Xiao, Yuzhe, Drew N. Maywar, and Govind P. Agrawal, "Reflection and transmission of electromagnetic waves at a temporal boundary," Optics Letters, Vol. 39, No. 3, 574-577, 2014.
doi:10.1364/ol.39.000574 Google Scholar

12. Salem, Mohamed A. and Christophe Caloz, "Space-time cross-mapping and application to wave scattering," arXiv preprint arXiv:1504.02012, 2015.
doi:10.48550/arXiv.1504.02012 Google Scholar

13. Caloz, Christophe and Zoé-Lise Deck-Léger, "Spacetime metamaterials --- Part II: Theory and applications," IEEE Transactions on Antennas and Propagation, Vol. 68, No. 3, 1583-1598, 2020.
doi:10.1109/tap.2019.2944216 Google Scholar

14. Wapenaar, Kees, Johannes Aichele, and Dirk-Jan van Manen, "Waves in space-dependent and time-dependent materials: A systematic comparison," Wave Motion, Vol. 130, 103374, 2024.
doi:10.1016/j.wavemoti.2024.103374 Google Scholar

15. Van Manen, Dirk-Jan, Johannes Aichele, Jonas Müller, Marc Serra-Garcia, and Kees Wapenaar, "On acoustic space-time media that compute their own inverse," arXiv preprint arXiv:2406.15203, 2024.
doi:10.48550/arXiv.2406.15203 Google Scholar

16. Koutserimpas, Theodoros T., "Wake-tail effects in two-dimensional wave refocusing," Physical Review E, Vol. 113, No. 6, 065102, 2026.
doi:10.1103/pv58-tf9k Google Scholar

17. Pacheco-Peña, Victor and Nader Engheta, "Effective medium concept in temporal metamaterials," Nanophotonics, Vol. 9, No. 2, 379-391, 2020.
doi:10.1515/nanoph-2019-0305 Google Scholar

18. Štumpf, Martin, Fabrizio Loreto, Giulio Antonini, and Jonas Ekman, "Pulsed wave propagation along a transmission line with time-varying wavespeed," IEEE Microwave and Wireless Technology Letters, Vol. 33, No. 7, 963-966, 2023.
doi:10.1109/lmwt.2023.3266921 Google Scholar

19. Wapenaar, Kees, "Green's functions, propagation invariants, reciprocity theorems, wave-field representations and propagator matrices in two-dimensional time-dependent materials," Proceedings of the Royal Society A, Vol. 481, No. 2307, 20240479, 2025.
doi:10.1098/rspa.2024.0479 Google Scholar

20. Budko, Neil V., "Electromagnetic radiation in a time-varying background medium," Physical Review A, Vol. 80, No. 5, 053817, 2009.
doi:10.1103/physreva.80.053817 Google Scholar

21. De Hoop, Adrianus T. and Ioan E. Lager, "Closed-form analytic expressions for the pulsed-source radiated electromagnetic field in a class of media with time-varying wave speed," Wave Motion, Vol. 51, No. 3, 418-424, 2014.
doi:10.1016/j.wavemoti.2013.11.004 Google Scholar

22. Koutserimpas, Theodoros T. and Romain Fleury, "Electromagnetic fields in a time-varying medium: Exceptional points and operator symmetries," IEEE Transactions on Antennas and Propagation, Vol. 68, No. 9, 6717-6724, 2020.
doi:10.1109/tap.2020.2996822 Google Scholar

23. Landau, L. D. and E. M. Lifshitz, Electrodynamics of Continuous Media, Pergamon Press, 1960.

24. De Hoop, A. T., Handbook of Radiation and Scattering of Waves, Academic Press, London, 1995.

25. Torrent, Daniel, William J. Parnell, and Andrew N. Norris, "Loss compensation in time-dependent elastic metamaterials," Physical Review B, Vol. 97, No. 1, 014105, 2018.
doi:10.1103/physrevb.97.014105 Google Scholar

26. Stumpf, Martin and Giulio Antonini, "State-variable analysis of pulsed EM-fields in temporally layered media," Scientific Reports, 2026.
doi:10.1038/s41598-026-44439-y Google Scholar

27. Feynman, R., R. Leighton, and M. Sands, The Feynman Lectures on Physics, Volume II, California Institute of Technology, 1963.

28. Burns, Lucas, Konstantin Y. Bliokh, Franco Nori, and Justin Dressel, "Acoustic versus electromagnetic field theory: Scalar, vector, spinor representations and the emergence of acoustic spin," New Journal of Physics, Vol. 22, No. 5, 053050, 2020.
doi:10.1088/1367-2630/ab7f91 Google Scholar

29. Lorentz, Hendrik Antoon, "The theorem of Poynting concerning the energy in the electromagnetic field and two general propositions concerning the propagation of light," Koninklijke Akademie van Wetenschappen, Vol. 4, 176-187, 1895. Google Scholar

30. Knopoff, Leon and Anthony F. Gangi, "Seismic reciprocity," Geophysics, Vol. 24, No. 4, 681-691, 1959.
doi:10.1190/1.1438647 Google Scholar

31. De Hoop, Adrianus T., "Time-domain reciprocity theorems for electromagnetic fields in dispersive media," Radio Science, Vol. 22, No. 7, 1171-1178, 1987.
doi:10.1029/rs022i007p01171 Google Scholar

32. Knopoff, L., "Diffraction of elastic waves," The Journal of the Acoustical Society of America, Vol. 28, No. 2, 217-229, 1956.
doi:10.1121/1.1908247 Google Scholar

33. De Hoop, Adrianus Teunis, "Representation theorems for the displacement in an elastic solid and their application to elastodynamic diffraction theory," Delft University of Technology, Delft, The Netherlands, 1958.

34. Gangi, Anthony F., "A derivation of the seismic representation theorem using seismic reciprocity," Journal of Geophysical Research, Vol. 75, No. 11, 2088-2095, 1970.
doi:10.1029/jb075i011p02088 Google Scholar

35. Stratton, J. A., Electromagnetic Theory, McGraw-Hill, New York, 1941.

36. Weaver, Richard L. and Oleg I. Lobkis, "Ultrasonics without a source: Thermal fluctuation correlations at MHz frequencies," Physical Review Letters, Vol. 87, No. 13, 134301, 2001.
doi:10.1103/physrevlett.87.134301 Google Scholar

37. Campillo, Michel and Anne Paul, "Long-range correlations in the diffuse seismic coda," Science, Vol. 299, No. 5606, 547-549, 2003.
doi:10.1126/science.1078551 Google Scholar

38. Wapenaar, Kees, "Synthesis of an inhomogeneous medium from its acoustic transmission response," Geophysics, Vol. 68, No. 5, 1756-1759, 2003.
doi:10.1190/1.1620649 Google Scholar

39. Snieder, Roel, "Extracting the Green's function from the correlation of coda waves: A derivation based on stationary phase," Physical Review E, Vol. 69, 046610 , 2004.
doi:10.1103/physreve.69.046610 Google Scholar

40. Malcolm, Alison E., John A. Scales, and Bart A. van Tiggelen, "Extracting the Green function from diffuse, equipartitioned waves," Physical Review E, Vol. 70, 015601, 2004.
doi:10.1103/physreve.70.015601 Google Scholar

41. Roux, Philippe and W. A. Kuperman, "Extracting coherent wave fronts from acoustic ambient noise in the ocean," The Journal of the Acoustical Society of America, Vol. 116, No. 4, 1995-2003, 2004.
doi:10.1121/1.1797754 Google Scholar

42. Slob, Evert, Deyan Draganov, and Kees Wapenaar, "Interferometric electromagnetic Green's functions representations using propagation invariants," Geophysical Journal International, Vol. 169, No. 1, 60-80, 2007.
doi:10.1111/j.1365-246x.2006.03296.x Google Scholar

43. Slob, Evert C. and Kees Wapenaar, "Retrieving the Green's function from cross correlation in a bianisotropic medium," Progress In Electromagnetics Research, Vol. 93, 255-274, 2009.
doi:10.2528/pier09041004 Google Scholar

44. Stehly, L., M. Campillo, B. Froment, and R. L. Weaver, "Reconstructing Green's function by correlation of the coda of the correlation (C3) of ambient seismic noise," Journal of Geophysical Research: Solid Earth, Vol. 113, No. B11, 2008.
doi:10.1029/2008JB005693 Google Scholar

45. Wapenaar, Kees and Joost van der Neut, "A representation for Green's function retrieval by multidimensional deconvolution," The Journal of the Acoustical Society of America, Vol. 128, No. 6, EL366-EL371, 2010.
doi:10.1121/1.3509797 Google Scholar

46. van der Neut, Joost, Jan Thorbecke, Kurang Mehta, Evert Slob, and Kees Wapenaar, "Controlled-source interferometric redatuming by crosscorrelation and multidimensional deconvolution in elastic media," Geophysics, Vol. 76, No. 4, SA63-SA76, 2011.
doi:10.1190/1.3580633 Google Scholar

47. Curtis, Andrew and David Halliday, "Directional balancing for seismic and general wavefield interferometry," Geophysics, Vol. 75, No. 1, SA1-SA14, 2010.
doi:10.1190/1.3298736 Google Scholar

Professor Kees Wapenaar

Dr. Evert C. Slob
